- Page 1 Installation, Operation, and Maintenance manual EOP1 Operator Panel...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Introduction and Safety........................2 Introduction..........................2 Safety terminology and symbols....................2 Safety.............................3 Spare parts........................... 3 Disposal of packaging and product..................3 Warranty............................3 Transportation and Storage......................4 Inspect the delivery........................4 Inspect the package........................ 4 Inspect the unit........................4 Storage guidelines........................ -
Page 4: Introduction And Safety
Introduction and Safety Introduction and Safety Introduction Purpose of this manual The purpose of this manual is to provide necessary information for: • Installation • Operation • Maintenance CAUTION: Read this manual carefully before installing and using the product. Improper use of the product can cause personal injury and damage to property, and may void the warranty. -
Page 5: Safety
This includes any modification to the equipment or use of parts not provided by Xylem. If there is a question regarding the intended use of the equipment, please contact a Xylem representative before proceeding. -
Page 6: Transportation And Storage
Transportation and Storage Transportation and Storage Inspect the delivery Inspect the package 1. Inspect the package for damaged or missing items upon delivery. 2. Note any damaged or missing items on the receipt and freight bill. 3. File a claim with the shipping company if anything is out of order. If the product has been picked up at a distributor, make a claim directly to the distributor. -
Page 7: Product Description
Product Description Product Description Operator panel design Description The operator panel is a remote keypad and display. Dimensions The figure illustrates the dimensions of the product and of the cut-out area. 110 mm (4.3 in) 90 mm (3.5 in) 81 mm (3.2 in) 102 mm (4.0 in) 18 mm (0.7 in) Electrical requirements... -
Page 8: Installation
Installation Installation Precautions Before starting work, make sure that the safety instructions in the chapter Introduction and Safety (page 2) have been read and understood. DANGER: Electrical Hazard Before starting work on the unit, make sure that the unit and the control panel are isolated from the power supply and cannot be energized. -
Page 9: Select The Data Cable
Installation Not used Not used RS485- Optibus RS485+ Optibus +24 V, power supply for the operator panel RS485- Modbus RTU RS485+ Modbus RTU Select the data cable Incorrect cable connection can damage the product. Do NOT use an RJ22 cable. Select one of the following: •... -
Page 10: System Setup And Operation
System Setup and Operation System Setup and Operation System setup Description The drive provides the +24 V power supply to the operator panel via the RJ45 connection. If the drive is not used for power supply, then external power supply is possible. When the connection has been set up, the system is ready to operate. -
Page 11: Display And Buttons
System Setup and Operation Operator panel Drive Cable splitter Figure 3: Two operator panels with one drive Operator panel Drive Cable splitter Figure 4: Two operator panels with up to 63 drives Display and buttons Symbol Name Description The button is used to start the drive EOP1 Operator Panel Installation, Operation, and Maintenance manual... -
Page 12: Set Up The Communication Address Manually
System Setup and Operation Symbol Name Description Navigate The button is used to enter/exit (2 seconds) the menu and to confirm selection/change (< 2 seconds). The button is used to increase a value or selection in the submenu. The button is used to reset a tripped drive and to stop the drive in manual mode. -
Page 13: Change The Display Language
System Setup and Operation Change the display language 1. Press the on and up buttons at the same time. 2. Select the requested language by use of the up or down buttons. 3. Press the navigate button to select and activate the requested language. Display messages Drive messages and trip codes Any information displayed that is not related to the operator panel refers to the drive... -
Page 14: Troubleshooting
Troubleshooting Troubleshooting Error messages and remedies Message Description Remedy Select Drive Address xx The operator panel fails to • Check that the cable is correctly connected. communicate with the specified • Check that the drive with address xx is in the network. If xx is drive address in the network. - Page 16 For more information on how Xylem can help you, go to xyleminc.com Refer to www.xylemwatersolutions.com/contacts/ for contact details of your local sales and service representative.
