MOD.SOM8
Circuit
No.
board
11 2a
12 2b
13 1a
14 1b
15 5b
16 5a
17 6b
18 6a
19 7b
20 7a
21 8b
22 8a
EN
Explanation
Relay 2: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 2: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 1: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 1: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 5: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 5: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 6: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 6: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 7: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 7: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 8: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
Relay 8: Potential-free contact (NC treated as NO in
software); activated depending on authorisations.
7. Connections
