  • Page 1: Instruction Manual

    Mini Digital Video Cassette Digital Video Camcorder Instruction Manual PUB.DIE-193 English Introduction Mastering the Basics Using the Full Range of Features Editing Using a Memory Card Direct Printing Additional Information...

  • Page 2: Important Usage Instructions

    Important Usage Instructions WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

  • Page 3: Reference Guide

    • AV/C Camera Storage Subunit-WIA Driver (IEEE1394): Allows you to download/upload images to/from the computer and use the camcorder as a card reader/writer. Trademark Acknowledgements • Canon and Bubble Jet are registered trademarks of Canon Inc. • D is a trademark. • logo is a trademark.

  • Page 4: Table Of Contents

    Table of Contents Introduction Reference Guide ...3 Thank You for Choosing a Canon ...7 Introducing the MVX3i ...8 Components Guide ...9 Mastering the Basics Preparations Using a Household Power Source ...13 Attaching and Charging the Battery Pack ...14 Installing the Backup Battery ...17 Preparing the Camcorder ...18...
  • Page 5 Using the Zebra Pattern ...84 Backlight Compensation ...84 Setting the Shutter Speed ( Setting the Aperture ( Setting the White Balance ...88 Playback Magnifying the Image...90 Displaying the Data Code ...91 Photo Search/Date Search...93 Returning to a Pre-marked Position ...94 Editing Recording to a VCR or Digital Video Device ...95 Recording from Analog Video Devices (VCR, TV or Camcorder) ...97...

  • Page 6: Conventions Used In This Manual

    Conventions Used in This Manual Operating Modes Operating Mode CAMERA PLAY (VCR) CARD CAMERA CARD PLAY (VCR) Available functions depend upon the operating mode. It is indicated as follows: CAMERA : Function can be used in this mode. CAMERA : Function cannot be used in this mode. Other Symbols and References ❍...

  • Page 7: Thank You For Choosing A Canon

    Thank You for Choosing a Canon The Canon MVX3i provides a full range of options and functions. We recommend reading this manual thoroughly before you use the camcorder. It will help you to become more familiar with your camcorder, and learn how to operate it properly.

  • Page 8: Introducing The Mvx3I

    Stitch Assist mode can be merged into one panoramic scene with the supplied software. Direct Print You can print still images by connecting to a Canon printer with Direct Print function or to a PictBridge-compliant printer. USB Terminal Allows transfer of memory card data to a computer with built-in USB port.

  • Page 9: Components Guide

    Components Guide MVX3i – REC SEARCH button (p. 33) / (record review) button (p. 33) / (rewind) button (p. 35) / – CARD button (p. 124) (self-timer) button (p. 73) / REC PAUSE (LINE-IN) button (p. 97,98) CARD STILL/MOVIE button (p.
  • Page 10 Viewfinder (p. 18) PHOTO button (p. 56, 112) POWER indicator Start/stop button (p. 26, 122) POWER switch (p. 6) CAMERA PLAY(VCR) NETWORK* * The NETWORK mode is for use with DV Messenger (Windows XP users only). Press the small button below the POWER switch when switching to NETWORK ( Diopter adjustment lever (p.
  • Page 11 Assist lamp (White LED) (p. 63) USB terminal (p. 138) DV IN/OUT terminal (p. 96) S-video IN/OUT terminal (p. 39) DC IN terminal (p. 13) AV IN/OUT terminal (p. 3) MIC terminal (p. 75) CHARGE indicator (p. 14) Terminal cover Bottom view Tripod socket (p.
  • Page 12 WL-D81 Wireless Controller Zoom buttons (p. 28) MIX BALANCE button (p. 106) PHOTO button (p. 56, 112) SEARCH SELECT button (p. 93) 12bit AUDIO OUT button (p. 106) D. EFFECTS (Digital effects) button (p. 67) CARD STILL/MOVIE button (p. 125) Digital effects ON/OFF button (p.

  • Page 13: Using A Household Power Source

    Using a Household Power Source You can operate the camcorder from a household power source using the supplied power adapter. The power adapter converts current from a power outlet (100-240 V AC, 50/60 Hz) to the DC current used by the camcorder. 1.

  • Page 14: Attaching And Charging The Battery Pack

    Attaching and Charging the Battery Pack Charge the battery pack with the supplied power adapter before you use the camcorder for the first time and subsequently when the message “CHANGE THE BATTERY PACK” appears. 1. Turn the POWER switch to OFF. 2.

  • Page 15: Charging Time

    Charging, Recording and Playback Time Below times are approximate and vary according to the charging, recording or playback conditions. Charging Time Battery Pack BP-512 (Supplied) BP-511 (Optional) BP-522 (Optional) BP-535 (Optional) • Charge the battery pack in temperatures between 5º C and 40º C. •...
  • Page 16 How much power is left? The battery symbols indicate the charge status of the battery pack. When the battery pack is empty, “CHANGE THE BATTERY PACK” appears for 4 seconds and The battery charge indicators are not constant – they vary according to the condition under which battery pack and camcorder are used.

  • Page 17: Installing The Backup Battery

    Installing the Backup Battery The backup battery allows the camcorder to retain date, time and other camcorder settings while the power source is disconnected. Power the camcorder from a household power source or with a battery pack when replacing the backup battery to retain the setting.

  • Page 18: Preparing The Camcorder

    Preparing the Camcorder Adjusting the Viewfinder (Diopter Adjustment) 1. Turn on the camcorder and keep the LCD panel closed. 2. Extend the viewfinder and move it upward. 3. Adjust the diopter adjustment lever. Do not leave the viewfinder exposed to direct sunlight as it may melt (due to concentration of light by the lens).

  • Page 19: Attaching The Shoulder Strap

    Fastening the Grip Belt Hold the camcorder with your right hand and adjust the belt with your left. Adjust the grip belt so that you can reach the zoom lever and photo button with your index finger, and the start/stop button with your thumb.

  • Page 20: Loading A Cassette

    Loading a Cassette Use only video cassettes marked with the Loading and Unloading 1. Slide and hold the OPEN/EJECT switch and open the cassette compartment cover. The cassette compartment opens automatically. 2. Load/unload the cassette. • Load the cassette with the window facing the grip belt and the REC/SAVE tab facing upward.

  • Page 21: Protecting Tapes From Accidental Erasure

    Protecting Tapes from Accidental Erasure To protect your recordings from accidental erasure, slide the tab on the cassette to the left. (This switch position is usually labelled SAVE or ERASE OFF.) If you load a protected cassette in CAMERA mode, the message “THE TAPE IS SET FOR ERASURE PREVENTION”...

  • Page 22: Using The Wireless Controller

    Using the Wireless Controller You can operate the camcorder with the supplied wireless controller from a distance of up to 5 m. Point it at the camcorder’s remote sensor when you press the buttons. Following functions cannot be operated without the wireless controller: •...

