YORK ® STACK FAN
This Installation Manual is provided as a guide for the installation of fans manufactured by YORK
Stack Fan. It is the responsibility of the purchaser to provide qualified personnel experienced in the
installation, operation, and maintenance of air moving equipment. Instructions given in this manual
are general in nature and apply to a variety of models manufactured by YORK
Manual completely before installing the fan. Additional product and engineering information is
available at www.York.com. Always follow good safety practices when installing, maintaining and
operating air moving equipment.
If fans are located less than 7 feet
above the floor, guarding is required in
accordance with OSHA (Occupational
Safety and Health Act) requirements.
Disconnect power before servicing or
installing.
This fan should be assembled and installed
by a qualified technician.

RECEIVING AND HANDLING

All YORK products are carefully constructed and inspected before shipment to insure the highest
®
standards of quality and performance. Compare all components with the bill of lading or packing list
to verify that the proper unit was received. Check each unit for any damage that may have occurred
in transit. Any damage should be reported immediately to the carrier and the necessary damage
report filed.
Handling of all air moving equipment should be conducted by trained personnel and be consistent with
safe handling practices. Verify the lift capacity and operating condition of handling equipment. Maintain
handling equipment to avoid serious personal injury.
Units shipped completely assembled may be lifted with slings and spreader bars. Lift the fan in a
fashion that protects the fan and fan coating from damage. Never lift a fan by the inlet or discharge
flange, shafting or drives, impeller, motor, motor base, or in any other manner that may bend or
distort parts.
. Read this Installation
®
Maximum Fan Weight
Specifications
Max. Total
Fan Size
Weight (lbs.)
105 240
122 270
135 300
150 340
165 490
182 476
200 528
222 815
245 1263
®
