SPECIFICATION, INSTALLATION
AND OPERATION MANUAL
READ ALL INSTRUCTIONS BEFORE USE
BACK BAR REFRIGERATORS - REMOTE
HORIZONTAL / VERTICAL
Models Horizontal:
CR.BB.U.AG.RB, CR.BB.U.AG.RB.PC, CR.BB.U.AG.RC, CR.BB.U.AG.RC.PC
CR.BB.U.FG.RB, CR.BB.U.FG.RB.PC, CR.BB.U.FG.RC, CR.BB.U.FG.RC.PC
CR.BB.U.SG.RB, CR.BB.U.SG.RB.PC, CR.BB.U.SG.RC, CR.BB.U.SG.RC.PC
CR.BB.U.SGR.RB, CR.BB.U.SGR.RB.PC, CR.BB.U.SGR.RC, CR.BB.U.SGR.RC.PC
Models Vertical:
CR.BB.V.AG.RB, CR.BB.V.AG.RB.PC, CR.BB.V.FG.RB, CR.BB.V.FG.RB.PC
CR.BB.V.SG.RB, CR.BB.V.SG.RB.PC, CR.BB.V.SGR.RB, CR.BB.V.SGR.RB.PC
A guide on the use, care and maintenance
of your quality Culinaire product
Revision: 02 - 8/03/2021 - A
Advertisement
Table of Contents
Related Manuals for Culinaire Stoddart CR.BB.U.AG.RB
Summary of Contents for Culinaire Stoddart CR.BB.U.AG.RB
- Page 1 CR.BB.U.FG.RB, CR.BB.U.FG.RB.PC, CR.BB.U.FG.RC, CR.BB.U.FG.RC.PC CR.BB.U.SG.RB, CR.BB.U.SG.RB.PC, CR.BB.U.SG.RC, CR.BB.U.SG.RC.PC CR.BB.U.SGR.RB, CR.BB.U.SGR.RB.PC, CR.BB.U.SGR.RC, CR.BB.U.SGR.RC.PC Models Vertical: CR.BB.V.AG.RB, CR.BB.V.AG.RB.PC, CR.BB.V.FG.RB, CR.BB.V.FG.RB.PC CR.BB.V.SG.RB, CR.BB.V.SG.RB.PC, CR.BB.V.SGR.RB, CR.BB.V.SGR.RB.PC A guide on the use, care and maintenance of your quality Culinaire product Revision: 02 - 8/03/2021 - A...
- Page 2 Page Intentionally Left Blank Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 1...
- Page 3 Cleaning and Maintenance Your New Culinaire Product � � � � � � � � � � � � � � � � � � � 3 Cleaning � � � � � � � � � � � � � � � � � � � � � � � � � � � 20 Cleaning and Maintenance Schedule Australia and New Zealand Warranty �...
-
Page 4: Your New Culinaire Product
Thank you for choosing this quality Culinaire product� All Culinaire products are designed and manufactured to meet the needs of food service professionals� By caring for and maintaining your new Culinaire product in accordance with these instructions, will provide many years of reliable service�... -
Page 5: Warranty And Registration
Introduction Warranty & Registration Australia and New Zealand Warranty Warranty Period All Stoddart manufactured and distributed products are covered by Stoddart’s standard Australia and New Zealand Product Warranty (minimum 12 month on-site parts and labour, terms and conditions apply)� Further to this standard warranty, certain products have access to an extended warranty�... -
Page 6: Product Overview
CAUTION This unit includes refrigeration components. Cold surfaces can burn DO NOT touch these surfaces Code Explanation = Culinaire Refrigerated = Back Bar = Under Counter = Aluminium Framed Glass Door = Frameless Glass Door = Stainless Steel Framed Glass Door... - Page 7 Installation Setting Up WARNING Improper installation, adjustments, alterations, service or maintenance can cause property damage, injury or death. Handling • Use suitable means to move the unit; - For smaller items use two people - For large items a fork lift, pallet trolley or similar (the forks should reach completely beneath the pallet) Unpacking •...
-
Page 8: Refrigeration Connections
Installation Refrigeration Connections IMPORTANT This refrigeration system must be installed in accordance with local refrigeration standards Pre-Installation Pressure Test • All refrigeration lines are pressurised with nitrogen before leaving the factory� Exported units are de-pressurised before shipping to a country other than Australia •... - Page 9 Installation Remote Unit Leak Testing Diagram START Connect the Using a Close the pressure gauge to soapy Check all pressure gauge the pipe work and solution pipes are and note the fill with dry check all the fully welded. pressure nitrogen to joints for reading.
- Page 10 Installation Climate Classes Test room Climatic classes & classifi cations indicated on rating labels are specifi ed in ISO-23953-2 (& AS-1731) e�g� Climatic Class: • 3=25°C @ 60% humidity, • 4=30°C @ 55% humidity & • 5=40 °C @ 40% humidity� The cabinet classifi cation shall be given by the combination of climate class and M-package temperature class�...
