Assembly Instructions
Kettler BTR 300
Exercise Bike
IMPORTANT
PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE.
THIS IS IMPORTANT INFORMATION REGARDING THE USE
AND CARE OF YOUR EXERCISE EQUIPMENT.
Feb 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTR 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kettler BTR 300

Summary of Contents for Kettler BTR 300

  • Page 1 Assembly Instructions Kettler BTR 300 Exercise Bike IMPORTANT PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE. THIS IS IMPORTANT INFORMATION REGARDING THE USE AND CARE OF YOUR EXERCISE EQUIPMENT. Feb 2021...

  • Page 2: Safety Notice

    Safety Notice Warning This exercise bike has been designed and constructed to provide maximum safety. Nevertheless, certain precautions should be taken when using exercise equipment. Read the whole manual before assembling and using the exercise bike. The following safety precautions should also be observed: •...

  • Page 3: Pre-Assembly Notes

    Pre-assembly Notes Open the boxes: Make sure you check you have all of the parts listed in the box prior to assembly. If there are any parts missing, please contact the supplier. Ø10 - Qty 2 Ø10 - Qty 8 Ø10.

  • Page 4: Gather Your Tools

    Gather Your Tools Before starting assembly ensure you have the correct tools. Name Specification Quantity L-shaped wrench 5x80x80S (with a cross) L-shaped wrench 6x40x120 Open-end wrench t4. 0x32x110 Clear your work area Make sure that you have cleared away a large enough space to properly assemble the unit. Make sure the space is free from anything that may cause injury during assembly.

  • Page 5: Product Diagram

    Product Diagram Console Bottle Holder Handle Bar Saddle Pedal (R) Front Stabiliser Pedal (L) Back Stabiliser Dimension 1090x560x1490mm Speed Ratio Flywheel Outer magnet with double way: Ø280/9kg Up & Down 9 level, 270mm distance Front & Back 70mm distance *We reserve the right to amend the product without prior notice.
  • Page 6 Assembly Instructions Step 1: Attach the front stabiliser (2) to the main frame (1) with curved washer (28), spring washer (27) and Allen C.K.S. half thread screw(26). Step 2: Attach the rear stabiliser (3) to the main frame (1) with curved washer (28), spring washer (27) and Allen C.K.S.
  • Page 7 Assembly Instructions Step 3: Loosen the knob and attach saddle post (4) to the main frame. Then tighten the knob. Step 4: • Attach saddles (5) to the saddle post (4) with casing (25) and handle knobs (23), do not tighten them. •...
  • Page 8 Assembly Instructions Step 5: • Attach the Upright post trim strip (46) to the Upper upright post (6). Take the Upright post cover (13) from main frame (1). Then attach to the upper upright post (6). • Connect motor communication wire (10) and console communication wire (9).
  • Page 9 Assembly Instructions Step 7: • Connect communication wire (9) and back hole of the console. Connect handle pulse connection wire (11) and console outlet (12). • Attach console (8) to upper upright post (6) with Philips C.K.S. full thread screw (24). •...

  • Page 10: Workout Tips

    Assembly Instructions Step 9: Attach bottle holder (20) to upper upright post (6) with Philips pan head full thread screw (37). Workout Tips • The user is required to put their feet completely inside the pedal. • Adjust the magnetic resistance according to the user. •...
  • Page 11 Finished.
  • Page 12 Half-Drawing for Assembly...

