Congratulations on selecting your new Carson binoculars!
With reasonable care, your binoculars will provide you with years of enjoyment.
In order to achieve optimum performance, please read the instructions carefully on the
proper use and care of your binoculars.
Specifications
Model
TD-832ED
Magni cation
8x
Objective Lens Diameter 32mm
Prism
BAK-4
Fully
Lens Coating
Multi-Coated
Field of View
392 feet
Eye Relief
19.5mm
Close Focus
6.6 feet
O-Ring Sealed
Yes
Phase Coated
Yes
Waterproof / Fogproof
Yes
ED Glass Objective Lens
Yes
Weight
1.2 lbs.
Dimensions
4.9" x 4.8" x 1.8" 5.5" x 5" x 2"
TD-842ED
TD-042ED
TD-042EDMO
8x
10x
10x
42mm
42mm
42mm
BAK-4
BAK-4
BAK-4
Fully
Fully
Fully
Multi-Coated
Multi-Coated
Multi-Coated
341 feet
314 feet
314 feet
19.5mm
16mm
16mm
9.8 feet
9.8 feet
9.8 feet
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1.4 lbs.
1.5 lbs.
1.5 lbs.
5.5" x 5" x 2"
5.5" x 5" x 2"
TD-050ED
10x
50mm
BAK-4
Fully
Multi-Coated
262 feet
20mm
13.1 feet
Yes
Yes
Yes
Yes
1.7 lbs.
6.8" x 5.3" x 2.5"
INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Carson TD-832ED
Summary of Contents for Carson TD-832ED
- Page 1 INSTRUCTIONS Congratulations on selecting your new Carson binoculars! With reasonable care, your binoculars will provide you with years of enjoyment. In order to achieve optimum performance, please read the instructions carefully on the proper use and care of your binoculars.
-
Page 2: Prism System
Prism System eyepiece Your Carson 3D binoculars feature a roof prism system. The prisms overlap closely allowing the objective (front) lenses to line up directly with the eyepieces. The result is a slim, streamlined shape in which the lenses and prisms that magnify and correct the image are in a straight line. -
Page 3: Focusing Your Binoculars
Focusing your binoculars: Carson 3D binoculars have a center focus wheel and an independent right diopter eyepiece to account for small differences in the strength of each eye. Please follow the steps below to focus properly: 1. Adjust the interpupillary distance. - Page 4 All Carson 3D binoculars are nitrogen purged and o-ring sealed to protect your binocular from water damage. They are designed to protect against accidental splashing, rain or even full submersion in up to 1 meter of water for up to 5 minutes.
-
Page 5: Attaching The Neck Strap
As light travels through a roof prism binocular, it becomes slightly out of phase. This affects the color balance and fidelity. Your 3D binoculars are phase coated to correct this problem, forcing the light back into phase and therefore resulting in more accurate color reproduction. Attaching the Neck Strap All 3D binoculars come with both a neck strap and a shoulder harness. - Page 6 Attaching the Shoulder Harness To attach the shoulder harness: 1. Remove the security buttons from the quick release hooks on your binocular harness. 2. Slide the security button loop upward through the strap clips on each side of your binocular. 3.
- Page 7 Using the BinoArmor Deluxe binocular wrap Your 3D binocular features a BinoArmor Deluxe protective binocular wrap. This wrap is designed to protect your binocular from damage, while also keeping the lenses safe from scratching and exposure to dust and debris. To use the protective wrap: 1.
- Page 8 Use of a Tripod Adapter All Carson 3D binoculars are compatible with most standard binocular tripod adapters. To attach a tripod adapter to your binoculars: 1. Twist the tripod adapter cap (located at the hinge in between the binocular barrels) counterclockwise and remove it.
-
Page 9: Instructions For Care
Use of a coarse cloth or unnecessary rubbing may scratch the lens surface and eventually cause permanent damage. 3. For a more thorough cleaning, use a Carson C6® lens cleaning product. Never attempt to clean your binoculars internally or try to take them apart. - Page 10 CARSON LIFETIME LIMITED WARRANTY This Carson product is warranted to be free from defects in material and workmanship. Carson will, at its option and without charge, either repair any part or assembly of parts found to be defective in material or workmanship, or replace this Carson product with a Carson product of comparable value and condition, subject to the limitations and exclusions noted herein.
-
Page 11: Warranty Procedure
Print the RA number prominently on the top of the package. Prepay shipping. Insure the package. Send it to Carson Warranty Service, 2070 5th Avenue, Ronkonkoma,NY 11779, together with a check in the amount of $15.00 to cover the cost of handling. - Page 12 Carson Optical • 2070 5th Avenue, Ronkonkoma, New York 11779 • U.S.A. ©2016 Carson Optical...
