- Page 1 Sport SX Installation Manual Including Legacy Sport HS/WS Installation Revision A May 2019 GRT Avionics, Inc. 3133 Madison Avenue SE Wyoming, MI 49548 616-245-7700 support@grtavionics.com grtavionics.com...
- Page 2 Congratulations on your purchase of the GRT Avionics EFIS! We are pleased that you have chosen our product to meet your flying needs! This manual describes the installation of the GRT Sport SX and legacy Sport HS and Sport WS display units using the software version shown in the Record of Revisions.
-
Page 3: Record Of Revisions
GRT Avionics, Inc. May 2019 RECORD OF REVISIONS Sport Revision Date Description SW Revision SX 15.00 Re-issue as a standalone manual for 2019 and prior Sport SX/Sport HS/Sport WS Sport SX Install. Manual Rev. A... -
Page 4: Table Of Contents
2-1: Choosing Your Serial Port Assignments—the Key to a Good Installation! ... 6 2-2: Common Equipment Interfaces ................7 2-2-1: Other GRT Avionics Display Units—the Inter-Display Unit Link ..... 7 2-2-2: Autopilots ....................... 8 2-2-3: Autopilot Using GRT Avionics Servos ............8 2-2-4: Trio Avionics and TruTrack Flight Systems External Autopilots ..... - Page 5 5-14: How Accurate Should the Magnetic Heading Be? ..........29 5-15: Other Required Settings and Options ............... 29 APPENDIX ........................31 A-1: 6.5” Sport SX Mounting Template ..............32 A-2: 8.4” Sport SX Mounting Template ..............33 A-3: Sport HS Mounting Template ................34 A-4: Sport WS Mounting Template ................
- Page 6 A-5: External Module Diagrams ................. 36 A-6: Magnetometer Installation Diagram ..............37 A-7: Sport SX Internal GPS Diagram ................. 38 A-8: Sport SX200A (Adaptive AHRS) Connector A Pinout Diagram ......39 A-9: Legacy Model SX200 Connector A Pinout Diagram ........... 40 A-10: Magnetometer –...
-
Page 7: Section 1: General Description
Sport SX stem: • EFIS: Electronic Flight Instrumentation System. This refers to the Sport SX system as a whole; it includes the display unit, peripheral devices and the components that connect them together (such as wiring harnesses). -
Page 8: 1-2: Certification
GPS. The Sport SX EFIS display units have two model numbers. The S200 is used as the primary flight display (PFD) in a multi-display system, or the only display in a single- display system. -
Page 9: 1-4: Integrating Third-Party Equipment
S200 should be used in place of the S100. An internal GPS is standard in the Sport SX S200. Any external GPS may also be used, as long as its serial data output is in one of the commonly used avionic formats. Most GPS units will always transmit their flight plan, allowing the EFIS to display either the GPS’s flight plan or its own internal plan. -
Page 10: 1-6: Supported Equipment
1-6: Supported Equipment The list of serial-port compatible equipment includes: • ADS-B (Traffic and Weather) • GRT EIS Engine Monitor (All Versions) • GRT Autopilot Servos • External Autopilots (Trio Avionics and TruTrack Flight Systems) Sport SX Install. Manual Rev. A... - Page 11 • Zaon Flight Systems PCAS XRX and MRX • BF Goodrich WX-500 Stormscope • Vertical Power VP-X Series Electronic Circuit Breaker System • Serial Data Input Transponders • TCAS (Traffic Collision Avoidance System/Traffic Alert and Collision Avoidance System) Sport SX Install. Manual Rev. A...
