Operation; Signal Distribution - DwarfConnection DC-LINK-CLR2 Manual

Operation

Transmitter
Connect the two omni-directional antennas to the SMA male connectors.
1.
There is a ¼" tripod mount at the base of the transmitter if required.
2.
Use the enclosed 4-pin male-to-D-TAP cable to connect to a power supply with
3.
a suitable voltage.
Receiver
There is a ¼" tripod mount at the base of the receiver if required.
1.
Use the enclosed 4-pin male-to-D-TAP cable to connect to a power supply with
2.
a suitable voltage.
3. Ensure you have selected the frequency that corresponds to that of the
transmitter.

Signal Distribution

Connect the camera's SDI or HDMI output to the transmitter's SDI or HDMI input. If both
SDI and HDMI inputs are active, the transmitter will prioritise the SDI signal.
Connect the receiver's SDI or HDMI output to the SDI or HDMI input of the
monitoring/recording device. During active transmission, both the SDI and the HDMI
output on the receiver can be used simultaneously.
Ensure that the antennas are connected firmly, that all other connections are stable,
and that the batteries are suitable.
