INSTALLING THE DVB-T CHANNELS
1. Connect the cable antenna of your antenna wall socket to the "Antenna IN" DivaBox (see
illustration page 10).
2. Check that HDMI cable is well connected between the DivaBox and the TV.
3. Connect the power supply cable of the wall socket to the "DC IN" of the DivaBox (see
illustration page 10). Turn on the unit by pressing the
have the following screen:
4. Select "HDTV" in order to be able to start the scan of DVB-T channels.
5. Press the key "MENU" of your remote control, 4 icons will appear at the bottom of the page:
6. Select the third icon in order to reach the page that allows to scan automatically the DVB-T
channels:
Quick Installation Guide
, once the unit is lit you should
" " button
DivaBox
© Storex 2009
12