-
Page 12: Section 2: Planning Your Installation
Note: that when two devices share one serial port, they must use the same baud rate. Some limitations that should be considered when planning your serial port connections: Sport SX Install. Manual Rev. A... -
Page 13: 2-2: Common Equipment Interfaces
EFIS exceeds the standard. • The Sport SX serial ports are all high-speed, meaning that any serial port can be used with any device, regardless of the baud rate the connection may require. The Legacy Sport WS and HS models have a single high-speed port (serial port 4), which is typically used to provide ADS-B weather or XM weather to the EFIS. -
Page 14: 2-2-2: Autopilots
2-2-3: Autopilot Using GRT Avionics Servos An autopilot using GRT Servos provides excellent performance and is the easiest configuration to implement. The installation will require wiring for the servos, mounting kits to attach the servos to your airplane, a power-switch for the servos and an engage/disengage button. -
Page 15: 2-2-5: Ads-B Receivers
2-2-6: ADS-B GPS Output The GPS output from the Sport SX’s internal GPS is NOT FAA 2020 compliant for use with ADS-B or mode S with extended squitter transponders. If this GPS position data is used, the FAA will detect that a noncompliant GPS is being used. However, the GRT Safe-Fly GPS is 2020 ADS-B compliant and is approved by the FAA for this use. -
Page 16: 2-2-9: Communication And Navigation Radio Tuning
GRT Avionics, Inc. May 2019 data. The Sport SX requires an external adapter for Gray code altitude encoding outputs. Newer transponders may allow either serial output or Grey code. 2-2-9: Communication and Navigation Radio Tuning The EFIS has the ability to load the Garmin SL30 and SL40 radios with frequency pre- sets, allowing convenient selection of these frequencies from the front panel controls of the radio. -
Page 17: 2-3: Gray Code Altitude Encoder Output
A USB port is easy to connect and transmits large amounts of data quickly. USB devices do not require you to program a baud rate. The Sport SX has one USB port that may be used for one USB device. Alternatively, you may attach a USB hub to connect up to three devices. -
Page 18: 2-9: For More Information
• The Experimental Aircraft Association has compiled a collection of videos called “Hints for Homebuilders” on its website, www.eaa.org. A quick search through these will give you valuable hints on various wiring topics, including properly crimping D-sub/Molex connector pins. Sport SX Install. Manual Rev. A... -
Page 19: Section 3: Physical Installation
EFIS when the canopy is closed. See the Appendix sections A-1: 6.5” Sport SX Mounting Template, A-2: 8.4” Sport SX Mounting Template, A-3: Sport HS Mounting Template and A-4: Sport WS Mounting Template for display unit dimensions and clearance requirements for the rear of the unit. -
Page 20: 3-3: Legacy Analog Magnetometer Installation For Sport Sx200
The magnetometer’s location will be tested for interference in Section 5: Initial Checkout, Basic Configuration Settings and Calibration, after the initial boot-up checks of the Sport SX. 3-3: Legacy Analog Magnetometer Installation for Sport... -
Page 21: 3-4: Cooling Considerations
Interface Diagrams for additional installation instructions. 3-4: Cooling Considerations The GRT Sport SX does not require external cooling. However, as with all electronic equipment, lower operating temperatures may extend equipment life. Units in an avionics stack heat each other through radiation, convection and sometimes by direct conduction. -
Page 22: 3-6: Angle-Of-Attack Pressure Port Connection
Use the appropriate tubing to make an air-tight connection between the AOA pitot and the AOA port on the EFIS. The AOA port is located between the pitot (marked “P”) and the static (marked “S”) ports. Sport SX Install. Manual Rev. A... -
Page 23: Section 4: Wiring
Configuration Settings and Calibration must be completed to verify that the EFIS is not affected by radio transmissions on any frequency. • Consider the effects of individual component failures in the design of the system and create redundancy where necessary. Sport SX Install. Manual Rev. A... -
Page 24: 4-2: Power Connections
The cable assembly provided includes 22 gauge wire for the ground return of the display units. This will result in a voltage drop of about 0.015V/ft, which is acceptable for wire lengths of up to five feet. Sport SX Install. Manual Rev. A... -
Page 25: 4-4: Magnetometer Wiring
“General Setup” menu. Each serial port is listed and entries are provided that allow them to be configured for a wide variety of functions. Since all serial ports on the Sport SX are high-speed, they are capable of receiving data at 115,200 baud and can be used for any function. -
