ekwb EK-FB KIT GA X79 (UD7) Installation And Mounting Manuals

Installation and mounting manual for EK-FB KIT GA X79 (UD7) water block:
This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at
Before installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box or our home page.
The barb hose fittings require only a small amount of force to screw them in; otherwise the high flow fittings might break. These fittings do not need to be tightened with much force because the
liquid seal is made using o-rings. The use of corrosion inhibitors is always recommended for any liquid cooling system.
STEP 1: GENERAL INFORMATION Sample photo of Gigabyte GA-X79-UD7 (rev. 1.0) motherboard
STEP 2: PREPARING YOUR MOTHERBOARD
1. REMOVING STOCK COOLER.
on the back of the motherboard that needs to be removed in order to remove the
factory installed SB/MOSFET heatpipe cooling solution.
3. APPLYING THERMAL COMPOUND.
Intel X79 PCH
(SB) with electrically non-conductive thermal grease - for example
Arctic Cooling MX-2 ™ or MX-4 ™. EKWB recommends to apply thermal grease in
cross form for best performance (see sample picture).
5. PLACING THERMAL PADS ON MOTHERBOARD.
SIDES OF THE THERMAL PADS PRIOR TO INSTALLATION). EK recommends using small drops of electrically non-conductive (for example: Arctic Cooling MX-2 ™ or MX-4 ™)
thermal grease on each phase regulator (that is being covered with thermal pad; see picture below) in order to even further improve the thermal performance of the EK-FB KIT
GA X79 (UD7) series water block.
All disclosures, notices and warranty conditions are being written on EKWB web page. Please check terms of use.
X79 PCH (SB)
Remove all encircled screws. There are 6 screws
Apply thermal compound: lightly coat the
Place thermal pads you cut on PCB as shown on picture bellow (PLEASE REMOVE THE PROTECTIVE FOIL FROM BOTH
2. CLEANING THE PCB.
Carefully detach the original stock cooler after removing all
screws securing it to the board. Wipe off the remains (by using non–abrasive cloth or
qtip
, as shown on sample photo) of the original thermal compound until the components
and circuit board are completely clean. EKWB recommends the use of denatured alcohol
for removing TIM leftovers.
4. CUTTING THERMAL PADS.
Your block comes with one (1) Thermal Pad A – 0.5mm
(100x16) which may need to be trimmed a bit in order to fit the voltage regulation area
(VRM/MOSFET) on the motherboard's circuit board.
WARNING: DIMENSIONS ON PICTURES BELOW ARE SCALED!
www.ekwaterblocks.com
Mosfets
CPU socket
Place 0.5mm thermal pad in large strip
over marked area and make sure all
mosfet chips are covered.
th
Released on 9 of February, 2012.
for updates.