  • Page 23: Setting The Time Zone, Date And Time

    Setting the Time Zone, Date and Time Set the time zone, date and time when you first start using your camcorder. Install the backup battery before you begin ( Setting the Time Zone/Daylight Saving Time CAMERA PLAY (VCR) SYSTEM 1. Press the MENU button to open the menu. 2.

  • Page 24: Setting The Date And Time

    14 15 16 17 18 19 20 21 22 23 Time zone LONDON PARIS CAIRO MOSCOW DUBAI KARACHI DACCA BANGKOK H. KONG (Hong Kong) TOKYO SYDNEY SOLOMON ❍ Once you have set time zone, date and time, you do not need to reset the clock each time you travel to another time zone.

  • Page 25: Displaying Date And Time During Recording

    2. Turn the selector dial to select [SYSTEM] and press the selector dial. 3. Turn the selector dial to select [D/TIME SET] and press the selector dial. The year display starts to flash. 4. Turn the selector dial to select the year, and press the selector dial. •...

  • Page 26: Recording Movies On A Tape

    Recording Movies on a Tape You can use the LCD screen or the viewfinder when recording. Adjust the angle of the LCD panel or viewfinder for comfortable recording. Before You Begin Recording Make a test recording first to check if the camcorder operates correctly. Before you make important recordings, clean the video heads ( Preparations Connect a power source.

  • Page 27: When You Have Finished Recording

    When You Have Finished Recording 1. Turn the POWER switch to OFF. 2. Close the LCD panel and return the viewfinder to its original position. 3. Replace the lens cap. 4. Unload the cassette. 5. Disconnect the power source. When recording outdoors or through a window, do not leave LCD screen, viewfinder or lens exposed to direct sunlight as it may cause damage.

  • Page 28: Zooming

    Zooming The camcorder’s zoom lens allows you to choose the best picture angle for your recordings. The camcorder automatically switches between optical zooming and digital zooming. Image resolution is slightly lower with the digital zoom. 10× Optical Zoom (Card: 9×) Move the zoom lever toward angle).
  • Page 29 ❍ Keep at least 1 m to the subject. At wide-angle, you can focus on a subject as close as 2 cm in CAMERA mode and 6 cm in CARD CAMERA mode. ❍ A zoom indicator appears for 4 seconds. It extends in light blue when the digital zoom is set to 40×, and extends further in dark blue when set to 200×.

  • Page 30: Using The Lcd Screen

    Using the LCD Screen 1. Push the OPEN button at the LCD panel and open the LCD panel. The LCD screen switches on and the viewfinder switches off. 2. Rotate the LCD panel and choose the angle of the screen. You can rotate the LCD panel so that the screen faces in the same direction as the lens 31), or push it flat against the camcorder with the screen facing outward.

  • Page 31: Adjusting The Brightness Of The Lcd Screen

    Adjusting the Brightness of the LCD Screen PLAY (VCR) CAMERA DISPLAY SET UP 1. Press the MENU button to open the menu. 2. Turn the selector dial to select [DISPLAY SET UP] and press the selector dial. 3. Turn the selector dial to select [BRIGHTNESS] and press the selector dial.
  • Page 32 CAMERA DISPLAY SET UP 1. Press the MENU button to open the menu. 2. Turn the selector dial to select [DISPLAY SET UP] and press the selector dial. 3. Turn the selector dial to select [LCD MIRROR] and press the selector dial. 4.

  • Page 33: Searching And Reviewing When Recording

    Searching and Reviewing when Recording REC SEARCH – button/ v (record review) button Record Review PLAY (VCR) CAMERA In record pause mode, this function allows you to review the last few seconds of your recording to check if it has been recorded properly. Press and release the c (record review) button.

  • Page 34: Tips For Making Better Videos

    Tips for Making Better Videos Holding the Camcorder For maximum stability, grip the camcorder in your right hand and keep your right elbow pressed against your body. If necessary, support the camcorder with your left hand. Be careful that your fingers do not touch the microphone or lens. For More Stability Lean against a wall Lie on your elbow...

  • Page 35: Playing Back A Tape

    4. Press the e/a button to begin playback. 5. Press the button to stop playback. ❍ If the playback picture is distorted, clean the video heads using a Canon Head Cleaning Cassette or a commercially available digital video head-cleaning cassette ( 160).

  • Page 36: Special Playback Modes

    Special Playback Modes Special playback modes (except of playback pause and fast/rewind playback) can only be operated with the wireless controller. e/a (Playback Pause) To pause playback, press the e/a button. Press the e/a button to resume playback. The camcorder goes into stop mode after 5 minutes in playback pause mode. 1 (Fast Forward Playback) / ` (Rewind Playback) Plays back the tape at 11.5 times normal speed (forward or reverse).

  • Page 37: Playing Back With The Built-In Speaker/Headphones

    Playing Back with the Built-in Speaker/Headphones Selector dial ❍ The built-in speaker does not sound when you use headphones. ❍ The built-in speaker is monaural. Use headphones for stereo sound. Adjusting the Volume CAMERA PLAY (VCR) Turn the selector dial up to increase the volume, and down to lower the volume.

  • Page 38: Playing Back On A Tv Screen

    Playing Back on a TV Screen You can connect the camcorder to a TV or VCR to play back your recordings on a TV screen. When you use the TV as a monitor during recording, keep the TV volume turned down as long as the camcorder’s audio terminals are connected.
  • Page 39 4. If connecting to a TV, set the input selector to VIDEO. If connecting to a VCR, set the input selector to LINE. The supplied PC-A10 SCART Adapter is for output only. For analog line-in recording or analog-digital conversion, please use a SCART Adapter with input capability (commercially available).
  • Page 40 TVs with Audio/Video Terminals Refer also to the TV or VCR instruction manual. 1. Turn off all devices before starting the connections. 2. Connect the STV-250N Stereo Video Cable to the camcorder’s AV terminal and the audio/video terminals on the TV/VCR. Connect the white plug to the white audio terminal L (left), the red plug to the red audio terminal R (right) and the yellow plug to the yellow video terminal VIDEO.

  • Page 41: Selecting The Audio Output Channel

    Selecting the Audio Output Channel You can select the output channels when playing back a tape with audio recorded on two channels. CAMERA PLAY (VCR) AUDIO SET UP 1. Press the MENU button to open the menu. 2. Turn the selector dial to select [AUDIO SET UP] and press the selector dial.

