Mark Bric ISOframe IS-9103 Mounting Instructions

Straight standard units
Item IS-9103
Width 2500 mm / 98.5"
Depth 495 mm / 19.5"
Height 1050 mm / 41.5"
Item IS-9104
Width 3300 mm / 130"
Depth 495 mm / 19.5"
Height 1050 mm / 41.5"
Item IS-9105
Width 4100 mm /161.5"
Depth 495 mm / 19.5"
Height 1050 mm / 41.5"
Starter & Extension units
Structure - Starter
Starter, curved Item IS-9111
Starter, straight Item IS-9113
Structure - Extension
Extension, curved Item IS-9112
Extension, straight Item IS-9114
Curved standard units
Item IS-9108
Width 2290 mm / 90"
Depth 830 mm / 32.5"
Height 1050 mm / 41.5"
Item IS-9109
Width 2760 mm /108.5"
Depth 1060 mm / 41.5"
Height 1050 mm / 41.5"
Item IS-9110
Width 3040 mm / 119.5"
Depth 1330 mm / 52.5"
Height 1050 mm / 41.5"
Table tops
Table top end, curved Item IS-9005
Table top center, curved Item IS-9006
Table top end, straight Item IS-9008
Table top center, straight Item IS-9009
Mounting instructions
Inner shelves
Curved Item IS-9007
Straight Item IS-9010
