- Page 1 SenSor control panel USER’S MANUAL...
- Page 2 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about the purpose, technical details, operating principle, design, and installation of the S14/S15 unit (-s) and all of its (their) modifications.
- Page 3 S14/S15 www.blaubergventilatoren.de • Disconnect the unit from power mains prior • Do not allow children to operate the unit. to any technical maintenance. • Do not store any explosive or highly • When the unit generates unusual sounds, flammable substances in close proximity to odour, or emits smoke, disconnect it from the unit.
-
Page 4: Technical Data
S14/S15 www.blaubergventilatoren.de TECHNICAL DATA 39 mm 86 mm 86 mm 39 mm 21 mm 21 mm 58 mm 58 mm 11.2 mm 11.2 mm Supply voltage [V] DC 8-30 Temperature range [°C] 0 ...+45 Humidity range [%] 5...80 (without condensation) R1.5 mm... - Page 5 S14/S15 www.blaubergventilatoren.de CONTROL PANEL WALL FLUSH MOUNTING CONTROL PANEL WALL SURFACE MOUNTING 1. Disconnect the connector from the connection cable of the control panel. 2. Route the cable to the 2. Route the cable to the panel mounting location, panel mounting location...
- Page 6 Setting, troubleshooting and upgrading of the software version is made by the service technician. To download the software, follow the link https://blaubergventilatoren.de/en/download. Select the document type “Software” and then using the search bar find the software for the automation S14/S15. Download the software file.
- Page 7 S14/S15 www.blaubergventilatoren.de High speed Filter maintenance Medium speed Heat recovery o Low speed Emergency indicator Control panel indication when the unit is off The touch buttons on the control panel are not highlighted. The filter maintenance indicator and emergency indicator are highlighted in the respective cases.
- Page 8 www.blaubergventilatoren.de B55-7EN-02...
