XR-3 Base Instrument Operation Manual
XR-3 Construction
Parts of the XR-3:
1) Cordura protective flap
2) Flap axle
3) XR-3 instrument base
4) Module (swappable)
5) Thumb screw (tuner lock down screw) to secure module (x2)
6) Threaded cross dowel pin to secure module (x2)
7) Rubber shock guard (x2)
2
TESCOMUSA.COM
1 3
Page 8 of 29
XR-3
4
5
6
7
