Page 1
ART. 35/09175-00 PAGINA 1 DI 4 Descrizione delle parti: tasselli e viti forniti. Premere il pulsante per trasmettere il segnale di Learn/test e 4. Allineate il magnete al sensore; avvitate il magnete (o utlizzate entrare in modalità test per 3 minuti. La spia LED si accenderà se un movimento viene rilevato in modalità...
Page 2
ART. 35/09175-00 PAGINA 2 DI 4 Funzionamento Attivazione Dopo l’attivazione il sensore si attiva nelle seguenti condizioni: 1. Quando la porta si apre e il magnete si allontana dal corpo principale e si attiva l'interruttore Reed all'interno del rivelatore. 2. Quando un sensore normalmente chiuso (N.C.) collegato al é...
Page 3
ART. 35/09175-00 PAGINA 3 DI 4 Screw the sensor onto the wall or door/window frame with the Parts Description: screws and plugs provided. for 3 minutes. The LED will light up whenever the Detector is activated under Test mode. no more than 15 mm. Frame Connect the terminal to any Normal Close (N.C) device Door/Window...
Page 4
ART. 35/09175-00 PAGINA 4 DI 4 Operation Activation following conditions: Terminal 1 is activated (opened). Terminal 2 is pulled down or retracted for set distance. Please refer to Jumper Switch Setting section below for setting roller shutter cord activation distance. This jumper is used to put the Door Contact into Tamper Switch permanent Test Mode.
