Celestron FirstScope 90AZ Quick Setup page 2

Quick Set-up Guide [cont]
10
Orient the Star Pointer so that the glass
window is facing towards the front of the tube.
Place Starpointer over the posts on the tube
and tighten it down with the knurled nuts.
13
Properly assembled, slow motion cables
should appear as shown above.
16
Insert the chrome barrel of the 20mm eyepiece
into the focuser and tighten the set screw.
For detailed usage information please consult your owner's manual.
11
Slide the chrome end of the slow motion
control cable onto gear shaft and tighten set
screw to secure in place.
14
Loosen the set screw on the focuser so that it
does not obstruct the inner diameter of the
focuser. Remove the plastic cap covering the
end of the focuser.
17
Remove the lens cap from the front of the
telescope before you begin observing.
12
Slide the chrome end of the other slow motion
control cable onto gear shaft located under
tube as shown.
15
Insert the diagonal into the focuser and tighten
the set screw.