  • Page 13: Parts List

    Parts List Name Specification Quantity Main frame Front stabiliser Rear stabiliser Saddle post Saddle Upper upright post Handlebar post Console Console communication wire Motor communication wire Handle pulse connection wire Console outlet Upright post cover Handlebar cover(L) Handlebar cover(R) Saddle cover(L) Saddle cover(R) Saddle cover(R) Pedal(R)
  • Page 14 Drawing for Assembly...
  • Page 15 Parts List Name Specification Quantity Main frame Front stabiliser Rear stabiliser Saddle post Saddle Upper upright post Handlebar post Console Console communication wire Motor communication wire Handle pulse connection wire Console outlet Upright post cover Handlebar cover(L) Handlebar cover(R) Saddle cover(L) Saddle cover(R) Saddle cover(R) Pedal(R)
  • Page 16 Parts List Name Specification Quantity Flat washer Ø8. 5xØ20xt1.5 Hex locking nut Flat washer Ø10 Allen C.K.S. full thread screw M10×20 Allen C.K.S. half thread screw M10×55×20 Philips pan head full thread screw M4×16 Saddle locking piece Crank cover Ø23x6xM22xP1.0 Hex flange full thread screw 5/16-18UNC-1"...
  • Page 17 Parts List Name Specification Tension wheel Ø38x22 Tension spring Ø18xØ2. 0x14 Tension spring Ø11. 5xØ1. 2x13 Square magnet 30x25xt12 Magnet axis Ø12x50 Deep groove ball bearing 6300-2RS Flat washer Ø34xØ25xt1.0 Fixed tension wheel Deep groove ball bearing 6003-2RS One-way kingpin ball bearing Ø35xØ17x16 Small belt pulley Ø30x64...

  • Page 18: Display Functions

    Display Functions Item Description Time Display Range 0:00 ~ 99:59; Setting range 0:00 ~ 99:00 Speed Range 0. 0 ~ 99.9KM/H Distance Display Range 0. 0 ~ 99.99; Setting range 0. 0 ~99.90 Calories Display Range 0 ~ 9999 Cal; Settingrange 0 ~ 9990 Cal Pulse Display Range P-30 ~230;...

  • Page 19: Operation

    Operation POWER ON Plug in power supply, computer will power on with a long beep sound and display all segments on LCD for 2 seconds(Drawing 1). Enter into user selection (Drawing 2) and personal data setting mode (Age, Gender, Height, Weight). After 4 minutes without pedalling or pulse input, console will enter into power saving mode.
  • Page 20 Operation Workout Selection In main page, the first program MANUAL is flashing (Drawing 5). User can press UP(+) or DOWN(- ) to select: MANUAL-->PROGRAM-->USER PROGRAM-->H R.C. -->WATT, press ENTER to confirm. Manual Mode 1. Press UP(+) or DOWN(-) to select workout program, choose Manual (Drawing 4) and press ENTER key to confirm.
  • Page 21 Operation 3. Hold on pressing ENTER to finish or quit setting. 4. Press UP(+) or DOWN(-) to preset workout TIME. 5. Press START/STOP button to start workout. During workout, user can press UP(+) or DOWN(-) to adjust load level from 1-16. 6.
  • Page 22 Operation Watt Mode 1. Press UP(+) or DOWN(-) to select workout program, choose WATT (Drawing 10) and press ENTER key to confirm. 2. Press UP(+) or DOWN(-) to preset WATT target. (default: 120) 3. Press UP(+) or DOWN(-) to preset workout TIME. 4.
  • Page 23 Operation Drawing 13 BMI (Body Mass Index) integrated LOW/MED MEDIUM MED/HIGH Scale Range <20 20>24 24. 1-26. 5 >26. 5 Body Fat: Symbol Ø Ø Fat% LOW/MED MEDIM MED/HIGH Male <13% 13%-25. 9% 26%-30% >30% Female <23% 23%-35. 9% 36%-40% >40% Recovery When pulse value display on the computer (hold hand grips), press RECOVERY button.
  • Page 24 Operation Drawing 14 Drawing 15 BMI (Body Mass Index) integrated Outstanding 1.0 < F < 2.0 Excellent 2.0 < F < 2.9 Good 3.0 < F < 3.9 Fair 4.0 < F < 5.9 Below Average Poor Note: 1. This computer require 9V, 1300mA adaptor. 2.

  • Page 26: For Your Safety

    • Damaged components may endanger your safety or shorten the life of the product. Replace all damaged parts immediately. Use only spare parts manufactured by Kettler. For further information and spare parts visit our website www. kettler. co. uk/shop Attention •...