  • Page 42: Menus And Settings

    Menus and Settings Many of the camcorder’s advanced functions are selected from menus that appear on the screen. Selecting Menus and Settings 1. Set the camcorder to the correct operating mode. 2. Press the MENU button to open the menu. 3.
  • Page 43 Menu and Default Settings Default settings are shown in boldface. CAMERA Menu (CAM. MENU) PLAY (VCR) CAMERA Submenu Menu Item \CARD MIX MIX TYPE ANIMAT. TYPE MIX LEVEL CAMERA SET UP D. ZOOM IMAGE S. i* WHITE BAL. AF AST LAMP 16:9 PHOTO REC ZEBRA*...
  • Page 44 Submenu Menu Item SYSTEM CUSTOM KEY WL. REMOTE TALLY LAMP BEEP T.ZONE/DST D/TIME SET MY CAMERA S-UP SOUND SHTR SOUND OPER. SOUND SELF-T SOUND Setting Options OFF, IMAGE S., BLC, ZEBRA A1, A2, OFF B ON, OFF ON, OFF See list of time zones OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2...
  • Page 45 PLAY (VCR) Menu (VCR MENU) CAMERA PLAY (VCR) Submenu Menu Item VCR SET UP REC MODE AV \ DV OUT AUDIO SET UP OUTPUT CH AUDIO DUB. WIND SCREEN MIC ATT MIC LEVEL AUDIO MODE CARD SET UP SI QUALITY MOVIE SIZE FILE NOS.
  • Page 46 Submenu Menu Item MY CAMERA S-UP SOUND SHTR SOUND OPER. SOUND SELF-T SOUND Setting Options OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2...
  • Page 47 CARD CAMERA Menu (C. CAM. MENU) CAMERA PLAY (VCR) Submenu Menu Item CAMERA SET UP D.ZOOM IMAGE S. i* WHITE BAL. DRIVE MODE* AF AST LAMP FOCUS PRI. ZEBRA* BLC* CARD SET UP SI QUALITY SI SIZE MOVIE SIZE FILE NOS. AUDIO SET UP WIND SCREEN MIC ATT...
  • Page 48 Submenu Menu Item SYSTEM CUSTOM KEY WL. REMOTE TALLY LAMP BEEP T.ZONE/DST D/TIME SET MY CAMERA S-UP SOUND SHTR SOUND OPER. SOUND SELF-T SOUND Setting Options OFF, IMAGE S., BLC, ZEBRA, DRIVE MODE A1, A2, OFF B ON, OFF ON, OFF See list of time zones OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2...
  • Page 49 A1, A2, OFF A ON, OFF ON, OFF STANDARD, STORAGE See list of time zones NO IMAGE, CANON LOGO, MY IMAGE1, MY IMAGE2 OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2 OFF, DEFAULT, MY SOUND1, MY SOUND2...

  • Page 50: Changing The Remote Sensor Mode

    Changing the Remote Sensor Mode Two remote sensor modes and an off setting are available to prevent interference from other Canon wireless controllers being used nearby. Turning the Remote Sensor Off CAMERA SYSTEM Open the menu and select [SYSTEM]. Select [WL.

  • Page 51: Customizing The Camcorder

    2. Select the menu item you wish to change. • When selecting a start-up image (only in CARD PLAY (VCR) mode): [NO IMAGE], [CANON LOGO], [MY IMAGE1] and [MY IMAGE2] appears. • When selecting a sound: [OFF], [DEFAULT], [MY SOUND1] and [MY SOUND2] appear.

  • Page 52: Using The Custom Key

    Using the Custom Key You can assign the following functions to the CSTM KEY, independently for CAMERA and CARD CAMERA mode. CAMERA Mode Image Stabilizer ( Backlight Compensation ( Zebra Pattern ( Assigning a Function to the CSTM KEY CAMERA SYSTEM Open the menu and select [SYSTEM].

  • Page 53: Recording

    Other Camcorder Settings Beep You will hear a beep upon camcorder operations such as power on/off, start/stop, self- timer countdown, automatic shut-off, and unusual conditions of the camcorder. The beep will not be recorded. If you turn off the beep, all camcorder sounds including the ones of the My Camera settings will be turned off.

  • Page 54: Changing The Display Language

    ❍ The 16:9 mode is an electronically processed effect. ❍ The 16:9 mode cannot be selected in the Easy Recording mode. ❍ Still images cannot be recorded when the 16:9 format is selected. ❍ Multi-image screen and card mix function cannot be used when the 16:9 format is selected.

  • Page 55: Changing The Recording Mode (Sp/Lp)

    Changing the Recording Mode (SP/LP) You can choose from SP (standard play) and LP (long play). LP extends the tape usage by 1.5 times. ❍ Tapes recorded in LP mode cannot be used for audio dubbing ( or AV insert ( ❍...

  • Page 56: Recording Still Images On The Tape

    Recording Still Images on the Tape Starting your recording with a still image allows you to easily locate the beginning of the recording with the Photo Search function ( You can also record still images on a memory card while recording movies on a tape 113).

  • Page 57: During Recording

    During Recording 1. Press the PHOTO button fully. • The camcorder records the still image for approx. 6 seconds. During this time, the camcorder displays the still image and keeps recording the sound. • The camcorder returns to record pause mode. ❍...

  • Page 58: Using The Built-In Flash

    Using the Built-in Flash You can use the built-in flash for recording still images. (auto) (red-eye reduction, auto) The flash fires automatically according to the brightness (flash on) (flash off) CAMERA 1. Press the (flash) button. • The setting changes with each press of the button. •...

  • Page 59: Af Assist Lamp

    ❍ The flash will not fire in the following cases: - When you lock the exposure by pressing the EXP dial in (red-eye reduction, auto) mode. - When the shutter speed is set to 1/2000 in Tv mode in CAMERA mode. However, if (flash on) is selected, the shutter speed becomes set to 1/1000 and the flash fires.
  • Page 60 Turning Off the AF-Assist Lamp PLAY (VCR) CARD PLAY (VCR) CARD CAMERA CAMERA CAMERA SET UP AF AST LAMP••AUTO To turn off the AF-assist lamp, open the menu and select [CAMERA SET UP]. Select [AF AST LAMP], set it to [OFF] and close the menu.

  • Page 61: Using The Recording Programs

    Using the Recording Programs The camcorder is equipped several program AE modes. The availability of functions differs depending on the selected mode. Availability of Functions in Each Mode: Position of the Mode Dial Digital Zoom Image Stabilizer Focus Exposure White Balance Shutter Speed Aperture Zebra Pattern...

  • Page 62: Shutter-Priority Mode

    Shutter-Priority Mode Use this mode to select the shutter speed ( shutter speed for recording sports scenes (such as tennis or golf) or moving subjects (such as roller coasters). Use a slow shutter speed when recording in dimly lit places, or to create a trailing effect. Aperture-Priority Mode Use this mode to select the aperture ( field to give accent to your subject by blurring the background or...

  • Page 63: Super Night

    Super Night Use this mode to record in very dark places. The shutter speed is adjusted automatically. The assist lamp (White LED) lights up automatically responding to the surrounding brightness and illuminates the subject in the center of the screen. ❍...

