3.7 Power Management
This monitor will meet the low power specification, Including USA governmental requirements
For Energy Star, the NUTEK standard and the VESA DPMS standard which detected the Hori. /Vert.
Sync signal from host CPU.
A dual color (green/amber) LED is located on the front bezel to indicate the power management states.
Status
Sync. Video
Active Active
No Sync. Blanked
Note. 1 : Audio function is operating at no signal input.
Once "Esc" or "△ " or "▽ " key initiates under power saving condition, the audio
function can be waked up and the power consumption can not be the above definition.
4. TROUBLE SHOOTING
VIDEO DOES NOT APPEAR
Power Power
consumption management
39W max. On
Power saving
≦ 2W
(Note.1)
-10-
Service Manual
Picture Recovery time
-
≦ 3 sec
S720G
LED Color
Green
Amber
