User Manual
Recorder
KRN50 Series
AEP-K-0104-AA
Thank you for purchasing an Autonics product.
This user manual contains information about the product and its proper use,
and should be kept in a place where it will be easy to access.
www.autonics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KRN50 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Autonics KRN50 Series

Summary of Contents for Autonics KRN50 Series

  • Page 1 User Manual Recorder KRN50 Series AEP-K-0104-AA Thank you for purchasing an Autonics product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access. www.autonics.com...

  • Page 2: Preface

    Preface Preface Thank you for purchasing autonics product. Please familiarize yourself with the information contained in the Safety Precautions section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.

  • Page 3: User Manual Guide

    The manual's content may vary depending on changes to the product's software and other  unforeseen developments within autonics, and is subject to change without prior notice. Upgrade notice is provided through out homepage. We contrived to describe this manual more easily and correctly. However, if there are any ...

  • Page 4: User Manual Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature's use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.

  • Page 5: Safety Precautions

    Failure to follow this instruction may result in fire or electric shock. Since Lithium battery is embedded in the product, do not disassemble or burn the unit.  Failure to follow this instruction may result in fire. © Copyright Reserved Autonics Co., Ltd.
  • Page 6 Failure to follow this instruction may result in fire, relay broken, contact melt, insulation failure or contact failure. ※The above specifications are subject to change and some models may be discontinued without notice. ※Be sure to follow cautions written in the instruction manual and the technical descriptions (catalog, homepage). © Copyright Reserved Autonics Co., Ltd.

  • Page 7: Table Of Contents

    Recording setup ..................43 8.2.4 Display information function ............... 59 Communication ..................63 ModBus address Map ..................65 DAQMaster ....................69 10.1 Overview ......................69 10.2 Features ......................70 10.3 Dedicated function for KRN50 ................71 © Copyright Reserved Autonics Co., Ltd.

  • Page 8: Overview

    RS485 communication and dedicated communication port to set or monitor parameters in  real-time by PC/PLC Multi-input with high accuracy 0.2% level (TC, RTD, Voltage, Current(shunt))  Various option I/O function  Small size (W96×H96×L100mm), light weight  © Copyright Reserved Autonics Co., Ltd.

  • Page 9: Component And Sold Separately

    1 Overview Component and sold separately 1.2.1 Components Before using KRN50, check the component. If any component is left out or damaged, contact our company or seller. © Copyright Reserved Autonics Co., Ltd.

  • Page 10: Sold Separately

    ※1. When selecting this for 2 CH model, 2EA alarm outputs for CH1 are available. In other words, you cannot set 1EA for CH1 and 1EA for CH2. ※2. It is selectable only for 2 CH model. © Copyright Reserved Autonics Co., Ltd.

  • Page 11: Part Descriptions

    Paper feeding key (STOP), printing parameter setting information key (RUN) PC loader port: It is a PC loader port for serial communication to set or monitor ⑮ parameters by PC. Used to connect SCM-US (USB to Serial converter, sold separately). © Copyright Reserved Autonics Co., Ltd.

  • Page 12: Specifications

    X, Y, Z directions for 1 hour Mechanical: Over 5,000,000 operations, Electrical: Over 100,000 Relay life cycle operations Insulation resistance Over 100 MΩ (at 500 VDC megger) Noise resistance Square shaped noise by noise simulator (pulse width 1 ㎲)±2 kV © Copyright Reserved Autonics Co., Ltd.
  • Page 13 ※1. Exception range for measurement accuracy by each sensor J: -200≤T≤-100 ±2.7℃ R, S, C, G: 0≤T≤100 ±5.2℃ B: below 400℃, there is no accuracy standard U, T: -200≤T≤-100 ±3.5℃, -100≤T≤400 ±2.5℃ ※Environment resistance is rated at no freezing or condensation. © Copyright Reserved Autonics Co., Ltd.

  • Page 14: Input Type And Range

    -1.000 to 1.000V Analog (display range depends on the -1.00 to 10.00V decimal point position.) 0 to 20mA 0-20 Current 4 to 20mA 4-20 ※1. C(TT): Same as exisitng W5(TT). ※2. G(TT): Same as exisitng W(TT). © Copyright Reserved Autonics Co., Ltd.