  • Page 64: Using Digital Effects

    Using Digital Effects You can use the digital effects during recording and playback. Faders ( 65): Begin or end scenes with a fade to or from black. Effects ( 68): Add flavor to your recordings. Multi-image screen ( Availability of Digital Effects by Operating Modes: CAMERA Movies Faders...
  • Page 65 Faders Fade Trigger (FADE-T) The image gradually fades in. Wipe (WIPE) The image begins as a vertical line in the centre and expands sideways until it fills the whole screen. Corner Wipe (CORNER) The image appears from the corners until it fills the whole screen.
  • Page 66 Puzzle (PUZZLE) The image appears in 16 pieces. The pieces move around until the puzzle is solved. Zigzag (ZIGZAG) The image appears in zigzag from the top of the screen. Beam (BEAM) The screen turns yellow, forms a beam that becomes thinner and the image appears.
  • Page 67 Selecting a Fader PLAY (VCR) CAMERA 1. In CAMERA mode, turn the mode dial to a position other than [. 2. Press the SELECT button. [D.EFFECTS |], [FADER], [EFFECT] and [MULTI-S] appear. 3. Select [FADER]. 4. Select the fader option. 5.
  • Page 68 Effects Art (ART) The image becomes like a paint (solarization). Black and White (BLK & WHT) The image becomes black and white. Sepia (SEPIA) The image becomes monochrome with a brownish tint. Mosaic (MOSAIC) The image is blurred through enlarging the size of some pixels. Ball (BALL) The image becomes like a ball.
  • Page 69 Selecting an Effect PLAY (VCR) CAMERA 1. In CAMERA mode, turn the mode dial to a position other than [. 2. Press the SELECT button. [D.EFFECTS OFF], [FADER], [EFFECT] and [MULTI-S] appear. 3. Select [EFFECT]. 4. Select the effect. 5. Press the SELECT button. The name of the selected effect flashes.

  • Page 70: Using The Multi-Image Screen

    Using the Multi-Image Screen The multi-image screen captures moving subjects in 4, 9 or 16 sequences of still images with the Image Capture feature and displays them at one time. Sound will be recorded normally. This feature can be used in CAMERA and PLAY (VCR) mode. You can choose the transition speed at which to capture the subject from manual, fast (every 4 frames), moderate (every 6 frames) or slow (every 8 frames).
  • Page 71 Capturing 10.Press the ON/OFF button. • MANUAL: Images will be captured each time you press the ON/OFF button. The blue frame indicating the next sequence disappears after the last image. To cancel the last captured image, press and hold the ON/OFF button. To cancel the multi-image screen, press and release the ON/OFF button.

  • Page 72: Turning Off The Image Stabilizer

    Turning Off the Image Stabilizer Canon‘s optical image stabilizer allows you to obtain steady recordings even at telephoto. Unlike electronic image stabilizers, it causes no loss in picture quality. There is no need to turn off the image stabilizer during normal recording. However, the camcorder tries to compensate for horizontal movements and you may therefore decide to turn it off during panning.

  • Page 73: Recording With The Self-Timer

    Recording With the Self-Timer PLAY (VCR) CAMERA (self-timer) button 1. Press the (self-timer) button. “ ” appears. When recording movies 2. Press the start/stop button. • The camcorder starts recording after a 10-second countdown (2 seconds when using the wireless controller). The count down appears on the screen.

  • Page 74: Audio Recording

    Audio Recording Changing the Audio Mode You can record sound in two audio modes—16-bit and 12-bit. The 12-bit mode records sound on two channels (stereo 1), leaving 2 channels free (stereo 2) for adding new sound later. Select the 16-bit mode for higher sound quality. CAMERA AUDIO SET UP Open the menu and select [AUDIO SET UP].

  • Page 75: Recording With An External Microphone

    ❍ The microphone level resets to [AUTO] when you turn the mode dial to [. ❍ We recommend using headphones when manually adjusting the audio level. ❍ When recording near loud sounds (such as fireworks, drums or concerts), sound may become distorted or may be recorded not in the actual sound level. ❍...

  • Page 76: Wind Screen

    Wind Screen You can reduce the wind noise when recording in windy places. CAMERA AUDIO SET UP Open the menu and select [AUDIO SET UP]. Select [WIND SCREEN], set it to [ON] and close the menu. “WS O” appears when you turn the wind screen on. ❍...

  • Page 77: Using The Vl-3 Video Light (Optional)

    Using the VL-3 Video Light (Optional) This VL-3 Video Light attaches to the camcorder’s cable-free operation and is powered by the camcorder’s power supply. Refer also to the VL-3 Video Light instruction manual. ❍ Always turn off the camcorder before attaching/removing the video light. ❍...

  • Page 78: Using The Vfl-1 Video Flash Light (Optional)

    Using the VFL-1 Video Flash Light (Optional) This video flash light attaches to the camcorder’s cable-free operation and is powered by the camcorder’s power supply. Using it as video light, you can set it to turn on and off automatically according to the surrounding brightness.
  • Page 79 Using the Video Flash Light as Flash If you attach the video flash light and set it to place of the built-in flash. Refer to selecting the flash mode. PLAY (VCR) CAMERA 1. Set the camcorder to CAMERA or CARD CAMERA mode. 2.

  • Page 80: Using The Dm-50 Microphone (Optional)

    Using the DM-50 Microphone (Optional) The high sensitive Directional Stereo Microphone DM-50 attaches to the advanced accessory shoe for cable-free operation and is powered by the camcorder’s power supply. Use it for recording or dubbing audio. Refer also to the DM-50 Microphone instruction manual. ❍...

  • Page 81: Adjusting The Focus Manually

    Adjusting the Focus Manually Autofocus may not work well on the following subjects: Subjects with Reflective surfaces low contrast (e.g. White Wall) PLAY (VCR) CAMERA 1. Turn the mode dial to a position other than [. 2. Adjust the zoom. When you operate the zoom after adjusting the focus, the subject may not stay in focus.

  • Page 82: Infinity Focus

    Infinity Focus Use this function when you wish to focus on faraway subjects such as mountains or fireworks. Press the FOCUS A/M button more than 3 seconds in step 3. “MF ∞” appears. When you operate the zoom or turn the focus ring, “∞” disappears and the camcorder changes to manual focus.

  • Page 83: Adjusting Exposure Manually

    Adjusting Exposure Manually Exposure Lock You can lock the exposure when recording in situations where the lighting may change suddenly to control the brightness of the image. PLAY (VCR) CAMERA 1. Turn the mode dial to a position other than [. 2.

  • Page 84: Using The Zebra Pattern

    Using the Zebra Pattern The zebra pattern is a series of diagonal stripes that appear on the screen to indicate overexposed areas. Use it as a guide when setting the exposure, aperture or shutter speed. CAMERA CAMERA SET UP Open the menu and select [CAMERA SET UP]. Select [ZEBRA], set it to [ON] and close the menu.

  • Page 85: Setting The Shutter Speed ( Mode)

    Setting the Shutter Speed ( (Shutter-Priority) mode, you can adjust the shutter speed to make stable shots of fast moving subjects or when recording in dimly lit places. PLAY (VCR) CAMERA 1. Turn the mode dial to 2. Turn the EXP dial to select the shutter speed. Turn the EXP dial up for a slower shutter and down for a faster shutter.
  • Page 86 ❍ Guidelines for Recording with High Shutter Speeds: - Outdoor sports such as golf or tennis: 1/2000 - Moving objects such as cars or roller coasters: 1/1000, 1/500 or 1/250 - Indoor sports such as basketball: 1/120 - Do not point the camcorder directly at the sun when the shutter speed is set to 1/1000 or higher.

