Maintenance
1. Pull the filter latch while pivoting the filter downwards
from the hood.
2. Remove the filter from the hood.
Hood Model
AK95
AK9546AS
To order parts, visit us online at http://store.zephyronline.com.

LumiLight LED

In the unlikely event that your LumiLight LED fails, please contact Zephyr to order replacement parts.
See the list of parts and accessories page for part numbers and contact information.
1. Remove hybrid baffle filters.
2. Remove side panels if applicable, and remove
light panels by two screws each.
3. Disconnect LED light quick connector.
4. Push in the two side clips on the ends of the
LED light.
5. Push LED light through the light panel opening.
20
Part Number
50210041
50210041
Monsoon Mini II Use, Care, and Installation Guide
M O N S O O N M I N I I I
I N S E R T
FIG. F
Qty. to Order
2
3
Push the clip
FIG. G
C O R E
