SHORT USER'S MANUAL
Description of the washing
FULL MANUAL HERE: http://docs.hotpoint.eu/default.cfm
machine and starting a wash cycle
Please input code "FMSL 603 EU" into box "Find documents through a Commercial Code".
Control panel
GB
Detergent dispenser drawer
Detergent dispenser drawer: used to dispense
detergents and washing additives (see "Detergents and
laundry").
ON/OFF button: switches the washing machine on and off.
WASH CYCLE knob: programmes the wash cycles. Du-
ring the wash cycle, the knob does not move.
FUNCTION buttons with indicator light: used to select the
available functions. The indicator light corresponding to the
selected function will remain lit.
TEMPERATURE knob: sets the temperature or the cold
wash cycle (see "Personalisation").
SPIN SPEED knob: sets the spin speed or exclude the
spin cycle completely (see "Personalisation").
WASH CYCLE PROGRESS/DELAY TIMER indicator
lights: used to monitor the progress of the wash cycle.
The illuminated indicator light shows which phase is in
progress.
If the Delay Timer function has been set, the time remaining
until the wash cycle starts will be indicated (see next page).
DOOR LOCKED indicator light: indicates whether the
door may be opened or not (see next page).
1
18
ON/OFF
button
TEMPERATURE
WASH CYCLE
knob
START/PAUSE button with indicator light: starts or tem-
porarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash orange,
while the indicator light for the current wash cycle phase
will remain lit in a fixed manner. If the DOOR LOCKED
indicator light is switched off, the door may be opened.
To start the wash cycle from the point at which it was inter-
rupted, press this button again.
Standby mode
This washing machine, in compliance with new energy sa-
ving regulations, is fitted with an automatic standby system
which is enabled after about 30 minutes if no activity is
detected. Press the ON-OFF button briefly and wait for the
machine to start up again.
WASH CYCLE PROGRESS/
DELAY TIMER
SPIN SPEED
knob
knob
FUNCTION
buttons with
indicator lights
indicator lights
DOOR
LOCKED
indicator light
START/PAUSE
button with indicator
light
