Installation (Continued)
FAN SPACING
Location and Placement of Plenum Fans in Air Handlers
Center the fan inlets in both the horizontal and vertical planes.
A
• For inlet clearance, see
A minimum of one fan impeller diameter clearance is
recommended.
.
Recommended Inlet Spacing
A
Minimum of one
Impeller diameter
YORK
®
STACK FAN
9
