- Page 1 Control Sun System 1 Etelligent Ballasts ® ™ with the same controller—operating on 2 separate channels. Sun System 1 Sun System 1 ® ETELLIGENT CONTROLLER INSTRUCTION MANUAL Vancouver, WA • Eureka, CA • Livermore, CA • Ontario, CA Denver, CO • Detroit, MI • York, PA • Nashville, TN Pompano Beach, FL •...
- Page 2 SUN SYSTEM ONE CONTROLLER MANUAL Thank you for purchasing the Etelligent™ Controller for programming the Sun System ® Etelligent Ballasts with signal ports for on/off/dimming functions. This is a dual zone controller which can control up to 400 lights (up to 200 in each of 2 zones). 1.
- Page 3 4. Keypad operation Page up or page down Right shift Increase parameters Reduce parameters Confirm/save 5. Interface connections Power input jack. ZONE A temperature probe input jack. ZONE A signal output jack. ZONE B temperature probe input jack. ZONE B signal output jack. 6.
- Page 4 8. Setting the ZONE parameters EXAMPLE: “ZONE A: 1000W” . Press “OK”, enter into “HOME”. Press “t or u”, select “ZONE A” or “ZONE B” . Select “TYPE” power options: 250W, 400W, 600W or 1000W. Select “POWER” options: Dimming 0% (OFF), 60% - 110% (ON).
- Page 5 11. Operation example settings Example: ZONE A control 1000W ballast, output power is 780W, sunrise time 08:35,(60% power), sunset time 9:00 (turn off), Sunrise and sunset duration time is 29min, if ambient temperature is 30°C ≤ temperature ≤ 40, dimming down automatically to decrease power and temperature.
- Page 6 14. LED failure indicator on electronic ballast Condition Status Maximum number of ignition attempts done without success. This condition is also used to indicate a locked or Ballast locked Flash*1 failed driver. (Ignition intervals 1-5-5-5-5) Lamp stopped for unknown reason Output errors Flash*2 Low input...
