Mobile lift Eva450EE has been developed to meet most lifting needs in combination with the right accessories. It is a lift
that can lift patients in a seated or supine position.The Eva450EE is made largely of aluminium, which makes it relatively
light, considering the weight it can lift.
VanGo VG400/VG450 has been developed to meet most lifting needs in combination with the right
accessories. It is a lift that can lift patients in a seated or supine position. The VanGo is made largely
Handicare's SystemRoMedic product series includes a range of lifts, slings and other accessories. SystemRoMedic
of aluminum, which makes it relatively light, considering the weight it can lift.
adopts a holistic approach to patient transfers and is organized in four categories: transfer, positioning, support and
lifting.
Functional inspection
Visual inspection
Inspect lift functions regularly. Check to ensure that material is free from damage.
Before use:
Ensure that the product is correctly assembled.
Check slingbar connection and safety latch function.
Check lift and base-width movement.
Check to ensure that the actuator is correctly installed.
Always read the manual
Always read the manuals for all assistive devices used during a transfer.
Keep the manual where it is accessible to users of the product.
The lift may only be used by persons who have received instruction in the operation of the lift.
Manual nr: 00789En Ver. 2 110203
1
11
12
1. Boom
9
2. Mast
3. Handlebar
4. Battery pack
5. Emergency stop
6. Control box
7. Motor for base-width adjustment
8. Rear castors with brakes
9. SlingBar with safety latch
10. Front castors
11. Emergency lowering
12. Motor/actuator for boom
13. Mast height adjustment
Max. load: 205 kg / 450Ibs
10
Manual - English
Advertisement
Table of Contents
Related Manuals for Vancare VG400
Summary of Contents for Vancare VG400
- Page 1 VanGo VG400/VG450 has been developed to meet most lifting needs in combination with the right accessories. It is a lift that can lift patients in a seated or supine position. The VanGo is made largely Handicare’s SystemRoMedic product series includes a range of lifts, slings and other accessories.
-
Page 2: Table Of Contents
Table of contents Assembly ....................................- Final inspection Using the product ................. - Important information ................- Safe working load ................. - Charging batteries ................. - Handset ....................- Emergency stop ..................- Emergency lowering ................- Trouble shooting .................. -
Page 3: Assembly
Assembly Check to ensure that all components are included: Mast with boom, lift motor, carry bar, control box and battery pack. Base with motor and locking handle. Handset and cord. Instructions, charging cable and power supply cord for charging. Place the mast in the base. There are three alternatives for adjusting the height of the mast. -
Page 4: Final Inspection
Final inspection Check to ensure that no parts have been left in the packaging. Inspect the lift for signs of wear and damage. Check all four castor wheels and castor wheel locks. Check all connections and fixtures including screws and bolts. Check the emergency stop function by depressing the emergency stop, and then pressing either the up or down button. -
Page 5: Using The Product
Using the product Important Information • The lift must be assembled according to the assembly instructions provided with the lift. • The lift may only be used indoors and on a level floor. • Lifting accessories must be properly trial fitted and tested in relation to the patient’s needs and functional ability. •... -
Page 6: Charging Batteries
Charging batteries A tone when using the lift indicating that the batteries need recharging. Charge the lift after use to ensure that the battery is always fully charged. Lock the castor wheels when charging the battery. 1. Connect the charging cable to a power outlet. 2. -
Page 7: Emergency Stop
Emergency stop To activate emergency stop: Depress the red emergency stop button on the control box. Resetting: Turn the button in the direction of the arrows until the button pops out. Emergency lowering Manual emergency lowering: For manual emergency, turn the round plastic knob on the actuator clockwise. Electrical emergency lowering: For electrical emergency, use the down button on the control box. -
Page 8: Accessories
Accessories Slings: For slings and other lifting accessories, please contact your local Vancare distributor. VanderScale for weighing patients Positioning aids: Vanderclips NAME DATE DRAWN hc-mabr 2010-10-14 APPROVED BY STATUS: TITLE COMMENTS: Unless otherwise stated, SIZE DWG. NO. REV. general tolerances... -
Page 9: Maintenance
Maintenance The lift must undergo thorough inspection at least once per year. Inspection must be performed by authorized personnel and in accordance with Vancare's service manual. Repairs and maintenance may only be done by authorized personnel using original spare parts. -
Page 10: Technical Information
Technical information Lifting speed: 34 mm/s without load. Batteries: Two 12V, 2.9 Ah valve-regulated, sealed, lead accumulator (gel-type batteries) Charger: Max. 400mA Motor (mast): DC 24 V, 10 A. IP X4. Operationtime: 10% at maximum continous operation of 2 minutes, maximum 5.5 cycles per minute. -
Page 11: Dimensions Eva450Ee
Dimensions Eva450EE 58-186 22.85-73.28 63-191 24.82-75.25 68-196 26.79-77.22 50-169 19.70-66.59 54-174 21.28-68.56 59-179 23.25-70.53 51,22 47,67 34,67 11,5 4,53 2,36 133-192 52.4-75.65 138-197 54.37-77.62 143-202 56.34-79.59 21.67 Column A measurement is in cm and weight is in kg. Column B measurement is in inches and weight is in lbs. M A N U A L... - Page 12 Dimensions Eva450EE 17.34 17.73 58,5-88 23.05-34.67 68.5-98 26.99-38.61 74.9 14,5 31.9 10.64 16,1 17,7 M is turning diameter N is total weight of lift O is the weight of the heaviest component P is movement in forward direction R is referencemeasure 70 cm with max legspreading S is minimum distance from wall to slingbar at maximum height (legs spread).
- Page 13 For more information on your VanGo lift and accessories, please call 1-800-694-4525 for your nearest distributor. Or go to our website at www.vancare.com for more information. Manufactured for: Vancare, Inc. 1515 First St Aurora, NE 68818 1-800-694-4525 www.vancare.com info@vancare.com...
- Page 14 Demonstrate proper understanding of how to clean the sling and lift? Refer to Operator’s Manual for more detailed description of transfer technique. Pass Fail Observations __________________________________________________________________ _____________________________________________________________________________ Observer’s Name _______________________________________________________________ Observer’s Signature ____________________________________________________________ VANCARE, INC PHONE: (800)694-4525 1515 FIRST STREET FAX: (402)694-3994 AURORA, NE 68818 WEB: www.vancare.com...
