  • Page 1 CONTROL PANEL WITH A SENSOR DISPLAY USER’S MANUAL...

  • Page 2: Table Of Contents

    Control ......................................... 6 This user’s manual is a main operating document intended for technical, maintenance, and operating staff . The manual contains information about purpose, technical details, operating principle, design, and installation of the S14/S15 unit and all its modifi cations.

  • Page 3: Purpose

    S14/S15 www.blaubergventilatoren.de • Disconnect the unit from power mains prior • Do not allow children to operate the unit. to any technical maintenance. • Do not store any explosive or highly • When the unit generates unusual sounds, fl ammable substances in close proximity to odour, or emits smoke, disconnect it from the unit.

  • Page 4: Technical Data

    S14/S15 www.blaubergventilatoren.de TECHNICAL DATA 11.2 Supply voltage, 50 (60) Hz [V] 8-30 Temperature range [°C] from 0 up to +45 Humidity range [%] 5-80 (without condensation) R1.5 Casing material Plastic OUT OUT Sensor surface material Glass Electrical protection class IP30...
  • Page 5 S14/S15 www.blaubergventilatoren.de CONTROL PANEL WALL FLUSH MOUNTING CONTROL PANEL WALL SURFACE MOUNTING 1. Route the required wires 1. Prepare a hole in the wall and cables to the control and route all the wires to panel installation place. the installation place.

  • Page 6: Control

    Setting, troubleshooting and upgrading of the software version is made by the service technician. To download the software follow the link https://blaubergventilatoren.de/en/download. Select the document type “Software” and then using the search bar fi nd the software for the automation S14/S15 . Download the software fi le.
  • Page 7 S14/S15 www.blaubergventilatoren.de Control panel buttons indication and functions High speed Filter maintenance Medium speed Summer Cooling mode Low speed Emergency indicator Control panel indication when the unit is off The touch buttons on the control panel are not highlighted. The fi lter maintenance indicator and emergency indicator are highlighted in the respective cases.
  • Page 8 www.blaubergventilatoren.de B55-7EN-01...
