Capacitive sensors with easyreach function

Table of Contents

Available languages

ET = Easy Teach Push Button

Test

The test function can be used to check the control system that is connected to the sensor.

• Press the EasyTeach button with the screwdriver

and hold it until the yellow-green LED is flashing

and the outputs switch pulsating at the same

time.

For leaving the test mode release the EasyTeach

button. The sensor returns to the previously ad-

justed state.

ETW = Easy Teach by wire

• Connect the grey teach wire (Pin 5) to the supply

voltage and hold it until the LED is flashing yel-

low-green and the outputs switch pulsating at the

same time.

Leave the test mode by disconnecting the grey

teach wire from the supply voltage. The sensor re-

turns to the previously adjusted state.
