Summary of Contents for BLAUBERG Ventilatoren S16
- Page 1 CONTROL PANEL OPERATION MANUAL...
-
Page 2: Table Of Contents
This User’s Manual consisting of the technical details, operating instructions and technical specification covers the installation, connection and mounting of S16 control panel (hereinafter „Control panel“ or „Unit“ as mentioned in the „Safety requirements“ and „Manufacturer’s warranty“ sections as well as in warnings and information blocks). - Page 3 www.blaubergventilatoren.de UNIT MOUNTING AND OPERATION SAFETY PRECAUTIONS • Do not operate the unit outside the temperature range stated in the user’s • Do not use damaged equipment or cables manual. when connecting the unit to power mains. • Do not operate the unit in aggressive or explosive environments.
-
Page 4: Purpose
PURPOSE S16 control panel is designed for combined operation with automatic system controllers of MPA and VPA supply ventilation units as well as VUT air handling units with integrated electric heaters. THE UNIT MAY NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED PHYSICAL, MENTAL OR SENSORY CAPACITIES, OR LACKING THE APPROPRIATE TRAINING. -
Page 5: Mounting And Connection
www.blaubergventilatoren.de MOUNTING AND CONNECTION DO NOT LAY THE AIR HANDLING UNIT POWER CABLE IN CLOSE PROXIMITY TO THE CONTROL PANEL SIGNAL CABLE! WHILE ROUTING THE CONTROL PANEL CABLE DO NOT COIL THE EXTRA LENGTH. The control panel connects to the air handling unit via a four-core Unitronic LiYY cable 0.25 mm in cross-section. - Page 6 www.blaubergventilatoren.de BATTERY REPLACEMENT The battery supports the operation of the clock built into the control panel in the event that the air handling unit goes offline due to a power outage. When the battery discharges completely while the unit is offline the clock stops and the date and time settings are reset leading to incorrect date and time readings upon a subsequent power-up of the unit and, as a result, incorrect scheduled operation.
-
Page 7: Unit Control
www.blaubergventilatoren.de UNIT CONTROL Red LED Green LED Screen Exit Enter Left Down Right Fig. 2 Control panel button functions The control panel screen displays the information about the current state of the ventilation system automatic control system. The screen interface is divided into several main windows. - Page 8 www.blaubergventilatoren.de Room Heater 34 % 12 :3 4 Fig. 4 Window 2, see Fig. 5: To switch to Window 2 press the Right button. „h“ – temperature regulation using the outdoor air temperature sensor; „i“ – temperature regulation using the exhaust air temperature sensor downstream of the heat exchanger. Outdoor Heater 34 %...
- Page 9 www.blaubergventilatoren.de Air handling unit activation/deactivation Filter replacement interval setup Speed (air capacity) setup Screen illumination control Control temperature selection Emergency sound alarm activation/deactivation Date and time setup Indicator contrast setup Daily timer setup Service settings Weekly schedule setup Unit activation/deactivation. Unit activation options: Immediate turning OFF Upon pressing the Enter button the air handling unit is disabled after heater cooling within 120 seconds.
- Page 10 www.blaubergventilatoren.de Year Hours Month Date Minutes Press the Enter button once again to go back to the functions menu. To exit the functions menu press the Exit button. Daily timer setup. The daily timer activates and deactivates the air handling unit at the pre-programmed period of time on a daily basis. Daily timer Activate Deactivate...
- Page 11 www.blaubergventilatoren.de 6.2 „Deactivate“ – disabling the weekly schedule and exit to the functions menu. 6.3 „Review“ – settings preview in the read-only mode; 6.4 „Edit“ – weekly schedule program editing mode. This mode allows editing the air temperature and fan performance settings, adding and deleting programs for specific days of the week as well as editing the values entered previously.
- Page 12 www.blaubergventilatoren.de MONDAY Program #02 has been entered into the memory. The weekly schedule settings enable forced heater shutdown. Enter Program #01 by pressing the Left or Right button, and then press the Up or Down button. MONDAY To enter Program #01 editing mode press the Enter button: Use the Up/Down buttons to set the desired temperature „**“: To finish editing the parameters press Enter.
-
Page 13: Storage And Transportation Regulations
www.blaubergventilatoren.de The values entered into Program #02 (speed stage 3, control temperature +25 °C, and program activation time 12:34) have shifted one number down while Program #01 values have been permanently deleted from the list. In other words, Program #02 parameters have replaced those of Program #01. -
Page 14: Manufacturer's Warranty
www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The warranty period is 24 months after the retail sale date provided the user’s observance of the transportation, storage, mounting and operation regulations. Should any malfunctions occur in the course of the unit operation through the Manufacturer’s fault during the guaranteed period of operation the user is entitled to elimination of faults by the manufacturer by means of warranty repair at the factory free of charge. -
Page 15: Acceptance Certificate
CONNECTION CERTIFICATE Control panel is connected to power mains in compliance with the operation manual requirements by the professional: Company: Expert’s Full Name Date Signature WARRANTY CARD SELLER PURCHASE DATE REPRESENTATIVE IN EU BLAUBERG Ventilatoren GmbH Aidenbachstr. 52 D-81379 Munich, Germany... - Page 16 S16 v.1(1) / EN...