  • Page 87: Setting The Aperture

    Setting the Aperture ( Select the aperture to control the depth of field to give accent to your subject by blurring the background or the foreground. PLAY (VCR) CAMERA 1. Turn the mode dial to 2. Turn the EXP dial to select the aperture. •...

  • Page 88: Setting The White Balance

    Setting the White Balance The camcorder’s auto white balance system adjusts the colours to appear natural for different lighting conditions. However, you can use the preset modes to reproduce colours more accurately, or set a custom white balance to obtain the optimal setting. White sheet or paper ❍...
  • Page 89 PLAY (VCR) CAMERA CAMERA SET UP For T (Indoor) or U (Outdoor) Setting: 1. Turn the mode dial to a position other than [. 2. Open the menu and select [CAMERA SET UP]. 3. Select [WHITE BAL.]. 4. Select [INDOOR T] or [OUTDOOR U]. “T”...

  • Page 90: Magnifying The Image

    Magnifying the Image The playback image can be magnified up to 5 times. CAMERA 1. Move the zoom lever toward • The image is magnified by 2 times. • A frame appears indicating the position of the magnified area. • To further enlarge the image, move the zoom lever toward To shrink the image below 2 times magnification, move the zoom lever toward 2.

  • Page 91: Displaying The Data Code

    Displaying the Data Code Once date and time are set, the camcorder maintains a data code containing recording date and time and other camera data such as shutter speed and exposure (f-stop). Only date and time appear when playing back a memory card. FOCUS A/M button (data code) ❍...

  • Page 92: Selecting The Date/Time Display Combination

    Selecting the Date/Time Display Combination CAMERA DISPLAY SET UP Open the menu and select [DISPLAY SET UP]. Select [D/TIME SEL.], set it to [DATE] or [TIME] and close the menu. Selecting the Data Code Display Combination CAMERA DISPLAY SET UP Open the menu and select [DISPLAY SET UP].

  • Page 93: Photo Search/Date Search

    Photo Search/Date Search You can search for a still image recorded anywhere on the tape with the photo search function, or locate the change of the date/time zone with the date search function. CAMERA PLAY (VCR) 1. Press the SEARCH SELECT button to choose between photo search and date search.

  • Page 94: Returning To A Pre-Marked Position

    Returning to a Pre-marked Position If you wish to return to a particular scene later, mark the point with the zero set memory and the tape will stop at that point when you rewind/fast forward the tape. CAMERA 1. Press the ZERO SET MEMORY button at the point you wish to return to later.

  • Page 95: Recording To A Vcr Or Digital Video Device

    Recording to a VCR or Digital Video Device You can copy your recordings by connecting the camcorder to a VCR or a digital video device. If you connect a digital video device, you can copy recordings with virtually no generation loss in image and sound quality. When connecting a VCR: ❍...
  • Page 96 Connecting a Digital Video Device Refer also to the instruction manual of the digital video device. Signal flow 4 pin - 4 pin: CV-150F DV Cable (optional) 4 pin - 6 pin: CV-250F DV Cable (optional)

  • Page 97: Recording From Analog Video Devices (Vcr, Tv Or Camcorder)

    Recording from Analog Video Devices (VCR, TV or Camcorder) You can record videos or TV programs from a VCR or analog camcorder on the tape in the camcorder. ❍ Anomalous signals sent from the connected device may be recorded as anomalous picture (although it may not appear so on the screen), or it may not be recorded at all.

  • Page 98: Recording From Digital Video Devices (Dv Dubbing)

    Recording from Digital Video Devices (DV Dubbing) You can record from other digital video devices equipped with a DV terminal with virtually no loss in picture and sound quality. ❍ When recording from digital video devices, make sure that “AV displayed on the screen.

  • Page 99: Concerning Copyright

    Concerning Copyright Copyright Precaution Certain pre-recorded video tapes, films and other materials, as well as some television programmes are copyrighted. Unauthorised recording of these materials may violate copyright protection laws. Copyright Signals During playback: If you try to play back a tape that contains copyright control signals for protection of software, “COPYRIGHT PROTECTED PLAYBACK IS RESTRICTED”...

  • Page 100: Converting Analog Signals Into Digital Signals (Analog-Digital Converter)

    Converting Analog Signals into Digital Signals (Analog-Digital Converter) By connecting the camcorder to a VCR or 8mm video camcorder, you can convert analog video/audio signals to digital signals and output the digital signals via the DV terminal. The DV terminal serves as output terminal only. ❍...
  • Page 101 Turning On the Analog-Digital Converter CAMERA PLAY (VCR) Press the AV \ DV button on the wireless controller. VCR SET UP Open the menu and select [VCR SET UP]. Select [AV\DV OUT], set it to [ON] and close the menu. ❍...

  • Page 102: Replacing Existing Scenes (Av Insert)

    Replacing Existing Scenes (AV Insert) You can insert and replace images/audio on the tape of the camcorder with images/audio from other video devices connected via AV terminal or DV terminal. Playback tape Tape in the camcorder before inserting Tape in the camcorder after inserting ❍...
  • Page 103 Example: AV Insert from a VCR CAMERA PLAY (VCR) 1. Connect the camcorder to the VCR. See Playing Back on a TV Screen ( 2. VCR: Load a recorded cassette. Locate the scene you wish to insert and pause playback shortly before the scene. 3.

  • Page 104: Audio Dubbing

    Audio Dubbing You can add sound from audio devices (AUDIO IN) or with the built-in or an external microphone (MIC. IN). ❍ Use only tapes recorded in SP mode 12-bit audio sound with this camcorder. Audio dubbing will stop if the tape has a blank section or a section recorded in LP mode, 16-bit or 12-bit 4-channel sound.

  • Page 105: Using A Microphone

    Using a Microphone ❍ When using the built-in microphone: Do not connect any cables to the microphone terminal or the accessory shoe. ❍ When using an external microphone: Connect it to the microphone terminal. ❍ When using the DM-50 Microphone: Do not connect any cables to the microphone terminal.

  • Page 106: Playing Back The Added Sound

    7. Press the STOP 3 button on the wireless controller to stop dubbing. Audio device: Stop playback. Set the zero set memory at the end of the scene you wish to dub audio. The camcorder will automatically stop audio dubbing at that point. Playing Back the Added Sound You can select to play back Stereo 1 (original sound), Stereo 2 (added sound), or adjust the balance of both sounds.

  • Page 107: Connecting To A Computer Using A Dv (Ieee1394) Cable

    Connecting to a Computer Using a DV (IEEE1394) Cable You can transfer recordings to a computer equipped with a DV (IEEE1394) terminal or IEEE1394 capture board (optional software required). Use the optional CV-150F (4 pin–4 pin) or CV-250F (4 pin– 6 pin) DV Cable. DV IN/OUT terminal ❍...

