Cardo Systems S-800 User Manual

Cardo Systems S-800 User Manual

Cardo systems s-800: user guide
Hide thumbs Also See for S-800:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Manual
C A R D O S Y S T E M S , I N C .
Cardo
User Guide
Gebrauchsanleitung
Guide d'Utilisation
Guida di Avvio
Guia de usario
When Technology Meets Design

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cardo Systems S-800

Summary of Contents for Cardo Systems S-800

  • Page 1 C A R D O S Y S T E M S , I N C . Cardo User Guide Gebrauchsanleitung Guide d’Utilisation Guida di Avvio Guia de usario When Technology Meets Design...
  • Page 2 Congratulations and thank you for choosing the Cardo S-800 Bluetooth headset. This User Guide will help you learn about the ® Cardo S-800’s many features, allowing you to make the best use of english english your headset. CArdo S-800 overview...

  • Page 3: Getting Started

    GettinG StArted To use your Cardo S-800 (“the headset”), please follow these initial steps: • Charge your headset • Pair your headset with a Bluetooth -enabled mobile phone. ® 1. ChArGinG yoUr heAdSet The headset comes with a built-in rechargeable battery. Prior to using the headset, make sure to charge the headset for at least 4 hours.
  • Page 4 Bluetooth menu and may be referred to as “discover” or “add” a device. 4. After a few seconds, the phone will list the “Cardo S-800” as a discovered device. Select it from the list and press “oK” or “yes”.

  • Page 5: Wearing Your Headset

    Paired Devices. 3. weArinG yoUr heAdSet the S-800 headset can be worn on either your left or right ear. There are two ways in which you can wear the S-800 headset. 1. without the earloop: Gently insert the headset without an earloop into your ear, and it will hold itself in place securely.
  • Page 6 Mute the microphone During a call, tap the MFW inwards to turn on/off mute. * note: wait until you hear the incoming call on the headset (not only on the phone) 5. USinG yoUr heAdSet – AdvAnCed FUnCtionS 1. redial the last dialed number During Standby, press the MFW inwards to redial the last dialed number.
  • Page 7 CTRL Button. 6. hot dial Function The S-800 allows you to call any of three different phone numbers at the press of a button. In order to use the Hot Dial function, you must first configure your mobile phone’s Speed dial settings.
  • Page 8 • The headset will start buzzing. 10. Call back the last incoming caller (Callback Function) Full charge The S-800 allows you to place a call to the phone number of the Medium charge last incoming, missed or rejected call. Weak charge...
  • Page 9 3. The last incoming caller had a blocked or restricted number. note: This feature is not supported by some mobile phones. 11. Auto-Answer Function The S-800 allows you to automatically answer all incoming calls using the Auto-Answer function. Please note that once this feature is activated you are subject to unintended eavesdropping. Use of ...
  • Page 10 ‘-’ sign on the headset decreases the volume one step at a time. If you wear the headset on your left ear, the S-800 allows you to...
  • Page 11 The headset will revert to its default right ear configuration once it is turned off. In order to regularly use the headset in left ear configuration, always turn on the headset using the CTRL + Power Button procedure above.

  • Page 12: Status Lights

    During Standby mode, move the MFW down and hold Led Status indicator for at least four seconds. Changing the wheel Turn on the headset by pressing and holding the CTRL But- - orientation ton and the Power Button simultaneously for 4 seconds. 6. StAtUS LiGhtS Missed Call indicator Whenever a call is missed or rejected, the red and blue Status...

  • Page 13: Audio Tones

    Standby mode With the exception of the actions described in the following table, all During a call actions are followed by a single tone to confirm that the headset has  Missed call Low battery accepted the action. A double tone means that the action has failed.
  • Page 14 This equipment generates and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. Your Cardo S-800...
  • Page 15 FCC. This means that your headset can communicate only over a certain distance subject on the location of the cell phone, base unit and headset, your vehicle,  the  construction  and  layout  of  your  home  or  office.  Weather  conditions  can  also affect performance.
  • Page 16 Copyright © 2007 The Cardo S-800™ The Bluetooth ® is developed and word mark and manufactured by logos are owned Cardo Systems, Inc. by the Bluetooth All rights reserved. SIG, Inc.
