Settings Page Selections:
From the Settings page screen you can select one of the following selections:
Identity– This page allows the user to enter information that is necessary to identify
the meter. It gives an identity to a particular PPX II. Each PPX II should have
different information entered for its identity.
Input – This page allows for the selection of wiring configuration, setup of CT and
PT ratios, demand intervals, and TDD denominator. It is also used for setting up
loss compensation, binary input de-bounce (if input option is ordered) and energy
pulse output.
Network – This page allows the user to change the network configuration settings
for IP address, gateway and router address.
Serial Port – This page allows user setup of the serial port (serial port mode, baud
rate, parity, etc.)
Protocol – This page allows user configuration of the protocols – DNP or Modbus
IEC61850 – This page allows user to download and upload ICD and CID files (if
option is ordered)
Screen Enable - Allows the screens shown on the PPXIITD or the D650 (if either
ordered) to be enabled/disabled by the user. The Screen Enable tab/link only
appears if the PPX II has the display port or optional serial port. Refer to Appendix
A3.
Custom Screens – Allows the user to set up custom display screens if the standard
screens don't meet their needs (if either the PPXIITD or D650 is ordered). The
Custom Screens tab/link only appears if PPX II has the display port or optional
serial port. Refer to Appendix A3
Time Sync – This page allows the user to set time
Load/Store Settings – This page allows you to save and retrieve settings
Security – This page allows the user to set a password
Firmware Upload – This page allows the user an interface to browse for or type in
the location on their PC of new firmware for purposes of uploading to the unit.
Trend Recorder – This page allows for configuring the trend recorder settings.
Screen shots showing the selections to be made for each of the above selections
follow on the next few pages. Default values are shown where applicable.