  • Page 108: Inserting And Removing The Memory Card

    Inserting and Removing the Memory Card You can use SD Memory Cards or a commercially available MultiMediaCards with this camcorder. The SD Memory Card has a protect switch for prevent accidental erasure. ❍ This camcorder is compatible with SD Memory Cards or MultiMediaCards only. Do not use any other types of memory cards.

  • Page 109: Selecting The Image Quality/Size

    Selecting the Image Quality/Size Changing the Still Image Quality You can choose between Superfine, Fine and Normal. CAMERA PLAY (VCR) CARD SET UP Open the menu and select [CARD SET UP]. Select [SI QUALITY], set it to [SUPER FINE] or [NORMAL] and close the menu. Changing the Still Image Size You can choose between 1632 CAMERA...

  • Page 110: Changing The Movie Size

    ❍ The indication may not decrease even though a recording has been made, or may decrease by 2 images at once. ❍ All indicators are displayed in green when a memory card is played back. Changing the Movie Size You can choose between 352 × 288 pixels and 176 × 144 pixels. CAMERA CARD SET UP Open the menu and select [CARD SET UP].
  • Page 111 RESET The file number will be reset each time a new memory card is inserted (starting at 101-0101 with still images and 001-101 with movies). If the memory card already contains image files, the consecutive file number will be assigned. Still images: CONTINUOUS 101-0104...

  • Page 112: Recording Still Images On A Memory Card

    Recording Still Images on a Memory Card You can record still images with the camcorder, from a tape in the camcorder 114) or from devices connected via the DV terminal or AV terminal ( ❍ Do not turn off the camcorder, disconnect the power source, open the memory card cover or remove the memory card while the card access indicator is flashing.
  • Page 113 3. Press the PHOTO button fully. • F and focusing frame disappear and you hear a shutter sound. • The card access indicator flashes and the card access display appears. • The still image shown on the screen will be recorded on the memory card. ❍...
  • Page 114 CAMERA CAMERA SET UP 1. Open the menu and select [CAMERA SET UP]. Select [PHOTO REC], set it to [CARD ] and close the menu. 2. While you are recording a movie, press the PHOTO button. The image shown on the screen will be recorded on the memory card. Recording from a Tape in the Camcorder You can record images from a tape in the camcorder as still images on a memory card.

  • Page 115: Recording From Other Video Devices

    Recording from Other Video Devices You can record images from devices connected via the S-video terminal or AV terminal (analog line-in function), or via the DV terminal as still images on a memory card. When recording via the AV terminal, make sure that “AV the screen.

  • Page 116: Selecting The Focusing Point

    Selecting the Focusing Point The subject you wish to record is not always in the centre of the screen. In the Focus- priority mode, you can choose from one of three focusing points to automatically put the subject you wish into sharp focus. When the mode dial is set to [, the Focus-priority becomes set to ON (only the centre focusing point is available).
  • Page 117 ❍ If you operate the zoom lever, press the EXP dial or do not press the PHOTO button within 4 seconds, the frames other than the selected one disappear. ❍ When you press the PHOTO button fully before F and focusing frame turn green, F and focusing frame turn yellow.

  • Page 118: Selecting The Drive Mode

    Selecting the Drive Mode You can choose between three drive modes (recording modes). Continuous AEB (Auto Exposure Bracketing) Captures a still image in three different exposures Single Continuous Shooting You can capture a quick series of still images with the continuous shooting function. CAMERA CAMERA SET UP 1.

  • Page 119: Auto Exposure Bracketing

    Auto Exposure Bracketing With Auto Exposure Bracketing (AEB), the camcorder records a still image in three different exposures (dark, normal, light in 1/2 EV steps), allowing you to choose the perfect exposed shot. CAMERA PLAY (VCR) CAMERA SET UP 1. Set the camcorder to CARD CAMERA mode. 2.

  • Page 120: Recording Panoramic Images (Stitch Assist Mode)

    Recording Panoramic Images (Stitch Assist Mode) You can shoot a series of overlapping images and merge them into one large panoramic scene using the supplied software (PhotoStitch) on a computer. When Recording in Stitch Assist Mode: PhotoStitch detects the overlapping portion of adjoining images and merges them. Try to include a distinctive item (landmark, etc.) in the overlapping portion.
  • Page 121 ❍ Compose each image so that it overlaps 30 to 50% of the adjoining image. Try to keep the vertical misalignment within 10%. ❍ Do not include moving subject in the overlapping portion. ❍ Do not try to stitch images that include both distant and close subjects. They may appear warped or doubled up.

  • Page 122: Recording Mpeg-4 Movies On A Memory Card

    Recording MPEG-4 Movies on a Memory Card You can record MPEG-4 movies with the camcorder or from a tape in the camcorder 123). ❍ Do not turn off the camcorder, disconnect the power source, open the memory card cover or remove the memory card while the card access indicator is flashing.
  • Page 123 Recording from a Tape in the Camcorder You can record movies from a tape in the camcorder on a memory card. CAMERA PLAY (VCR) 1. Set the camcorder to PLAY (VCR) mode. 2. Play back the tape. 3. Press the start/stop button when the scene you wish to record appears. You can keep recording until “CARD FULL”...

  • Page 124: Playing Back A Memory Card

    Playing Back a Memory Card You can play back memory card images on the LCD screen, viewfinder screen, or on a connected TV screen (see You can display a single image, 6 at one time (index screen another (slide show without displaying them one by one ( ❍...

  • Page 125: Index Screen

    • Press the CARD + button for fast forward playback and the CARD – button for fast reverse playback. ❍ Movies recorded in Motion JPEG format with another Canon camcorder will be displayed in still image playback mode (indicated with e/a). The 3 button cannot be used during playback of Motion JPEG movies.

  • Page 126: Slide Show

    2. Press the CARD +/– button to change the image selection. 3. Move the mark to the image you wish to view. • Turn the selector dial up to move to the next image and down to move to the previous image. •...

  • Page 127: Protecting Images

    Protecting Images You can protect important images from accidental erasure when displaying a single image or index screen. If a memory card is formatted, all still images and movies, even protected ones, will be erased permanently. ❍ The sample images recorded on the supplied SD Memory Card are already protected.

  • Page 128: Erasing Images

    Erasing Images You can erase images singly or all at once. Be careful when erasing images. Erased images cannot be recovered. ❍ Protected images cannot be erased. ❍ When you select to erase all images, only those images in the respective playback mode (still image or movie) will be erased.

  • Page 129: Selecting Still Images For Printing (Print Order)

    You can select still images for printing and set the number of copies. These print order settings are compatible with the Digital Print Order Format (DPOF) standards and can be used for printing on DPOF compatible Canon printers and PictBridge-compliant printers.

