User's Manual
All-in-One Collaboration Solution
NEC 65" InfinityBoard
NEC 75" InfinityBoard
NEC 86" InfinityBoard
Contents
▪
▪
▪
▪
▪
▪
▪
▪
▪
▪
Large Format Display Models
• IB654Q-2.1
• IB754Q-2.1
OOTE:
Please find your model name on the label on the rear side of the monitor.
2.1
®
2.1
®
2.1
®
• IB864Q-2.1
November 15, 2019
Revision 1.0
Advertisement
Table of Contents
Related Manuals for NEC 65" InfinityBoard 2.1
Summary of Contents for NEC 65" InfinityBoard 2.1
-
Page 1: Table Of Contents
User's Manual All-in-One Collaboration Solution NEC 65” InfinityBoard ® NEC 75” InfinityBoard ® NEC 86” InfinityBoard ® Contents ▪ Addendum information ▪ Important information ▪ Safety precautions, maintenance, and recommended use ▪ Shipping box contents ▪ Unpacking the monitor ▪... -
Page 2: Addendum Information
• TC ornament logo: The NEC InfinityBoard version of the base monitor model does not have an ® ornament logo. Therefore, changing the position of the NEC logo is not possible. English−2... -
Page 3: Important Information
Please use the power cord provided with this display in accordance with the power cord table. If a power cord is not supplied with this equipment, please contact NEC. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located. - Page 4 (4) The image shown in this user’s manual is indicative only. If there is inconsistency between the image and the actual product, the actual product shall govern. (5) Notwithstanding articles (3) and (4), NEC will not be responsible for any claims on loss of profit or other matters deemed to result from using this device.
- Page 5 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 3250 Lacey Rd, Ste 500 Downers Nrove, IL 60515 Tel.
-
Page 6: Safety Precautions, Maintenance, And Recommended Use
Safety precautions, maintenance, and recommended use Safety precautions and maintenance Refer to the monitor's full user's manual for complete safety and maintenance instructions. Cleaning the glass surface • The glass surface should be cleaned regularly with a soft, lint-free cloth. •... -
Page 7: Shipping Box Contents
Shipping box contents 65” InfinityBoard ® • FlatFrog InNlass™ Touch Display (V654Q INB) • OPS Slot-in PC (OPS-Kbl-i7v-d8/128/10Pro//TPM/Infinity) • Side-mounted Speaker Set (SP-65IBSM) • USB Camera (Huddly 2m Room Kit) • 2x Passive Magnetic Pen • Remote Control • CD-ROM (User Nuides/Manuals) •... -
Page 8: Unpacking The Monitor
Unpacking the monitor Unpack the display (V654Q INB / V754Q INB / V864Q INB) from the carton box by removing the white clips on the bottom of the box. CAUOIOE: Due to the weight of the product, for installation and handling, four people are required. DO NOT start unless you have enough people available. -
Page 9: Mounting The Monitor
If a problem is detected, please refer to qualified personnel for service. • Regularly check the mounting location for signs of damage or weakness that may occur over time. For NEC qualified personnel Stability hazard To prevent personal injury and damage to the monitor, the monitor must be securely attached to the floor/wall in accordance with the installation instructions. -
Page 10: Installing The Camera, Speakers, And Ops
Installing the camera, speakers, and OPS This section includes: > "Parts list" on page 10 > "Before you begin" on page 11 > "Mount the camera in the speaker" on page 12 > "Mount the speakers to the monitor" on page 13 >... - Page 11 Before you begin The camera can be mounted to either the left or right speaker. Initially, the speaker cover with the camera window is on the left speaker. If you want the camera located on the right side of the monitor, swap the speaker covers between the left and right speakers.
- Page 12 Mount the camera in the speaker 1. Attach the speaker brackets to the sides of the speakers using the countersunk (flat) screws 2. Place the camera in the speaker housing. Insert the screw into the washer , then insert the screw in to the camera to attach the camera to the bracket in the speaker.
- Page 13 Mount the speakers to the monitor 1. Remove screw from the back of the display. 2. Using screws and washers , attach the mounting brackets to the back of the monitor on both the left and right side. OOTE: Most monitors will have a gasket strip attached to the monitor. If your monitor does not have the gasket attached, it is a separate part in the box.
- Page 14 Install the OPS slot-in PC 1. rite down the indows 10 license code; this key is required to activate indows. The code is located on the rear-side of the OPS ANT1 ANT2 slot-in PC. ON/OFF USB 3.0 USB-C DP++ DP++ 2.
- Page 15 Connect the cables OOTE: • Do not connect or disconnect cables when turning on the monitor's main power or other external equipment's power as this may result in a loss of image. • Do not use an attenuating (built-in resistor) audio cable. Using an audio cable with a built-in resistor will lower the sound level.
