Characteristics
1000m Range
Transmission ranges of up to 1000m are possible with good line-of-sight and
optimum antenna positioning
Rapid and Reliable Connectivity
The decision not to implement the DFS System compulsory for outdoor use, as well as the
preinstalled transmission channels, mean there is no need for complex pairing procedures.
In addition, transmission stability is increased
Real-Time Transmission
With a latency of less than 1ms, the system is suitable for live monitoring applications
Uncompressed Transmission
10-bit, 4:2:2 transmissions via 3G-SDI and HDMI without format conversion
Supports Formats up to and including 1080p 60Hz
2- Channel Audio Transmission
Embedded audio transmission on CH1 & CH2 via SDI and HDMI, incl. formats such as
Dolby TrueHD, DTS-Master etc.
License-free Frequency Band
Functions in the license-free 5GHz ISM frequency range from 5.1-5.9GHz
Multicast Support
1:1 or 1:n transmissions with up to four parallel systems
Metadata- and Timecode Transmission
AES-128 Encryption
Metal Casing
Transmitter and receiver are extremely durable
Variable Input Voltage
Input voltage range from 9.0-18.0V DC allows the system to be operated with a variety
of batteries or power supplies
Status Displays
Status displays for DC power, video and RSSI signal strength
Mount
1/4" tripod mount
Battery Adapter Plate
Delivered with NPF/V-Mount battery plates as standard
Plug-and-Play Design
Ready to use without the need for complex configuration
!
1
Y
e
a
r
M
a
n
u
f
a
c
t
u
r
e
r
'
s
G
u
a
r
a
n
t
e
e
!5
