BEFORE STARTING
Connection between the DivaBox and the TV
Antenna wall socket
Rear TV
2
3
1
Antenna cable
Composite cable
HDMI cable
3
4
2
1
1. Connect the antenna cable (provided) between the DivaBox and your antenna wall socket
2. Connect the DivaBox to the television with the AV cable (depending on your configuration).
3. Connect the DivaBox to the television with the provided HDMI cable (depending on your
configuration).
4. Connect the power supply adapter to the DC IN port of the DivaBox.
Quick Installation Guide
DivaBox
© Storex 2009
10
