INSTRUCTIONS
®
Congratulations on selecting your new Carson binoculars!
With reasonable care,your binoculars will provide you with years of enjoyment.
In order to achieve optimum performance,please read the instructions
carefully on the proper use and care of your binoculars.
Instructions for Care
Like any fine optical instrument,your binoculars should be
given sensible care. Keep the lens covers (not included with
some models) on the lenses when binoculars are not in use.
Do not drop or violently jar your binoculars. This may cause the internal
optical components of your binoculars to become misaligned resulting
in a double image when looking through them.Non-waterproof models
should not be exposed to excessive moisture.