  • Page 15: Dimensions

    3 Dimensions Dimensions (1) KRN50 (2) Panel cut-out © Copyright Reserved Autonics Co., Ltd.

  • Page 16: Connections

    ※Dot line terminals are for the option model. (CH2 input terminal, alarm output terminal, communication output terminal) ※The DC power model does not have F.G. ※When using 2-wire RTD, short B and b terminals. ※For current input, connect external 50Ω B class(0.1%) high-accuracy resistor. © Copyright Reserved Autonics Co., Ltd.

  • Page 17: Installation

    You should warm-up this unit over 30 min. to acquire accurate data before using it. At the place where temperature and humidity is fluctuated excessively, recording paper  color may be changed. © Copyright Reserved Autonics Co., Ltd.

  • Page 18: Installation

    When RTD lead wire need to extend, please use it with small resistance value and be equal for resistive value to 3 lead wires. Connect wiring after power off in order to prevent from an electric shock. Check input specifications in order to prevent from any damages. © Copyright Reserved Autonics Co., Ltd.

  • Page 19: Functions

    Feeding function and recording run/stop function are able to be used by front key or communication at the status of recording stop. Also recording reservation function is able to start or stop recording at the suitable time period user wants. © Copyright Reserved Autonics Co., Ltd.

  • Page 20: General Operation And Parameter Setting Menu

    Set relevant parameter (input type, alarm, record speed) according to input sensor. Record and display measuring value  If necessary, press key for recording Run / Stop. Also mode is able to be changed by measuring value display mode relevant key. © Copyright Reserved Autonics Co., Ltd.

  • Page 21: Setting Keys

    If moving from the lower setting menu to the next step menu, please use key. If entering into the setting category at the lower setting menu, the cursor flashes on the setting category. Then, user is able to change the setting category by means of key. © Copyright Reserved Autonics Co., Ltd.
  • Page 22 (3) Change the setting category If pressing key after changing the setting category by key, it is saved and moved to the setting menu. © Copyright Reserved Autonics Co., Ltd.
  • Page 23 Especially the fourth position of number is able to change to either number or sign. If pressing key at the status of wrong value and save it when changing setting value, it indicates Error code as above. © Copyright Reserved Autonics Co., Ltd.

  • Page 24: Parameter Groups

    Parameter groups © Copyright Reserved Autonics Co., Ltd.

  • Page 25: Recording

    Then if the cursor flashes at the position for change, moving the cursor by key and setting the value by key. After then if pressing key, setting value is saved. Time setting method is same as 3rd. © Copyright Reserved Autonics Co., Ltd.

  • Page 26: Explanation For Input Function And Setup

    This recorder has multi input type and user voluntarily is able to select each input type for CH1 and CH2 separately. (Ex: set as CH1: DPT1, CH2: TC-K1) Set range: temperature range of each input type and sensor  Factory default: TC-K1 (unit: - )  © Copyright Reserved Autonics Co., Ltd.
  • Page 27 For analog input type, this parameter is not displayed. Set range: Graph low-limit scale value[ CH Lo Graph ] + F.S. 5% to Max. range by  each sensor input type Factory default: 1350(unit: Digit)  © Copyright Reserved Autonics Co., Ltd.
  • Page 28 This function is to assign and limit the actual using high limit input value within input range. Set range: Low-limit input value[CH□ Lo Range]+ F.S 10% to max. input range  Factory default: Max. input range (unit: -)  © Copyright Reserved Autonics Co., Ltd.
  • Page 29 : -100, high limit scale value : 100. When input value is 0V, PV displays –100. If input value is 5V, PV displays 100.) Set range: Within F.S. range(-1999 to 9999/-199.9 to 999.9/-19.99 to 99.99/-1.999 to  9.999) Factory default: 100.0 (unit: Digit)  © Copyright Reserved Autonics Co., Ltd.
  • Page 30 [CH□ DP Unit] is not indicated. us0 to us9 is used to apply user font unit with 16X16 size(32byte) font. User font unit is written through RS485 communication. (Communication program, DAQMaster, has user unit setup and download function.) © Copyright Reserved Autonics Co., Ltd.
  • Page 31 In case of TC or RTD, if temp. unit conversion ℃ ↔ ℉ or input type change, correction value will be initialized to 0. If actual temperature is 80℃, but display indicates 78℃, input correction value [CH□ Input Bias] should be set '2' for indicating 80℃. © Copyright Reserved Autonics Co., Ltd.
  • Page 32 A ↔ B ↔ C ↔ D ↔ E ↔ F ↔ G ↔ H ↔ I ↔ J ↔ K ↔ L ↔ M ↔ N ↔ O ↔ P ↔ Q ↔ R ↔ S ↔ T ↔ U ↔ V ↔ W ↔ X ↔ Y ↔ Z ↔ = Factory default: CH-□ (unit: -)  © Copyright Reserved Autonics Co., Ltd.

