DwarfConnection DC-LINK-CLR2 Manual page 8

¼" Tripod Mount
1)
Antenna Connection: RP-SMA (male) Connector
2)
RSSI Status Display: Signal Strength
3)
4) Menu button: Unlock/lock screen
5) Control button: Press to change the channels
LCD screen: Display channel, BAT voltage, temperature
6)
info.
7) ON-OFF: Power Switch
HDMI-OUT: HDMI Output (Type A Female Connector)
8)
9)
Dual SDI-OUT: 3G/HD/SD-SDI Output, (BNC Female Connector)
10) DC-IN: 9.0 – 18.0V DC
11) Mini USB: For firmware upgrade use.