Page 26: 4-6: Warning Light Output
This output provides a path to ground when active, thus the indicator should be wired with one of its terminals to aircraft power while the other is wired to this output. The maximum current that can be controlled by this output is 0.2 amps. Sport SX Install. Manual Rev. A... -
Page 27: Section 5: Initial Checkout, Basic Configuration Settings And Calibration
Once all settings are configured, the settings should then be backed up to a USB memory stick, using the “User Setting Backup” function on the “Display Unit Maintenance” set menu. This will allow you to restore these setting if they ever become altered. It also Sport SX Install. Manual Rev. A... -
Page 28: 5-4: Required Setup For The Internal Gps
GPS1 or GPS2. The following user setting defines how the internal GPS is to be used. Internal GPS: None / GPS1 / GPS2: (Applies to Sport SX only. Accessed via the Set Menu, General Setup submenu) (Factory default is GPS1). This setting is used to assign the internal GPS to one of the two EFIS GPS inputs. -
Page 29: 5-7: Setting Ahrs Orientation
2. Enter the offset, in degrees, for each axis. Positive corrections correspond to right roll, pitch up and right yaw. See following figures (not to scale): Instrument Panel Tilt 20° Pitch Down = -20 Pitch Offset Longitudinal Axis Figure 5-1: AHRS Pitch Orientation Offset Sport SX Install. Manual Rev. A... -
Page 30: 5-8: Magnetometer Location Validation
For aircraft with retractable landing gear: If the magnetometer is located within 2 feet of retractable landing gear, support the aircraft using proper jacking equipment, then repeat Step 1 while operating the landing gear. Sport SX Install. Manual Rev. A... -
Page 31: 5-9: Analog Magnetometer Wiring Problems - Sport Sx200 (Legacy Ws And Hs Only)
1. Go to Set Menu > AHRS Maintenance > Set Magnetometer Orientation. Answer the prompts on the screen to begin automatic orientation of the magnetometer. For maximum accuracy, this procedure should be performed when the ambient temperature is between 50-90°F. Sport SX Install. Manual Rev. A... -
Page 32: 5-11: Check The Uncorrected Magnetic Heading
GPS ground track to determine when you are taxiing in a magnetic north direction. Make small corrections to the direction of travel of the airplane and continue to taxi for several seconds for the GPS to accurately Sport SX Install. Manual Rev. A... - Page 33 OVERLIMIT will be displayed on the AHRS maintenance page next to the Magnetometer Calibration field). A correction of greater than 127° can be caused by incorrect mounting of the magnetometer, the presence of ferrous Sport SX Install. Manual Rev. A...
-
Page 34: 5-13: Measuring The Accuracy Of The Magnetic Heading
This can also be observed on the PFD screen, although the heading data on this screen is slaving the yaw gyro, and thus, will respond slowly to the difference between the displayed heading and that of the magnetometer heading. When using the PFD screen, Sport SX Install. Manual Rev. A... -
Page 35: 5-14: How Accurate Should The Magnetic Heading Be
Fuel Units General Setup If Fuel Flow is installed. Stall Speed Landing Primary Flight Display Stall Speed Clean Primary Flight Display Max Flap Speed Primary Flight Display Max Struct. Cruise Speed Primary Flight Display Sport SX Install. Manual Rev. A... - Page 36 New databases are provided Database Maintenance > Display Unit every 28 days on the GRT Load Navigation Database Maintenance website. Adjust “BIAS” as necessary so Altimeter Calibration Altimeter Calibration Altimeter is correct with currently-entered baroset. Sport SX Install. Manual Rev. A...
-
Page 37: Appendix
This section contains diagrams (mounting, wiring and interface), installation notes for specific components (magnetometer, angle-of-attack, etc…) and physical specifications for the Sport SX. The Wiring and Pinout Diagrams included in this Appendix show the function of each D-sub connector terminal position and its associated wire color. Functions labeled NC have no connection or are terminal positions that should remain empty. -
Page 38: A-1: 6.5" Sport Sx Mounting Template
Figure A-1: 6.5” Sport SX Mounting Template All dimensions are in inches (NOT TO SCALE). Panel Cutout: 6.24” x 5.19” (This allows for clearance on each side). Use No. 6 screws for mounting. -
Page 39: A-2: 8.4" Sport Sx Mounting Template
Figure A-2: 8.4” Sport SX Mounting Template All dimensions are in Inches (NOT TO SCALE). Panel Cutout: 8.064” x 6.33” (This allows for clearance on each side). Use No. 6 screws for mounting. -
Page 40: A-3: Sport Hs Mounting Template