  • Page 33: Alarm Function Setup

    During recording, when alarm operation, current time, PV, alarm information (AL HI =↑, AL LO =↓, SBA = B, P.END = P) print to chart paper. HI, LO of AL1, AL2 in printed AL1(↑↓) AL2( ) for classify AL1 and AL2 separately. © Copyright Reserved Autonics Co., Ltd.
  • Page 34 If it is an alarm condition, it operates both alarm latch and standby sequence. When power is ON and it is an alarm condition, it is La+St ※ 3 standby ignored. sequence From the second alarm condition, alarm latch operates. © Copyright Reserved Autonics Co., Ltd.
  • Page 35 Set range: Within using/display range by input type  Factory default: [CH□ AL□ Lo]: Low-limit scale value  [CH□ AL□ Hi]: High-limit scale value (unit: ℃/℉)  © Copyright Reserved Autonics Co., Ltd.
  • Page 36 As alarm output hysteresis, 'hysteresis' sets the interval between ON and OFF of alarm output. Set range: 001 to 999 (decimal point is placed same as input decimal point)  Factory default: 001 (unit: Digit)  (8) High-limit alarm [PV.Hi] © Copyright Reserved Autonics Co., Ltd.
  • Page 37 Alarm option : None / AL2 high-limit : 600℃, Alarm option : None. For record mode, Record mode : graph mode, Recording speed : 960mm/h, Memo period : 1min. If setup is as above, recording will be as follows. © Copyright Reserved Autonics Co., Ltd.
  • Page 38 Set CH1 Lo Graph:0, CH1 Hi Graph:1000 at the lower menu of input type setup. Alarm setup After moving to the upper menu from the lower menu of input type setup and selecting alarm setup, press key to entering into the lower menu. © Copyright Reserved Autonics Co., Ltd.
  • Page 39 1: 'Record off'. For alarm function of channel 2, AL1 High-limit: 70.0ppm, Alarm option: None / AL2 Low- limit: 20.0ppm, Alarm option: None. For record mode, Record mode: graph mode, Recording speed: 960mm/h, © Copyright Reserved Autonics Co., Ltd.
  • Page 40 '4 to 20mA' and set CH2 Dp unit to 'ppm' and press key to get out of this menu. Input High/Low scale setup Set CH2 Lo Scale:000.0, CH2 Hi Scale:100.0 at the lower menu of input type setup. © Copyright Reserved Autonics Co., Ltd.
  • Page 41 After setting CH2 AL1 type : PV.Hi and saving it by pressing key, set AL1 Opt : None, AL1 High : 20.0. After setting CH2 AL2 type : PV.Lo and saving it by pressing key, set AL2 Opt : None, AL2 Low : 70.0. © Copyright Reserved Autonics Co., Ltd.

