- Page 1 20 LED Profile Mini LED Ellipsoidal Information specifically for: TH-SCLPM20WW/B TH-SCLPM20QW/B TH-SCLPM20QA/B This manual contains important information. Please read before operating fixture. V2.0...
- Page 2 If purchase date can not be provided, warranty period will start at manufacture date. It is the sole discretion of Techni-Lux to repair or replace parts or equipment. All shipping will be paid by purchaser. This warranty does not cover lamps, fuses,...
-
Page 3: Table Of Contents
Table of Contents Specifications ..........................4 Unpacking ...........................5 Purpose of Manual........................5 Power ............................5 Basic Reference ..........................6 Mounting .............................6 Installing Lens Barrel .........................7 Beam Chart ..........................7 Accessory Slot and GOBO Holder ....................8 Gobo Size ..........................8 Basic Setup Wiring Diagrams ....................8 Fixture Menu Display & Buttons ....................9 TH-SCLPM20WW Menu Settings .....................9 TH-SCLPM20QW or QA Menu Settings ...................9 DMX-512 Control ........................10... -
Page 4: Specifications
Specifications Fixture Overview 20w SSL COB LED Heatsink Cooling Block – No Fan Flicker-Free Output for Film/TV/Video Warm White 3000k with CRI >93 DMX, Standalone 5 Pin XLR Data Connectors Low voltage 12vDC power input ... -
Page 5: Unpacking
Unpacking Immediately upon receipt, carefully unpack and inspect the fixture to verify that all parts are present and have been received in good condition. If any parts appear damaged or the shipping carton shows signs of mishandling, notify the shipper immediately. Retain carton and all packing material for inspection. -
Page 6: Basic Reference
Basic Reference LED Display Framing Shutters x4 Menu Buttons Lens Barrel (Not Included) Data Out 10 Color Frame Slot Data In 11 Color Frame Locking Clip Power Input 12 Focus Knob x2 Yoke 13 Accessory / Gobo Slot and Cover Yoke Knob x2 14 Lens Barrel Rotation/Removal Knob Mounting... -
Page 7: Installing Lens Barrel
Installing Lens Barrel A Lens Barrel is required but sold separately to combine with the fixture and are interchangeable. This Lens Barrel determines the Beam Angle of the fixture. Select the angle best suited to the application. TA-SCLPMLENS/14 14 degree for mSculpt Profile TA-SCLPMLENS/19 19 degree for mSculpt Profile TA-SCLPMLENS/26... -
Page 8: Accessory Slot And Gobo Holder
Accessory Slot and GOBO Holder The Accessory Slot is located under a sliding plate fixed by two screws. When nothing is installed this cover prevents light spillage from the fixture. Under the cover are two different sized slots. The larger slot can accept accessories like Irises or GOBO rotators. The smaller slot is generally reserved for fixed GOBO holders and variants are available to accommodate either metal or glass gobos. -
Page 9: Fixture Menu Display & Buttons
Fixture Menu Display & Buttons Use the 3 buttons and display panel located on the rear of the fixture to access fixture settings. Press the ESC/Enter button to select an option then again to Save and exit. Use the DOWN/UP buttons to move through the menu and to increase or decrease a value or change the option. -
Page 10: Dmx-512 Control
DMX-512 Control Fixtures require a "Start Address" from 1 to 512, setting the first DMX channel containing data for the fixture (see DMX Background). Before addressing fixtures, consult the manual of the system’s DMX controller to select a desirable addressing scheme. Valid Start Addresses range from 1 to 512. -
Page 11: Adapters For 3 Or 5 Pin Xlr
Adapters for 3 or 5 pin XLR Systems using a mix of 3 and 5 pin XLR DMX interfaces can be accommodated by purchasing adapters or building adapter cables. Numbers designating each pin can be found on connectors. Converting between the two XLR types is done pin-to-pin. Shield wire connects to pin 1, then connect pin 2 to pin 2 and pin 3 to pin 3, regardless of either connector’s gender or pin count. -
Page 12: Dmx Channel Assignments And Values
DMX Channel Assignments and Values WW Channel Layout (for model TH-SCLPM20WW) 2 CHANNELS Values Description Channel Function Dimmer Dimmer Intensity 0 - 100% Shutter Strobe Strobe Speed Open to Fastest QW Channel Layout (for model TH-SCLPM20QW) 8 CHANNELS Values Description Channel Function Dimmer... -
Page 13: Maintenance
Maintenance Make sure fixture is cool and disconnected from power mains before any service. Weekly operating hours and environmental conditions will establish how often the fixtures need cleaning. Fixtures should be cleaned and inspected at least once a month to maintain optimum performance. -
Page 14: Dmx-512 Background
DMX-512 Background DMX-512 is a digital data transmission standard developed by the United States Institute for Theater Technology (USITT). It is designed to enable control of lighting equipment. DMX deals solely with the formatting of data for transmission and does not dictate how the data is created or used. Under DMX, signals are transmitted in much the same way a computer modem transmits data. -
Page 15: Accessory Items (Sold Separately)
Accessory Items (sold separately) Order Code Description CL-MINI/B MNB Clamp-Mini 3/4"-2"Pipe - Black CL-CBHALF/LP Coupler Half Cheese-borough Low Profile - Silver CL-MICRO/B MMB Clamp-Micro 7/16" to 1-1/4" OD Pipe Black DA-DCE1 DC Power Extension Cable - Male to Female connectors, 1.5 meter length (4.92 feet) DC Power Extension Cable - Male to Female connectors, 3 DA-DCE3... - Page 16 10900 Palmbay Drive • Orlando, FL 32824 U.S.A. www.techni-lux.com...
