Summary of Contents for ESS Easy Drain M-line
- Page 1 M-line M-line INSTALLATION MANUAL FOR CONCRETE AND WOODEN FLOORS Installation manual Consejo para la instalación Conseils de montage...
-
Page 2: Table Of Contents
CONTENTS Contenido Table des matières Installation options Installation guide Sealing advice Cleaning Important assembling advice M-line... -
Page 3: Installation Options
INSTALLATION OPTIONS Opciones de instalación Variantes de montage WPS - Water Protection System 3 ½” (89 mm) 1 ⁄ ” 2 ¾” (A - 40 mm) (70 mm) Ø2” (50,8 mm) 5 ⁄ ” 9 ⁄ ” (131 mm) (252 mm) WPS - Water Protection System 3 ½˝... - Page 4 INSTALLATION GUIDE - CLAMP DRAIN - VERTICAL OUTLET (M4) Manual de instalación Explications de montage CLAMP DRAIN* NOT INCLUDED OUTLET HOLE: DISTANCE TO WALL MAKE SURE THE CONNECTION BETWEEN THE CLAMP DRAIN BASE AND SIPHON/DISCHARGE PIPE IS A: 2 ” 3/16 WATERTIGHT! B: 2...
- Page 5 OPTION: CURBLESS SHOWER INSTALLATION DO NOT PIERCE ANY WATERPROOFING LINER! M-line...
- Page 6 ELECTRICAL GROUNDING CLIP CONTINUE WITH IMAGE 1 ON PAGE 11 TEST WATERTIGHTNESS! M-line...
- Page 7 INSTALLATION GUIDE - NO-HUB SLEEVE - VERTICAL OUTLET (M4) Manual de instalación Explications de montage PAN LINER WITH ADHESIVE BONDING OVER THE FIRST SLOPED INSTALL SHOWER IN COMPLIANCE WITH UPC MORTAR LAYER STANDARD SEAL THE ENTIRE FLOOR WITH PAN LINER CONCRETE BOARD (AT LEAST ¼”...
- Page 8 ELECTRICAL GROUNDING CLIP CONTINUE WITH IMAGE 1 ON PAGE 11 TEST WATERTIGHTNESS! M-line...
- Page 9 INSTALLATION GUIDE - HORIZONTAL OUTLET (M1) Manual de instalación Explications de montage CONCRETE BOARD (AT LEAST ¼” ABOVE THE FLOOR) PAN LINER WITH ADHESIVE BONDING SEAL THE ENTIRE FLOOR WITH PAN LINER REMOVE AIR POCKETS BENEATH THE LINER DO NOT PIERCE ANY WATERPROOFING LINER! ELECTRICAL GROUNDING CLIP M-line...
- Page 10 NO-HUB SLEEVE TEST WATERTIGHTNESS! CONTINUE WITH IMAGE 1 ON PAGE 11 M-line...
-
Page 11: Installation Guide
INSTALLATION GUIDE Manual de instalación Explications de montage SLOPED MORTAR BED (2% SLOPE) SLOPED MORTAR BED (2% SLOPE) FILL UP ALL HOLLOW SPACES BENEATH THE DRAIN FILL UP ALL HOLLOW SPACES BENEATH THE DRAIN SEALING COMPOUND (Easy2Seal, Easy2Seal 2K) SEALING COMPOUND (Easy2Seal, Easy2Seal 2K) M-line... - Page 12 SEALING COMPOUND (Easy2Seal, Easy2Seal 2K) OPTIONAL - WET AREA WATER PROTECTION SET MAX. TILE THICKNESS: 3/4” (18 mm) M-line...
-
Page 13: Sealing Advice
NO SECONDARY DRAINAGE! OPTIONAL - SEALING ADVICE PAGE 15 Easy Silicon (EDSIL 1), Easy Compound (ED2C) SEALING ADVICE PAGE 15 Easy Silicon (EDSIL 1), Easy Compound (ED2C) TILEABLE GRATE: 1/2” DEPTH (12 mm) M-line... - Page 14 M-line...
- Page 15 SEALING ADVICE - CLAMP DRAIN - VERTICAL OUTLET (M4) Consejo de sellado Conseil pour étanchéifier ONLY PRIMARY DRAINAGE Sólo desagüe de agua primario Seule évacuation primaire M-line...
- Page 16 WITH SECONDARY (UNDERTILE) DRAINAGE Con desagüe de agua secundario Avec évacuation secondairee Only apply with waterproofing of the entire shower floor M-line...
- Page 17 SEALING ADVICE - NO-HUB SLEEVE - VERTICAL OUTLET (M4) Consejo de sellado Conseil pour étanchéifier ONLY PRIMARY DRAINAGE Sólo desagüe de agua primario Seule évacuation primaire M-line...
- Page 18 WITH SECONDARY (UNDERTILE) DRAINAGE Con desagüe de agua secundario Avec évacuation secondairee Only apply with waterproofing of the entire shower floor M-line...
- Page 19 SEALING ADVICE - HORIZONTAL OUTLET (M1) Consejo de sellado Conseil pour étanchéifier ONLY PRIMARY DRAINAGE Sólo desagüe de agua primario Seule évacuation primaire M-line...
- Page 20 WITH SECONDARY (UNDERTILE) DRAINAGE Con desagüe de agua secundario Avec évacuation secondairee Only apply with waterproofing of the entire shower floor M-line...
-
Page 21: Cleaning
CLEANING - VERTICAL OUTLET (M4) Limpieza Nettoyage du siphon M-line... - Page 22 CLEANING - HORIZONTAL OUTLET (M1) Limpieza Nettoyage du siphon M-line...
-
Page 23: Important Assembling Advice
Important assembling advice: Easy Drain ® Suitable for renovation work and new construction The shower drain should only be installed by specialist companies in compliance with the building regulations. To achieve the best possible result, please carefully read the installation guide. If you have any questions, please consult your supplier. - Page 24 Indicaciones importantes de colocación: Easy Drain ® Adecuado tanto en los edificios de nueva construcción como en la de renovación Únicamente una empresa especializada puede colocar el drenaje o desagüe de ducha y siempre teniendo en cuenta las disposiciones técnicas de instalación. Para que la colocación resulte satisfactoria, lea las indicaciones de montaje cuidadosamente.
- Page 25 Consignes de montage importantes: Easy Drain ® Pour les nouvelles constructions et pour les projets de rénovation Le montage du caniveau de douche devra, dans le respect des règles de la construction, être réalisé uniquement par une entreprise spécialisée. Pour obtenir un résultat optimal, veuillez lire attentivement les instructions de montage.
- Page 26 INSTALLATION NOTES Notas de instalación Notes d’installation M-line...
- Page 27 INSTALLATION NOTES Notas de instalación Notes d’installation M-line...
- Page 28 Deer Park, NY 11729 T: 001-(888) 317-7927 F: 001-(888) 488-1617 email: sales-usa@esspost.com www.easydrainusa.com Manufacturer: Easy Sanitary Solutions Nijverheidsstraat 60 7575 BK Oldenzaal, The Netherlands tel: +31 (0)541 200800 email: info@esspost.com www.easydrain.com ESS PRODUCTS ARE PATENTED AND REGISTRATED TRADEMARKS MADE BY ESS 2019 rev.1...