  • Page 42: Recording Setup

    3 sec. The latest record is placed behind of paper cutter at STOP state therefore cut the chart paper after manual paper feeding in order to check the latest record. © Copyright Reserved Autonics Co., Ltd.
  • Page 43 8 Recording © Copyright Reserved Autonics Co., Ltd.
  • Page 44 ᆞ Factory default: 30 (unit: min)(O: enable to set, X: disable to set) Record Digital memo period speed None 30 sec. 1 min. 5 min. 10 min. 15 min. 30 min. (mm/h) © Copyright Reserved Autonics Co., Ltd.
  • Page 45 Regarding saved data by record backup, if record mode setup function (Rec mode, Rec period, Alarm speed) is changed, previous record backup data is removed(Backup data time initialization) and start saving the data from the current modified time. Therefore please be careful for setup. © Copyright Reserved Autonics Co., Ltd.
  • Page 46 This recorder is able to record in Korean and English and current date, high/low-limit scale value and parameter list are recorded by setting language. ᆞ Set range: Korea / English ᆞ Factory default: Korea (unit: -) © Copyright Reserved Autonics Co., Ltd.
  • Page 47 (12) Recording start time (Start Time) Set the recording start time. ᆞ Set range: 00:00 to 23:59 (13) Recording stop time (Stop Time) Set the recording stop time ᆞ Set range: 00:00 to 23:59 © Copyright Reserved Autonics Co., Ltd.
  • Page 48 Korean: 현재시간 2009 년 03 월 19 일 12 시 30 분 00 초 English: DATE 03-19-2009 12:30:00 If this mode sets 'Off', no function operation. ᆞ Set range: Off / Run ᆞ Factory default: Off (unit: -) © Copyright Reserved Autonics Co., Ltd.
  • Page 49 (17) Printing the setting list when record start [RUN On State] This function is to set printing the setting list when record start simultaneously. It is divided into List and Off. ᆞ Set range: List / Off ᆞ Factory default: Off(unit: -) © Copyright Reserved Autonics Co., Ltd.
  • Page 50 If alarm mode sets to paper end function, P.ED lamp will lighten and alarm output will be on simultaneously. When changing chart paper, if sensing chart paper, the unrecorded data of since the time of exhausting chart paper is able to be recorded and printed. © Copyright Reserved Autonics Co., Ltd.
  • Page 51 If chart paper is exhausted during RUN state, it will be changed to STOP state automatically. When user changes chart paper, message for re-recording function about unrecorded data is indicated on display and user is able to select the recording range. © Copyright Reserved Autonics Co., Ltd.
  • Page 52 8 Recording © Copyright Reserved Autonics Co., Ltd.
  • Page 53 Record mode setup: When changing Rec mode, Rec period or Time, Alarm speed setting. Input type setup: CH1 or 2 Record, CH1 or 2 In type, When analog input, CH1 or when changing 2 Lo,Hi scale setting Date/ Time setup: When changing date or time setting © Copyright Reserved Autonics Co., Ltd.
  • Page 54 = Approx. 25 hours 1 min. 60 sec. Approx. 8 days Approx. 12 days 60 min. 3600 sec. Approx. 480 days Approx. 755 days 99 min. 59 sec. 6000 sec. Approx. 800 days Approx. 1259 days © Copyright Reserved Autonics Co., Ltd.
  • Page 55 8 Recording © Copyright Reserved Autonics Co., Ltd.
  • Page 56 PV again. Record parameter: Tag name, Input, Unit, Range, Scale, Alarm mode, Alarm setting value, Communication function When starting record, parameter setting information is able to be recorded according to printing the setting list parameter. © Copyright Reserved Autonics Co., Ltd.
  • Page 57 8 Recording © Copyright Reserved Autonics Co., Ltd.

  • Page 58: Display Information Function

    + F.S 10% to Max. input range for each sensor, - 1350℃ to -122.5℃. Then if setting –123℃, “Hi < Lo !!”error message will be indicated.) If pressing key, it will be cancelled and returned to previous setting state. © Copyright Reserved Autonics Co., Ltd.
  • Page 59 User is able to select one channel manually by means of key. Display mode conversion method is as follows. If applying power, it will be indicated by mode setup (2CH or 1CH) on display mode parameter. © Copyright Reserved Autonics Co., Ltd.
  • Page 60 Even though selecting [Loc1],[Loc2],[Loc3], [Setting Lock] parameters will be always indicated and it will be changed. ᆞ Factory default: Off (unit: -) Even though setting parameter lock function up, parameter will be initialized by parameter initializing function. © Copyright Reserved Autonics Co., Ltd.
  • Page 61 If pressing key for 5 sec. simultaneously, it will operate. ᆞ Set range: Yes / No ᆞ Factory default: No (unit: -) © Copyright Reserved Autonics Co., Ltd.

