Summary of Contents for Cambridge Audio incognito ES10

  • Page 1 ES10 Exterior Speakers Installation Guide...
  • Page 2: Table Of Contents

    Hi-Fi or AV equipment. Please take time to read this guide, as it contains important installation information. The ES10 can only be as good as the system it is connected to. Please do not compromise on your audio/visual source components.
  • Page 3: Preparing The Location

    Points t t o r r emember b b efore b b efore m m ounting y y our s s peakers: - Please place your ES10 speakers at least two feet from any television or computer screen, the speakers are not video shielded.
  • Page 4: Mounting The Es10

    1. Unscrew and remove the bracket from the speaker. You can mount the bracket either horizontally or vertically onto the chosen wall. 2. Ensure the chosen wall or surface is solid, never mount a speaker on a plasterboard or unreinforced wall.
  • Page 5: Connecting The Es10

    Repeat connections for the right channel. The speaker cable is coded with a bead or stripe down one lead’s insulation, or has differently coloured wires. 5. If your speakers are wired incorrectly they will be out of phase and sound hollow and indistinct, with a weak bass.
  • Page 6: Troubleshooting

    TROUBLESHOOTING There i i s n n o s s ound Ensure that the amplifier is set correctly. Check that the interconnects are inserted correctly. The s s ound i i s d d istorted o o r g g arbled Check aerial connections and placements.
  • Page 7: Warranty

    If your dealer is not equipped to perform the repair of your Cambridge Audio product, it can be returned by your dealer to Cambridge Audio or an authorised Cambridge Audio service agent. You will need to ship this product in either its original packaging or packaging affording an equal degree of protection.
  • Page 8 ES10 www.cambridge-a a udio.com Part No. AP18812/1...
