INSTALLING THE DIVABOX MULTIMEDIA CARTDIDGE

If you have got a first multimedia cartridge with your DIVABOX, you should attach the cartridge to
the main unit, before turning the unit on, according to below procedure:
1. Remove the fake cartridge and moving the fake cartridge away in direction (1)
1
2. Position your DivaBox cartridge on top of the (2) cavity. Move gently in either direction (3)
or (4) until the cartridge falls in the rail.
3.
Then push in (4) direction until you hear a light "click".
To remove the cartridge, first turn off the main unit; repeat the same procedure: slide in direction
(5) and move it up to eject and store away the HMS cartridge.
Quick Installation Guide
2
5
DivaBox
1
3
4
© Storex 2009 7