  • Page 62: Communication

    KRN50 recorder is able to communicate through back terminal or front phone jack. (In case of back terminal connection. Front and back communication functions are not used simultaneously. (use autonics SCM-US (sold separately) for communicating by front communication port.) Interface...
  • Page 63 9 Communication It is recommended to use Autonics communiation converter SCM-38I(RS232C to RS485 converter), SCM-US48I(USB to RS485 converter). It is recommended to use DAQMaster program for monitoring. You can download DAQMaster program and communication manual at our website (www.autonics.com). For non-coummunication function models (KRN50-1000-00, KRN50-1002-00,KRN50-2000-00, KRN50-2002 -00, KRN50-2004-00), communication is available by front phone jack but there are no communication setup function.

  • Page 64: Modbus Address Map

    ※ 1 40072 Start record Minute hh.mm 40073 End record Hour 00:00 to 23:59 00:01 Stop Time ※ 1 40074 End record Minute ※1. This parameters are displayed only when reservation ON/OFF is ‘On’. © Copyright Reserved Autonics Co., Ltd.
  • Page 65 CH-2 CH2 Tag Name ※ 3 40333 ※1. Displays only when input type(In Type) is temperature sensor. ※2. Displays only when input type(In Type) is analog (voltage/current). ※3. Displays only for 2 channels model. © Copyright Reserved Autonics Co., Ltd.
  • Page 66 Backlight Temp 1: Always (9) Others Factory Addr Description Set range default Record run/stop (Recording RUN/STOP) 0:STOP 1: RUN SV initialization(Parameter initialization) 0:OFF 1:ON ※1 Memo (Memo) 0:OFF 1:ON Feed (Paper Feed) 0:STOP 1:FEED © Copyright Reserved Autonics Co., Ltd.
  • Page 67 384 x 80size ※18..2 ※1. When initializing SV, SVs related communication are also initialized. ※2. Unit and Unit group values are used at user unit download function of the integrated device management program (DAQMaster). © Copyright Reserved Autonics Co., Ltd.

  • Page 68: Daqmaster

    DAQMaster 10.1 Overview DAQMaster is a comprehensive device management program that can be used with Autonics thermometers, panel meters, pulse meters, counters, and autonics recorders, and indicators, etc. DAQMaster provides GUI control for easy and convenient management of parameters and multiple device data monitoring.

  • Page 69: Features

    Supports Korean, English, Japanese, Simplified Chinese. To add a different language, modify the files in the Lang folder, rename, and save. Script Support  Uses the Lua Script language and deals with different I/O processes for individual devices. © Copyright Reserved Autonics Co., Ltd.

  • Page 70: Dedicated Function For Krn50

    To get the recorded data, click ‘...’ button located on the right of Record Backup in the Property window. To read memory information, the device status must be Connected and not Run. There are also cases in which you cannot read from memory depending on KRN50 parameter setting. © Copyright Reserved Autonics Co., Ltd.
  • Page 71 You can also reset images back to the original status. This is also a self protocol, so cannot download images during Run. Download logo You can change the company logo image on contents that are printed on recording paper. Logo image should be 384 X 80 pixel of bitmap file. © Copyright Reserved Autonics Co., Ltd.
  • Page 72 10 DAQMaster Download Units There are 0-9 user units. The download procedure is: select a unit list → select a destination to save → double-click a unit image to add the image → download. © Copyright Reserved Autonics Co., Ltd.
  • Page 73 The boot image (logo image) appears on LCD upon initial power supply to KRN50. You can change booting logo image which displays when KRN50 is power ON. The image should be 128 X 32 pixel of bitmap file. © Copyright Reserved Autonics Co., Ltd.
  • Page 74 * Dimensions or specifications on this manual are subject to change and some models may be discontinued without notice.
