INSTALLATION INSTRUCTIONS
10880
10879
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove any debris.
2. Do not remove the plaster guard from the valve body until instructed to.
3. Install valve 880 according to the rough-in dimensions of 10880, install valve 882 according to the rough-in
dimensions of 10879.
ROUGH-IN DIMENSIONS
115
10880
1071632-2A/Rev04
SINGLE LEVER RECESSED SHOWER ONLY TRIM
SINGLE LEVER RECESSED BATH & SHOWER TRIM
The finished wall
38-55
38-55
115
10879
The finished wall
1
