Quick Setup Guide
DCP-1000

THANK YOU!

CONGRATULATIONS ON PURCHASING THE ULTIMATE
BROTHER MACHINE.
WE ARE SURE YOU WILL BE THRILLED WITH THE
CONVENIENT WAY YOUR NEW MACHINE PERFORMS SO MANY
TASKS WITH DAZZLING RESULTS!
Follow these simple instructions in numerical order.
For more details, press Reports and
your Owner's Manual.
If you cannot solve a problem:
Refer to Frequently Asked Questions (FAQs) on Brother World
Wide Web;
URL: http://solutions.brother.com
Call Brother Customer Service at:
USA: 1-800-284-4329 (9AM-5PM EST)
1-800-284-3238 (TTY service for the
hearing impaired)
In Canada: 1-877-BROTHER (8AM-8PM EST)
1-514-685-6464 (in Montreal)
2

Install the Drum Unit

A. Unpack the drum unit assembly, and gently
rock it from side to side five or six times to
distribute the toner evenly inside the cartridge.
To prevent damage to the drum, do not
expose it to light for longer than a few
minutes.
Do NOT remove the clear plastic starter
sheet-this will be ejected while the DCP is
warming up.
Starter Sheet
4

Load Paper

A. Adjust the guides to the position for the paper
size you are using.
B. Fan the paper well.
C. Push down the paper lever. Load the paper
(with the lever down). Make sure the print side
is toward the DCP and the paper level is
stacked below the paper mark. The feeder can
hold up to 200 sheets of paper, or up to 10
envelopes.
1
on your machine or see
B. Open the scanner cover of the machine by
pulling the lever toward you and lifting the
cover.
C. Holding the drum unit by its handles, insert it
into the DCP.
D. Close the scanner cover.
Load the paper
with the lever down

Packing List

Power Cord
Cable Tie
Filter Core for
USB Cable
Filter Core for
Bi-directional
IEEE 1284
CD-ROM
Drum Unit Assembly
With Free Starter
Toner Cartridge
(Up to 1000 pages)
Keep the packing materials for possible future transport. If you do not pack the machine properly, it may
void your warranty.
3
A.
B.
C.
5
Press and slide
Turn the power switch OFF.
– 1 –
Paper
Support
Attach the Plastic Supports
and Pull out the Paper Tray
Attach the plastic paper
support to the
multi-purpose sheet feeder.
Pull out the paper tray and
the extension.
If your paper size is A4 or
Letter, unfold the paper
stopper by pulling it toward
you.
Install Power Cord
Do Not connect the Parallel or USB Cable.
Software
License
Agreement
Accessory
Order Form
Owner's Manual
Warranty
Registration
(For USA Only)
Quick Setup Guide
(For legal paper)
(For A4/Letter paper)
version B
