3.6 User Controls and Indicator
3.6.1 Power ON/OFF Switch
3.6.2 LED Indicator
3.6.3 OSD
3.6.3.1 Buttons
3.6.3.2 OSD Menu Level
3.6.4 Hot Keys Function
3.6.4.1 Contrast (
3.6.4.2 Brightness (
*3.6.4.3 Mute On (
*3.6.4.4 Mute Off (
*3.6.4.5 In monitor power saving mode
*3.6.4.6 Key lock function
Table 2 S720G/S730G OSD Control Map
Level 1
Direct Adj. Brightness
Direct Adj. Contrast
Direct Adj. Audio Mute
Volume
*Auto Tune
Color
Main Menu
The switch control scaler power down and turn off panel.
The LED color shall indicate power status as shown in paragraph
3.7
ESC ,▽ , △ ,
See Table 2. S730G/S720G OSD Control Map
)
Press "△ " to pop up ;then press "△ " or "▽ " to adjust Contrast up
or down.
)
Press "▽ " to pop up ;then press "△ " or "▽ " to adjust Brightness
up or down.
Press "Esc" directly to disable speakers, while speakers in normal
)
state.
) Press "Esc" directly to enable speakers, while speakers in audio
mute state.
"Esc" key is for Mute On and Off function
"△ " key is for increasing volume function.
"▽ " key is for decreasing volume function.
"ESC" key is enable or disable audio mute.
Push"
Setup "Key lock" functions enable or disable.
Level 2
Adjustment Scale
*Adjustment Scale
9300∘ K
6500∘ K
User
*Clock
*Phase
Smooth
*Image Position
-8-
Service Manual
" for 10 sec while the screen has no any OSD showing to
Level 3
R/G/B select
*Adjustment Scale
*Adjustment Scale
On/Off
*H-Position
S720G
Level 4
Adjustment Scale
*Adjustment Scale