  • Page 130: Erasing All Print Orders

    Erasing All Print Orders CAMERA CARD OPERATIONS 1. Open the menu and select [CARD OPERATIONS]. 2. Select [ PRINT ORDERS ALL ERASE]. “ERASE ALL PRINT ORDERS?”, [NO] and [YES] appears. 3. Select [YES]. All “ ” disappear. 4. Select [b RETURN] to close the menu. PLAY (VCR) CARD CAMERA PRINT ORDERS ALL ERASE...

  • Page 131: Combining Images (Card Mix)

    Combining Images (Card Mix) You can produce effects not possible with just a tape with the Card Mix function. Choose one of the sample images provided on the supplied SD Memory Card (such as picture frames, backgrounds and animations) and combine it with the live video recording.
  • Page 132 Card Luminance Key (CARD LUMI.) Combines illustrations or title with your recordings. The live video recording will appear in place of the light area of the card mix image. You can create your own title or illustration by drawing on a white paper and recording it to the memory card. Mix level adjustment: light area of the still image.

  • Page 133: Selecting The Card Mix Effect

    Selecting the Card Mix Effect PLAY (VCR) CAMERA CARD MIX MIX TYPE•••••CARD CHROMA 1. Turn the mode dial to a position other than [. 2. Open the menu and select [\CARD MIX]. The card mix menu appears. 3. Select the image you wish to combine with the CARD +/–...
  • Page 134 Recording with the Card Mix Effect Movie: 1. Press the start/stop button to begin recording. The combined image is recorded on the tape. 2. Press the start/stop button to end recording. Still Image: 1. Press the PHOTO button halfway. F flashes in white and turns green when focus is adjusted. 2.

  • Page 135: Copying Still Images

    Copying Still Images You can copy still images from tape to memory card, or from memory card to tape. ❍ All still images from the selected still image onward will be copied. ❍ The size of a still image copied from tape to memory card will be 640 × 480. ❍...

  • Page 136: Copying Still Images From Memory Card To Tape

    Copying Still Images from Memory Card to Tape Load a cassette with enough free space, and insert a recorded memory card. Make sure that the protect tab on the cassette is set to allow recording. CAMERA CARD OPERATIONS 1. Select the first still image you wish to copy with the CARD +/–...

  • Page 137: Formatting A Memory Card

    Formatting a Memory Card Format new memory cards, or when you get the message “CARD ERROR”. You can also format a memory card to erase all images recorded on it. The camcorder formats memory cards in the Design rule for Camera File system (DCF) standard.

  • Page 138: Connecting To A Computer Using A Usb Cable

    Connecting to a Computer Using a USB Cable You can download images from the memory card to a computer using the supplied USB cable. ❍ Do not disconnect the USB cable, open the memory card cover, remove the memory card, change the position of the POWER switch or turn off the camcorder and computer while data is being transferred to the computer (while the camcorder’s card access indicator is flashing).
  • Page 139 (e.g. using Windows Explorer). Still Images are saved in the [***CANON] folder of the [DCIM] folder, and movies are saved in the [PRL***] folder of the [SD_VIDEO] folder.

  • Page 140: Memory Card Information

    ❍ We recommend saving backups of memory card images on your computer’s hard drive or other external memory device. Image data may be corrupted or lost due to memory card defects or exposure to static electricity. Canon Inc. makes no warranties for corrupted or lost data.

  • Page 141: Sample Images

    Sample Images 27 sample images are pre-recorded on the supplied SD Memory Card: 8 card chroma key images, 5 card luminance key images, 2 camera chroma key images and 12 card animation images. Card Chroma Key Card Luminance Key Camera Chroma Key Card Animation...
  • Page 142 If you have mistakenly erased the sample images on the supplied SD Memory Card, they can be downloaded from the following homepages: http://www.canon-europa.com/products/products.html http://www.canon-asia.com/ http://www.canon.com.au For details on how to add the downloaded images to the memory card, refer to Adding Still Images from Your Computer to the Memory Card in the Digital Video Software Instruction Manual.

  • Page 143: Printing Still Images (Direct Printing)

    PictBridge-compliant printer. You can also use the print order settings for direct printing ( 129). You can connect Canon Card Photo Printers with the Printers with the logo and printers with the ❍ Observe the following precautions during printing, otherwise printing may not be performed correctly.
  • Page 144 3. Set the camcorder to CARD PLAY (VCR) mode. Wait until the card access indicator stops flashing. 4. Connect the camcorder to the printer using the cable. appears and changes to “ the camcorder. (Does not appear with movies, or still images that cannot be played back with the camcorder.) ❍...

  • Page 145: Selecting The Number Of Copies

    ❍ Cancel Printing Press the controller in while "NOW PRINTING" is displayed. A confirmation dialog appears. Select [OK] and press the controller in. Printing stops even if it is incomplete and the paper is fed through. ❍ Printing Errors - If an error occurs during the printing process, an error message appears 158).

  • Page 146: Selecting The Print Settings (Style/Paper Settings)

    Selecting the Print Settings (Style/Paper Settings) Check which print setting menu your camcorder displays and move to the respective section.The print setting options vary depending on the printer. Setting Options Canon Card Photo Printers Canon Bubble Jet Printers PictBridge-compliant Printer Print Setting Menu...

  • Page 147: Selecting The Paper Size

    Selecting the Image Style 2. Make sure that (Image) is selected and press the controller in. 3. Press the controller to the right or left to select the image style and press the controller in. Pressing the MENU button brings you back to the print settings menu.

  • Page 148: Paper Settings

    Selecting the Borders 2. Press the controller to the right or left to select (Borders) and press the controller in. 3. Press the controller to the right or left to select a borders option and press the controller in. Pressing the MENU button brings you back to the print settings menu.

  • Page 149: Trimming Settings

    3. Move the trimming frame with the controller. Pressing the MENU button brings you back to the print settings menu. ❍ About the color of the trimming frame (Canon Card Photo Printers only): - White: No trimming settings. - Green: Recommended trimming size. (The trimming frame may not appear in green depending on the image size, paper size or borders settings.)

  • Page 150: Printing With Print Order Settings

    Printing with Print Order Settings You can print still images you have selected with the Print Order function. If you wish to print more than 1 copy, set the number of copies in the print order ( When printing with print order settings, you can select the print style such as bordered or borderless, but not the trimming settings.

  • Page 151: About The Network Mode

    Connection First, install DV Messenger. If you wish to connect the camcorder using a USB cable, you also need to install the Canon USB Video Driver. 1. Connect the power adapter to the camcorder. 2. Press the small button below the POWER switch and turn the POWER switch to NETWORK.

  • Page 152: Screen Displays

    Screen Displays LCD Screen Displays You can hide the displays on the LCD screen to have a clear screen for playback. CAMERA DISPLAY SET UP Open the menu and select [DISPLAY SET UP]. Select [DISPLAYS], set it to [OFF <PLAYBK>] and close the menu. •...
  • Page 153 Screen Displays during Basic Recording/Playback indicates flashing. CAMERA mode (battery pack attached): • Remote sensor mode and audio mode disappear after a few seconds. PLAY (VCR) mode: • Remote sensor mode and volume bar disappear after a few seconds. : Fast forward playback/ rewind playback ( PAUSE : ×2 playback...