- Page 16 12), to the USB input on the OPS slot-in PC. OOTE: If connecting to an external PC, NEC can provide the Huddly certified USB extension cable to connect the huddly camera to the external PC. 6. Tnable power to the OPS (skip this step if using an external PC) If you are using the OPS slot-in PC, the function for the monitor to supply power to the OPS needs to be enabled.
-
Page 17: Setting Up The Ops Slot-In Pc
Setting up the OPS slot-in PC This section includes: > "Installing indows 10" on page 17 > "Selecting the speakers" on page 18 Installing Windows 10 1. Press the OPOIO button on the IR remote control to change the video input to the OPS slot-in PC. 2. - Page 18 Selecting the speakers 1. Open the Sound settings in indows by clicking on the speaker icon in the indows task bar. 2. Open the Playpack tab in the Sound settings and select the V654Q, V754Q or V864Q monitor as the Default Device.
-
Page 19: Specifications
Output audio (analog) 3.5 mm jack Output control LAN 100Mbit Open modular intelligence OPS slot technology Open pluggable specification (NEC / Intel OPS standard) OPS max. current 4.7 A OPS power consumption 75 W Compute Module technology Compute Module slot (NEC proprietary standard) - Page 20 Power savings mode ≤0.5, ≤2 (networked standby) Power management VESA DPMS Tnvironmental conditions Operating temperature 0°C to 35°C Operating humidity 20% to 80% Mechanical Dimensions ( x H x D) 1457.1 mm x 832.1 mm x 79.4 mm eight 40.6 kg (89.5 lbs) Bezel width 12.9mm (left and right), 13.1mm (top and bottom) VESA mounting...
- Page 21 ® Compute module NEC Compute Module Interface Board with NEC Raspberry Pi Compute Module NEC Compute Module Interface Board with Raspberry Pi Compute Module 1 or 3 Green features Energy efficiency Annul energy consumption: 248 kh (based on 4 operating hours per day), carbon...
- Page 22 Output audio (analog) 3.5 mm jack Output control LAN 100Mbit Open modular intelligence OPS slot technology Open pluggable specification (NEC / Intel OPS standard) OPS max. current 4.7 A OPS power consumption 75 W Compute Module technology Compute Module slot (NEC proprietary standard)
- Page 23 Internal OPS interface DisplayPort up to 4096 x 2160 @ 60hz Available optional accessories Cart SmartMount® Motorized Height Adjustable Flat Panel Cart Compute module NEC Compute Module Interface Board with NEC Raspberry Pi Compute Module NEC Compute Module Interface Board with Raspberry Pi Compute Module 1 or 3 English−23...
- Page 24 Green features Energy efficiency Annul energy consumption: 248 kh (based on 4 operating hours per day), carbon savings meter, ECO mode, energy efficiency class A, local dimming Additional features Special characteristics 12-bit LUT (Look Up Table), AMX NetLinx support, ASCII control commands, auto ID assignment, auto-tiling function, automated email alert, CEC support, Cisco ebEx kit compatible, CRESTRON connected support, DICOM simulation, display browser control, emergency notification, HDMI with UHD at 60Hz, HDR gamma support (HLN, PQ),...
- Page 25 Output audio (analog) 3.5 mm jack Output control LAN 100Mbit Open modular intelligence OPS slot technology Open pluggable specification (NEC / Intel OPS standard) OPS max. current 4.7 A OPS power consumption 75 W Compute Module technology Compute Module slot (NEC proprietary standard)
- Page 26 Internal OPS interface DisplayPort up to 4096 x 2160 @ 60hz Available optional accessories Cart SmartMount Motorized Height Adjustable Flat Panel Cart ® Compute module NEC Compute Module Interface Board with NEC Raspberry Pi Compute Module NEC Compute Module Interface Board with Raspberry Pi Compute Module 1 or 3 English−26...
- Page 27 Green features Energy efficiency Annul energy consumption: 248 kh (based on 4 operating hours per day), carbon savings meter, ECO mode, energy efficiency class A, local dimming Additional features Special characteristics 12-bit LUT (Look Up Table), AMX NetLinx support, ASCII control commands, auto ID assignment, auto-tiling function, automated email alert, CEC support, Cisco ebEx kit compatible, CRESTRON connected support, DICOM simulation, display browser control, emergency notification, HDMI with UHD at 60Hz, HDR gamma support (HLN, PQ),...
-
Page 28: Manufacturer's Recycling And Energy Information
Dedicated recycling sites ensure that environmentally harmful components are properly handled and securely disposed. To ensure the best recycling of our products, NEC DISPLAY SOLUTIONS offers a variety of recycling procedures and gives advice on how to handle the product in an environmentally sensitive way, once it has reached the end of its life. - Page 29 WTTT Mark (Turopean Directive 2012/19/TU and amendments) Disposing of your used productE: In the Turopean Union EU-wide legislation as implemented in each Member State requires that used electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power cords.
