- Page 1 SenSor control panel with integrated wi-Fi SE VENTO Expert W USER'S MANUAL...
-
Page 2: Table Of Contents
Warranty card ....................................11 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the SE VENTO Expert W unit and all its modifications. - Page 3 SE VENTO Expert W www.blaubergventilatoren.de The information in this user’s manual was correct at the time of the document’s preparation. The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to incorporate the latest technological developments.
-
Page 4: Purpose
SE VENTO Expert W www.blaubergventilatoren.de PURPOSE The sensor control panel is designed to control the TwinFresh Expert (from version V.2) and TwinFresh Style Wi-Fi series ventilators. DELIVERY SET NAME NUMBER Control panel 1 pc. Mounting box 1 pc. User's manual 1 pc. -
Page 5: Technical Data
SE VENTO Expert W www.blaubergventilatoren.de TECHNICAL DATA DIMENSIONS Control panel Supply voltage, 50 (60) Hz [V] 110-230 42.5 mm Maximum current [A] 0.012 86 mm 82 mm 13.5 mm Cable type 2х0.35 mm 60 mm Temperature range [°C]... - Page 6 SE VENTO Expert W www.blaubergventilatoren.de Example 2: connection via a router with a single Wi-Fi access point. The control panel can be installed outside the range of the Wi-Fi access point built into the master ventilator. • Connect the router to the access point built into the router (see the ventilator user’s manual).
- Page 7 SE VENTO Expert W www.blaubergventilatoren.de 1. Install the mounting box. Installation inside a wall: make a niche in the wall, route the Installation on a wall surface: route the necessary wires and necessary wires and cables to the control panel mounting cables to the control panel mounting location, drill holes location and secure it in place.
-
Page 8: Control
SE VENTO Expert W www.blaubergventilatoren.de CONTROL The master ventilator is controlled by means of the buttons on the touch-sensitive control panel. Ventilator connection status indicator. The indicator glows steadily while the ventilator connection is live. These buttons are used to enable/disable the ventilator, and select speed 1, 2 or 3. The buttons remain dark in the Standby mode. -
Page 9: Storage And Transportation Regulations
SE VENTO Expert W www.blaubergventilatoren.de STORAGE AND TRANSPORTATION REGULATIONS • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5 °C to + 40 °C and relative humidity up to 70 %. -
Page 10: Manufacturer's Warranty
SE VENTO Expert W www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. -
Page 11: Certificate Of Acceptance
This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. Customer’s Signature Seller’s Stamp INSTALLATION CERTIFICATE The SE VENTO Expert W unit is installed pursuant to the requirements stated in the present user's manual. Company name Address Phone Number Installation Technician’s Full Name... - Page 12 www.blaubergventilatoren.de B133-2EN-03...