  • Page 154: Screen Displays During Advanced Recording/Playback

    Screen Displays during Advanced Recording/Playback CAMERA Mode Image stabilizer ( Zoom ( 28)/Exposure ( 83) Exposure level ( Program AE ( Backlight compensation ( Manual focus ( White balance ( Card mix ( 132) Digital effects ( Custom key ( Date and time ( AF/AE locked in Photo mode (...
  • Page 155 CARD CAMERA Mode Image stabilizer ( Self-timer ( 73)/ • Movie recording ( 122) Zoom ( 28)/Exposure ( 83) Program AE ( Exposure level ( Backlight compensation ( Manual focus White balance Custom key ( Date and time ( AF/AE locked in Photo mode ( 112) Accessory attached to...

  • Page 156: List Of Messages

    List of Messages Message SET THE TIME ZONE, DATE AND TIME CHANGE THE BATTERY PACK THE TAPE IS SET FOR ERASURE PREVENTION REMOVE THE CASSETTE CHECK THE DV INPUT CONDENSATION HAS BEEN DETECTED TAPE END CHECK THE CASSETTE [REC MODE] CHECK THE CASSETTE [AUDIO MODE] CHECK THE CASSETTE...
  • Page 157 Memory Card Related Messages Message NO CARD Memory card not is inserted into the camcorder. THE CARD IS SET FOR SD Memory Card is set for erasure prevention. Replace the ERASURE PREVENTION card or change the position of the protect switch. NO IMAGES No images are recorded on the memory card.

  • Page 158: Direct Print Related Messages

    Direct Print Related Messages Message Paper error No Paper Paper Jam Paper has been changed Incompatible paper size Media type error Ink error Ink Cassette Error No Ink Paper and ink do not match Low ink level Waste tank full File error Cannot Print! Could not print X...

  • Page 159: Maintenance

    Maintenance Camcorder Handling Precautions ❍ Do not carry the camcorder by the LCD panel or viewfinder. ❍ Do not leave the camcorder in places subject to high temperatures, such as a sun- heated car, and high humidity. ❍ Do not use the camcorder in places subject to magnetic or electric fields such as near the TV transmitters or portable communication devices.

  • Page 160: Video Heads

    ❍ To maintain the best picture quality, we recommend cleaning the video heads frequently with the Canon DVM-CL Digital Video Head Cleaning Cassette or a commercially available dry cleaning cassette.

  • Page 161: Condensation May Form In The Following Cases

    Condensation Moving the camcorder rapidly between hot and cold temperature may cause condensation (water droplets) to form on its internal surfaces. Stop using the camcorder if condensation is detected. Continued use may damage the camcorder. Condensation may form in the following cases: When the camcorder is moved from an air-conditioned room to a warm, humid place...

  • Page 162: Using The Camcorder Abroad

    You can use the compact power adapter to operate the camcorder and to charge battery packs in any country with power supply between 100 and 240 V AC, 50/60 Hz. Consult the Canon Service Centre for information on plug adapters for overseas use. Playback on a TV Screen You can only play back your recordings on TVs with PAL system.

  • Page 163: Troubleshooting

    Troubleshooting If you have a problem with your camcorder, refer to this checklist. Consult your dealer or a Canon Service Centre if the problem persists. Power Source Problem Camcorder will not turn Battery pack is exhausted. Battery pack is not correctly attached.
  • Page 164 Recording Problem Image will not appear on the screen. “Set the time zone, date and time” appears on the screen. Pressing the start/stop button will not start recording. Camcorder will not focus. A vertical light bar appears on the screen. Sound is distorted or recorded in a lower volume than the actual...

  • Page 165: Memory Card Operation

    Memory Card Operation Problem Memory card cannot be Memory card was not facing inserted. the correct direction. Memory card cannot be Memory card is full. recorded. Memory card is not formatted. Memory card is not inserted. File number reached maximum value. SD Memory Card is protected.

  • Page 166: System Diagram

    Power Adapter S-150 S-video Cable STV-250N Stereo Video Cable CV-150F/CV-250F DV Cable SDC-128M SD Memory Card MultiMediaCard IFC-300PCU USB Cable Canon printers with direct print function/ PictBridge-compliant printers CG-570 Battery Charger CA-570 Compact Power Adapter BP-500 Series Battery Pack PC-A10 SCART...

  • Page 167: Optional Accessories

    Use of genuine Canon accessories is recommended. This product is designed to perform optimally when used with genuine Canon accessories. Canon shall not be liable for any damage to this product and/or accidents such as fire, etc., caused by the malfunction of non-genuine Canon accessories (e.g., a leakage and/or explosion of a battery pack).
  • Page 168 TL-H37 Tele-converter This Tele-converter lens increases the focal length of the camcorder lens by a factor of 1.7. • The image stabilizer is not as effective when the Tele-converter is attached. • The image quality may be degraded at the telephoto side.

  • Page 169: Video Light

    SC-1000 Soft Carrying Case A handy camcorder bag with padded compartments and plenty of space for accessories. This mark identifies genuine Canon video accessories. When you use Canon video equipment, we recommend Canon-brand accessories or products bearing the same mark.

  • Page 170: Specifications

    This camcorder supports Exif 2.2 (also called “Exif Print”). Exif Print is a standard for enhancing the communication between camcorders and printers. By connecting to an Exif Print-compliant printer, the camcorder’s image data at the time of shooting is used and optimised, yielding extremely high quality prints.

  • Page 171: Battery Pack

    USB terminal: DV terminal input/output: AV terminal input/output: S-video terminal input/output: MIC terminal input: Headphone terminal: Operating temperatures: Dimensions: Weight: CA-570 Compact Power Adapter Power supply: Power consumption: Rated output: Operating temperature: Dimensions: Weight: BP-512 Battery Pack Battery type: Rated voltage: Operating temperature: Battery capacity: Dimensions:...

  • Page 172: Index

    Index 12bit audio ....106 16:9 wide screen ....53 6-second auto date ... . 92 Abroad, using the camcorder .
  • Page 173 Magnifying the image ..90 Maintenance ....159 Manual focus ....81 Memory card .
  • Page 174 Canon UK Ltd. CCI Service Centre, Unit 130 Centennial Park, Borehamwood, Hertfordshire, WD6 3SE, England Telephone 0870-241-2161 Canon Australia Pty. Ltd 1 Thomas Holt Drive, North Ryde, N.S.W. 2113, Australia Telephone 805-2000, Fax 887-4484 Canon New Zealand Ltd Akoranga Business Park, Akoranga Drive, Northcote, Auckland, New Zealand Telephone: 489-0300, Fax: 489-0380 Canon Singapore Pte.

This manual is also suitable for:

Mvx3i

Table of Contents
