IT IS IMPORTANT FOR EVERYONE'S SAFETY THAT ALL INSTRUCTIONS ARE FOLLOWED.
RETAIN THESE INSTRUCTIONS.

Conditions for installation

• This screen is intended for interior use.
• Requires a single phase electricity supply 230 V / 50 Hz + earth.
• Corresponds to standards CE EN 60335-1 and EN 60335-2-97
- Class 1 electric motor, to be fitted with a ground wire during installation (supply cable).
- Supply cable straight inside the motor with no casing interconnect.
- Case electrically isolated from the motor by the mounting system.
• Do not cut the motor cable to less than 10 cm in length.

Conditions for use

• Designed for optimum usage between 15°C and 25°C and maximum humidity of 80%.
• Must be kept away from sources of heat (as these may cause fabric deformation) and protected from splashes of water, steam, dust,
smoke or any other hazards that may damage the equipment.
• The motor is equipped with a thermal circuit breaker with automatic resetting. It is designed to function continuously for 4 mn.
Beyond this, it will stop in order to cool down.
Caution: automatic resetting: for safety, reset reverse to stop position beforehand.
• This class of screen is designed to be used intermittently, in other words, a few times each day.
!
Because the weight of the fabric and the slat bar, nobody must be under the screen.

Fixing the screen

• Position the adjustable brackets along the case.
Caution : do not place them further than one meter from each end (see A)
• Mount using screws and hardware suited to the type of wall or ceiling: see B or C. It is essential to check that the fixings are secure.
• Ensure that the screen is kept horizontal (max. variation of 3 mm per m ).
Mount the screen on the brackets: see D.
•
• Lock the screen on the fixing brackets: see E.
• It is vital that the 2 elastomer locks are in place and kept clean so that they stay in place.

Electrical connection

• See F.
• 3 position switch (up – stop – downs)
Caution: never wire in 2 switches in order to obtain 2 control points.

Operation

• The limit switches have been pre-set at the factory. Incorrect use could void the guarantee.
If you notice that
• The screen is not moving: check the electrical connection.
• The screen will come down but does not have enough power to retract and/or makes an unusual noise : check the electrical
connection. It is possible that the 2 motor windings (up and down = black and brown wires) are connected simultaneously (should be
avoided at all costs as there is the risk of damaging the motor).
• The screen stops or fails to function after several operations: the motor, which is designed for intermittent use (maximum 4 to 5 mn
in a row) has reached its maximum temperature and the thermal safety function has cut in: wait a few minutes for it to cool down.
• If in doubt, contact your dealer.

Maintenance

• The mechanical components do not require any maintenance.
• If the fabric becomes stained (matte white) use only a small quantity of industrial ethyl alcohol and rub gently with a lint free white
cotton cloth (with any other product, there is the risk of leaving a ring or destroying the surface).
Projecta reserves the right to modify its products in order to make technical improvements.
