ECO Sensors OS-6 User Manual

The OS-6 is an industrial grade ozone controller and monitor. The OS-6 design is optimized for
accuracy and ease of installation, setup and operation.
Front panel digital LCD displays ozone level.
Rugged, splash resistant NEMA 4X enclosure for
industrial environments.
Easily accessible
controls allow the unit to be setup after it is
mounted.
LED indicators display when ozone exceeds the
0.1 ppm OSHA limit and a variety of other
important ozone control parameters.
Set points for ozone generator control relays are
digitally controlled with numeric set points. This
makes precise ozone control easy to set up, even
when ozone is not present.
Ozone generator failure mode detection warns when the connected ozone generator is not
maintaining the desired ozone set points. This option can be disabled.
"Monitor Mode" can be enabled on the OS-6 panel. This mode disables the ozone generator
controller and generator failure mode status indicators while maintaining ozone measurement
and limit warning indicators.
Analog outputs (4-20 mA and 0-2 VDC) are compatible with PLCs and other process
controllers.
Digital serial output (RS-232) allows for convenient connection to a computer. Data output:
ozone (ppb), temperature (°C), and relative humidity (%).
Eco Sensors
Division of KWJ Engineering Inc.
sales@ecosensors.com or (800) 472‐6626
OZONE SWITCH
Model OS-6

OS-6 Features

connection terminals
Ozone Controller, Model OS‐6
and
User Manual, Rev. 1.4
USER MANUAL
1
