Canon PIXMA iP2000 Series Start Here

Canon pixma ip2000: setup instruction.
Hide thumbs


Advertisement

1
Unpack the Printer
1
Carefully remove all items from the box.
PIXMA iP2000
Photo Printer
Print Head
Power Cord
Ink Tanks
BCI-24 Black
BCI-24 Color
Documentation
and Software Kit
2
Prepare the Printer
1
Remove all shipping tape from the printer.
Shipping Tape
Open the front sheet feeder and the front cover.
2
Remove the shipping tape and packing
material from the print head holder.
Packing Material
Print Head Holder
Shipping Tape
3
Write down the serial number located
to the right of the print head holder.
You will need this to register the product.
Serial Number

Start Here

Easy Setup Instructions
3
Install the Print Head
1
Remove the print head from its package.
Tear at notch to open
2
Remove the orange protective cap.
NOTE: Do not touch the electrical contacts
or print head nozzles.
Print Head Nozzles
Electrical
contacts
3
Raise the gray lock lever on the printer.
IMPORTANT: Ensure that the gray lock
lever is raised into the notches located
above the print head holder before
proceeding or the print head may not
install correctly.
4
Slide the print head into the holder until
it is securely seated.
Do not press it down
Do not press it down
5
Lower the lever until it clicks into place.
Click
4
Install the Ink Tanks
1
Remove the black ink tank (BCI-24 Black)
from its package and pull off the orange
protective cap.
NOTE: To avoid spilling ink, do not touch
the bottom of the tank once you have
removed the protective cap.
Protective Cap
2
Insert the black ink tank (BCI-24 Black)
into the slot on the right. Then press in
until the ink tank clicks into place.
IMPORTANT: For correct printer
operation, make sure ink tanks
are secure in slots.
Click
3
Repeat the procedure for the color ink
tank (BCI-24 Color), inserting it into the
remaining slot.
4
Close the front cover.
Open the paper support and pull out the
5
output tray.
Paper Support
Series
Photo Printer
5
Connect the Printer
And Load Paper
1
Plug the power cord into the back of the
printer and connect the other end to a
power outlet.
IMPORTANT: BE SURE THE PRINTER
IS OFF, or the computer will attempt
to install the printer driver before
the printer is ready.
2
Connect one end of a USB cable to the
computer, the other to the printer.
USB Port
USB Cable
3
Pinch the paper guide and slide it to the
left. Load a sheet of blank paper in the
paper support. Slide the guide toward the
left edge of the paper.
Paper Guide
Continue with Step 6
on side two.
