FOREWORD
Thank We understand that you have a choice of many
different radios in the market place. We want to take a
couple of moments of your time to thank you for mak-
ing the IC-703 your radio of choice, and hope you
agree with Icom's philosophy of "technology first."
Many hours of research and development went into
the design of your IC-703.
FEATURES
❍ DSP features (AF DSP; UT-106
some version)
❍ All mode capability covering 160–6 m
❍ 9.0–15.87 V operation
❍ Compact with detachable front panel
❍ ±0.5 ppm of high frequency stability
❍ Built in antenna tuner
❍ Simple band scope function
PRECAUTION
R WARNING RF EXPOSURE!
Radio Frequency (RF) energy. Extreme caution should be
observed when operating this device. If you have any
questions regarding RF exposure and safety standards
please refer to the Federal Communications Commission
Office of Engineering and Technology's report on Evalu-
ating Compliance with FCC Guidelines for Human Radio
Frequency Electromagnetic Fields (OET Bulletin 65).
R WARNING HIGH VOLTAGE! NEVER
antenna or internal antenna connector during transmis-
sion. This may result in an electrical shock or burn.
R NEVER
apply AC to the [DC13.8V] receptacle on the
transceiver rear panel. This could cause a fire or damage
the transceiver.
R NEVER
apply more than 16 V DC, such as a 24 V
battery, to the [DC13.8V] receptacle on the transceiver
rear panel. This could cause a fire or damage the trans-
ceiver.
R NEVER
let metal, wire or other objects touch any in-
ternal part or connectors on the rear panel of the trans-
ceiver. This may result in an electric shock.
NEVER expose the transceiver to rain, snow or any liquids.
AVOID using or placing the transceiver in areas with tem-
peratures below –10°C (+14°F) or above +60°C (+140°F).
Be aware that temperatures on a vehicle's dashboard can
exceed 80°C (+176°F), resulting in permanent damage to
the transceiver if left there for extended periods.
AVOID placing the transceiver in excessively dusty envi-
ronments or in direct sunlight.
i
IMPORTANT
READ THIS INSTRUCTION MANUAL
CAREFULLY
transceiver.
SAVE THIS INSTRUCTION MANUAL.
manual contains important safety and operating in-
structions for the IC-703.
EXPLICIT DEFINITIONS
required
DSP UNIT
R R WARNING
AVOID placing the transceiver against walls or putting
This device emits
anything on top of the transceiver. This will obstruct heat
dissipation.
Place unit in a secure place to avoid inadvertent use by
children.
During mobile operation, DO NOT operate the transceiver
without running the vehicle's engine. When the trans-
ceiver's power is ON and your vehicle's engine is OFF,
attach an
the vehicle's battery will soon become exhausted.
Make sure the transceiver power is OFF before starting
the vehicle. This will avoid possible damage to the trans-
ceiver by ignition voltage spikes.
During maritime mobile operation, keep the transceiver
and microphone as far away as possible from the magnetic
navigation compass to prevent erroneous indications.
BE CAREFUL! The rear panel will become hot when op-
erating the transceiver continuously for long periods.
BE CAREFUL! If a linear amplifier is connected, set the
transceiver's RF output power to less than the linear am-
plifier's maximum input level, otherwise, the linear ampli-
fier will be damaged.
Use Icom microphones only (supplied or optional). Other
manufacturer's microphones have different pin assign-
ments, and connection to the IC-703 may damage the
transceiver.
Beat signals may be heard on some frequencies.
These will occur as a result of circuit construction.
For U.S.A. only
Caution: Changes or modifications to this transceiver, not
expressly approved by Icom Inc., could void your authority
to operate this transceiver under FCC regulations.
before attempting to operate the
WORD
Personal injury, fire hazard or electric
shock may occur.
CAUTION Equipment damage may occur.
If disregarded, inconvenience only. No
risk or personal injury, fire or electric
NOTE
shock.
This
DEFINITION
