Champ Deluxe Mobile Masker Part #6266 Assembly Instructions Auto Body Toolmart Champ Frame Straightening Equipment, Inc. 2 5 4 5 M i l l e n n i u m D r. , E l g i n I L , 6 0 1 2 4...
Page 2
P a r t s L i s t • (A) - Left Side Brace (viewed from the front) w/Foot • (B) - Right Side Brace (viewed from the front) w/Foot • (C) - Basket • (D) - (4) Caster Wheels •...
Page 3
I n s t r u c t i o n s Attach each foot to the left and right sides Join both sides together by attaching the lower brace (H) to each side Middle Brace (I) Rear View Attach the middle brace (I) to the second holes Attach the bottom tray to the lower back down, from the top of the masker of the masker...
Page 4
Tape Hub Locations Attach (3) blades (N) (figure 1), (4) tape hubs (O) (figure 2) and locking collars, springs and washers (figure 3) Just load your paper rolls and tape, and your Champ Deluxe Mobile Masker is ready to be used!