GRT Avionics, Inc. May 2019 A-3: Sport HS Mounting Template Figure A-3: Sport HS Mounting Template NOT TO SCALE Sport SX Install. Manual Rev. A... -
Page 41: A-4: Sport Ws Mounting Template
GRT Avionics, Inc. May 2019 A-4: Sport WS Mounting Template Figure A-4: Sport WS Mounting Template All dimensions are Inches (NOT TO SCALE). Sport SX Install. Manual Rev. A... -
Page 42: A-5: External Module Diagrams
• GPS and ARINC modules are 9/16” taller than mount. • Allow an extra 3” above ARINC module for D-sub connector. Figure A-5: External Module – Top View Figure A-6: External Module – Side View Sport SX Install. Manual Rev. A... -
Page 43: A-6: Magnetometer Installation Diagram
GRT Avionics, Inc. May 2019 A-6: Magnetometer Installation Diagram Figure A-7: Magnetometer Installation Sport SX Install. Manual Rev. A... -
Page 44: A-7: Sport Sx Internal Gps Diagram
GRT Avionics, Inc. May 2019 A-7: Sport SX Internal GPS Diagram Figure A-8: Sport SX Internal GPS *NOTE: Serial Port 3 is used for the Internal GPS, when optionally installed. The receiving port and GPS module are located inside the EFIS display unit. Pin 32 functions as an output to feed GPS information to an external device that requires GPS. -
Page 45: A-8: Sport Sx200A (Adaptive Ahrs) Connector A Pinout Diagram
SX200A by noting the AHRS software version on the Set Menu, **: Applies to SX with CPU/GPU processor upgrade. AHRS Maintenance page. AHRS software versions less than 50 (or 0.50) are legacy type AHRS. Recommended serial port usage in italics. Sport SX Install. Manual Rev. A... -
Page 46: A-9: Legacy Model Sx200 Connector A Pinout Diagram
SX200A by noting the AHRS software version on the Set Menu, **: Applies to SX with CPU/GPU processor upgrade. AHRS Maintenance page. AHRS software versions less than 50 (or 0.50) are legacy type AHRS. Recommended serial port usage in italics. Sport SX Install. Manual Rev. A... -
Page 47: A-10: Magnetometer - Digital And Analog (Legacy)
Insert terminal into connector after the Insert terminal into connector after the wire is pulled through the airframe. wire is pulled through the airframe. Figure A-10: 9 Position Female D-sub Connector Figure A-11: 9 Position Male D-sub Connector Sport SX Install. Manual Rev. A... -
Page 48: A-11: Sport Sx200A Suggested Connector A Pinout Diagram (Dual-Screen System)
SX200A by noting the AHRS software version on the Set Menu, **: Applies to SX with CPU/GPU processor upgrade. AHRS Maintenance page. AHRS software versions less than 50 (or 0.50) are legacy type AHRS. Recommended serial port usage in italics. Sport SX Install. Manual Rev. A... -
Page 49: A-12: Legacy Model Sx200 Suggested Connector A Pinout Diagram (Dual-Screen System)
SX200A by noting the AHRS software version on the Set Menu, **: Applies to SX with CPU/GPU processor upgrade. AHRS Maintenance page. AHRS software versions less than 50 (or 0.50) are legacy type AHRS. Recommended serial port usage in italics. Sport SX Install. Manual Rev. A... -
Page 50: A-13: Sport Sx100 Suggested Connector A Pinout Diagram (Multi-Screen System)
*NOTE: Serial Port 4 is the only high-speed port in HS and WS Sport EFIS models, making it the only port suitable for XM Weather ***NOTE: Applies to SX with CPU/GPU processor upgrade. in these units. All five SX serial ports are high-speed. Sport SX Install. Manual Rev. A... -
Page 51: A-14: Angle-Of-Attack (Aoa) Installation And Calibration
When in flight, in smooth air and at a sufficient altitude to safely stall the airplane, select “Set Menu – Primary Flight Display.” Near the end of this menu, set “Angle of Attack (AOA)” to “ON.” New settings will appear below this setting when set to “ON.” We Sport SX Install. Manual Rev. A... -
Page 52: A-15: Sport Sx Display Unit Specifications
The prompts will include a step where you fly the airplane near stall speed. When performing this step, minimal power should be used while the flaps should be in their retracted position. A-15: Sport SX Display Unit Specifications Overall Size: 6.5” Sport SX 7.1” W x 5.25” H Faceplate 4.75”... -
Page 53: A-16: Table Of Figures
5-1: AHRS Pitch 5-7: Setting AHRS Orientation Offset Orientation 5-2: AHRS Yaw 5-7: Setting AHRS Orientation Offset Orientation A-1: 6.5” Sport SX A-1: 6.5” Sport SX Mounting Template Mounting Template A-2: 8.4” Sport SX A-2: 8.4” Sport SX Mounting Template Mounting Template... - Page 54 A-10: Magnetometer – A-10: 9 Position Female Digital and Analog D-sub Connector (Legacy) A-10: Magnetometer – A-11: 9 Position Male Digital and Analog D-sub Connector (Legacy) A-12: Sensed AOA A-14-1: Sensed AOA Fabrication and Installation Installation Sport SX Install. Manual Rev. A...