-
Page 11: Electrical Connection
Installation Electrical Connection WARNING This unit must be installed in accordance with AS/NZS 60335.1 Some procedures in this manual require the power to the equipment to be turned off and isolated. Turn the power OFF at the power point and unplug the power supply lead by the plug body. -
Page 12: Technical Specifications
Specification Technical Specifications Code Explanation = Culinaire Refrigerated = Back Bar = Under Counter = Aluminium Framed Glass Door = Frameless Glass Door = Stainless Steel Framed Glass Door = Stainless Steel Framed Glass Door Recessed Handle = Remote Control Box... - Page 13 Specification 700mm 960mm Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 12...
- Page 14 Specification CR.BB.U.xx.RC.x SPECIFICATIONS Model CR.BB.U.AG.RC.2 / CR.BB.U.AG.RC.PC.2 CR.BB.U.AG.RC.3 / CR.BB.U.AG.RC.PC.3 CR.BB.U.AG.RC.4 / CR.BB.U.AG.RC.PC.4 CR.BB.U.FG.RC.2 / CR.BB.U.FG.RC.PC.2 CR.BB.U.FG.RC.3 / CR.BB.U.FG.RC.PC.3 CR.BB.U.FG.RC.4 / CR.BB.U.FG.RC.PC.4 CR.BB.U.SG.RC.2 / CR.BB.U.SG.RC.PC.2 CR.BB.U.SG.RC.3 / CR.BB.U.SG.RC.PC.3 CR.BB.U.SG.RC.4 / CR.BB.U.SG.RC.PC.4 CR.BB.U.SGR.RC.2 / CR.BB.U.SGR.RC.PC.2 CR.BB.U.SGR.RC.3 / CR.BB.U.SGR.RC.PC.3 CR.BB.U.SGR.RC.4 / CR.BB.U.SGR.RC.PC.4 Width 1450mm 1970mm...
- Page 15 Specification 700mm 960mm Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 14...
- Page 16 Specification CR.BB.V.xx.RC.x SPECIFICATIONS Model CR.BB.V.AG.RB.2 / CR.BB.V.AG.RB.PC.2 CR.BB.V.AG.RB.3 / CR.BB.V.AG.RB.PC.3 CR.BB.V.AG.RB.4 / CR.BB.V.AG.RB.PC.4 CR.BB.V.FG.RB.2 / CR.BB.V.FG.RB.PC.2 CR.BB.V.FG.RB.3 / CR.BB.V.FG.RB.PC.3 CR.BB.V.FG.RB.4 / CR.BB.V.FG.RB.PC.4 CR.BB.V.SG.RB.2 / CR.BB.V.SG.RB.PC.2 CR.BB.V.SG.RB.3 / CR.BB.V.SG.RB.PC.3 CR.BB.V.SG.RB.4 / CR.BB.V.SG.RB.PC.4 CR.BB.V.SGR.RB.2 / CR.BB.V.SGR.RB.PC.2 CR.BB.V.SGR.RB.3 / CR.BB.V.SGR.RB.PC.3 CR.BB.V.SGR.RB.4 / CR.BB.V.SGR.RB.PC.4 Width 1450mm 1970mm...
- Page 17 Specification 3230mm 2710mm 2190mm 1670mm 1150mm TOP VIEW 180mm FRONT VIEW Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 16...
-
Page 18: Control Panel
Operation Control Panel Lights ON/OFF Light Dimmer Glass Heater Power ON/OFF Refrigerator Temperature Adjustment Initial Start-up & Operation IMPORTANT This unit is not designed to cool down products, it only maintains them at the regulated 2°C to 4°C serving temperature. Initial Start Up •... - Page 19 Operation Loading Restrictions • Air vents must NOT be covered • There should NOT be any overhang of products on the shelves • Remove some products if the shelves are flexing or bending • Allow air space around all products for even cooling and efficient operation of the refrigerator� Leave an air space of at least 50mm above products on the top shelf and 40mm should be maintained below the shelves for air circulation Defrost Cycle •...
-
Page 20: Temperature Adjustment
Operation Temperature Adjustment • The “Refrigerator” temperature can be set between 2°C and 4°C� How to set the temperature is shown below • Different modes require different temperatures • The temperature probe only measures the temperature of the water/air, NOT the food temperature KEY FUNCTIONS: To display target set point;... -
Page 21: Cleaning And Maintenance
Cleaning and Maintenance Cleaning Cleaning and Maintenance Schedule • Daily cleaning is required for the unit� This will help to maintain and prolong the efficiency of your unit • The unit should be cleaned at the end of each work day Materials Required •... - Page 22 Cleaning and Maintenance Refrigerator 1� Isolate the unit from the power supply 2� Remove metal shelves/racks/vent covers and wash separately in a dishwasher or kitchen sink, thoroughly wipe dry after cleaning, DO NOT allow to air dry 3� Using a good quality nylon brush remove crumbs and small food items 4�...
-
Page 23: Troubleshooting
Cleaning and Maintenance Troubleshooting • If any faults/issues occur with the unit, follow the below troubleshooting procedures • If the troubleshooting procedures do not correct the problem, contact the Stoddart Service Department WARNING Technician tasks are only to be completed by qualified service people. - Page 24 Cleaning and Maintenance Disposal If the appliance is no longer of use, please dispose in an environmentally correct way� Contact a qualified service technician: • To recover all refrigerant • To remove the compressor or remove the oil from the compressor The distributor / retailer can contact their local metal recycling centre to collect the remaining cabinet, shelves, etc�...
