X1000-4K
Smart LED Soundbar Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.
Model No. VS17679
P/N: X1000-4K

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic VS17679

Summary of Contents for ViewSonic VS17679

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
  • Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.

  • Page 3: Safety Precautions

    Safety Precautions following Safety Precautions before you start using the projector. Please read the • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Allow at least 20“ (50 cm) clearance around the projector to ensure proper ventilation.
  • Page 4 (UPS). • If smoke, an abnormal noise, or a strange odor is present, immediately switch the projector off and call your dealer or ViewSonic®. It is dangerous to continue using the projector. • Use only attachments/accessories specified by the manufacturer.
  • Page 5 Safety Precautions - Ceiling Mounting Please read the following Safety Precautions before you start using the projector. If you intend to mount the projector on the ceiling, it is strongly recommended that you use a proper fitting projector ceiling mount kit and that you ensure it is securely and safely installed.

  • Page 6: Table Of Contents

    Contents Safety Precautions ............3 Introduction ..............9 Features ........................9 Package Contents ....................10 Product Overview ....................11 Projector ........................ 11 Connection Ports ....................12 Remote Control ..................... 14 Initial Setup ............... 16 Choosing a Location - Projection Orientation ............16 Projection Dimensions ..................17 Mounting the Projector ..................18 Making Connections ..........
  • Page 7 Using the Projector ............ 32 Starting Up the Projector ..................32 First Time Activation .....................32 Image Focus ......................32 Preferred Language ....................33 Projection Orientation ..................33 Network Settings ....................34 Source Input ......................34 Selecting an Input Source ..................35 Adjusting the Projected Image ................36 Adjusting the Projector's Height and Projection Angle .........
  • Page 8 Appendix ..............84 Specifications ......................84 Timing Chart ......................86 HDMI/USB C PC Timing ..................87 3D Support Timing ....................89 IR Control Table ....................90 Glossary ........................91 Troubleshooting ....................94 Maintenance......................95 General Precautions ....................95 Cleaning the Lens ....................95 Cleaning the Case ....................95 Storing the Projector .....................

  • Page 9: Introduction

    Introduction Combining stunning 4K resolution with smart streaming functionality, the ViewSonic® X1000-4K is a dark room projector. With an ultra short throw lens it is easy to install in the home. Additionally, it features multiple HDMI ports and rich connectivity allowing users to stream content from their favorite providers.

  • Page 10: Package Contents

    Package Contents X series Smart LED Soundbar Projector Quick Start Guide Snabbstartsguide Vodič za brzo pokretanje а а а а クイックスタートガイド Ghid de pornire rapidă Guide de démarrage rapide Első lépések Schnellstarthandbuch Οδηγόσ γρήγορησ εκκίνησησ Guía de inicio rápido Pika-aloitusopas Guida introduttiva Úvodní...

  • Page 11: Product Overview

    Product Overview Projector Front USB 1 (3.0) USB 2 (2.0) HDMI 1 AUDIO AUDIO 5V/2A 5V/1.5A USB C HDCP 2.2 Speaker Speaker IR Sensor Rear WiFi DONGLE SUBWOOFER OUT HDMI 2 HDMI 3 S/PDIF SERVICE AUDIO OUT HDCP 2.2 HDCP 2.2 Sides Adjustment Foot Adjustment Foot...

  • Page 12: Connection Ports

    Connection Ports Side I/O USB 1 (3.0) USB 2 (2.0) HDMI 1 AUDIO AUDIO 5V/2A 5V/1.5A USB C HDCP 2.2 USB 1 (3.0) USB 2 (2.0) USB C HDMI 1 AUDIO AUDIO 5V/2A 5V/1.5A HDCP 2.2 Port Description USB (5V/2A Out) USB 3.0 Type-A port (USB Reader - FAT32/NTFS¹) USB (5V/1.5A Out) USB 2.0 Type-A port (USB Reader - FAT32/NTFS¹)
  • Page 13 Rear I/O WiFi DONGLE HDMI 2 HDMI 3 S/PDIF SERVICE SUBWOOFER OUT AUDIO OUT HDCP 2.2 HDCP 2.2 WiFi DONGLE SUBWOOFER OUT HDMI 2 HDMI 3 S/PDIF SERVICE AUDIO OUT HDCP 2.2 HDCP 2.2 Port Description AUDIO OUT / SUBWOOFER OUT Audio signal output socket (3.5 mm jack) HDMI 2¹...

  • Page 14: Remote Control

    Remote Control Button Description Power Turns the projector On or Off Displays the input source selection Source bar. Focus Automatically focus the image. Bluetooth Launch Bluetooth search. Confirms the selection. Up/Down/ Navigates and selects the desired Left/Right menu items and make adjustments. Setting Displays the Setting menu.
  • Page 15 Remote Control - Receiver Range To ensure proper function of the remote control follow the steps below: 1. The remote control must be held at an angle within 30° perpendicular to the projector’s IR remote control sensor(s). Approx. 30° 2. The distance between the remote control and the sensor(s) should not exceed 8 m (26 ft.) NOTE: ...

  • Page 16: Initial Setup

    Initial Setup This section provides detailed instructions for the initial set up your projector. Choosing a Location - Projection Orientation Personal preference and room layout will decide the installation location. Consider the following: • Size and position of your screen. •...

  • Page 17: Projection Dimensions

    Projection Dimensions • 16:9 Image on a 16:9 Screen NOTE:  • (e) = Screen (f) = Center of Lens • The distance from the center of the lens to the rear of the projector is 17.35 cm (6.83”). 16:9 Image on a 16:9 Screen (b) Projection (a) Screen Size (c) Image Height...

  • Page 18: Mounting The Projector

    NOTE:  If you buy a third party mount, please use the correct screw size. Screw size can vary depending on the thickness of the mounting plate. 1. To ensure the most secure installation, please use a ViewSonic® wall or ceiling mount.

  • Page 19: Making Connections

    Making Connections This section guides you on how to connect the projector with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the projector. 2. Plug the power cord into a power outlet. NOTE: ...

  • Page 20: Connecting To External Devices

    Connecting to External Devices HDMI Connection Connect one end of an HDMI cable to the HDMI port of your video device. Then connect the other end of the cable to the HDMI 1/2/3 port (each support HDCP 2.0/HDMI 2.2) of your projector. NOTE: ...

  • Page 21: Audio Connection

    Audio Connection You can connect to various external sound delivery devices via the Audio Out, Audio In, Subwoofer Out, and S/PDIF ports. • To play music with Audio In: select Bluetooth > Bluetooth Speaker • To use Subwoofer Out: select Settings > Advanced Setting > harman/kardon > Internal Speaker >...

  • Page 22: Usb And Network Connection

    USB and Network Connection Just like any PC, it is easy to connect various USB devices, dongles, and networking devices. USB-C Connection Connect one end of a USB Type-C cable to the USB-C port of your device. Then connect the other end of the cable to the USB-C port of your projector. NOTE: ...

  • Page 23: Wireless Screen Mirroring

    3. “ViewSonic PJ-XXXX” will now be visible, select it. NOTE:  Some Android devices support direct “Casting”. If your device does, go to the Casting feature and choose “ViewSonic PJ-XXX” from the list of available devices. You can also scan the FAQ QR code and follow the...

  • Page 24: Connecting To Networks

    Connecting to Networks Wi-Fi Connection To connect to a Wi-Fi network: 1. Insert the Wi-Fi dongle into the projector’s Wi-Fi dongle socket. 2. Go to: Home > Settings > Network Settings > Wi-Fi 3. Press Left or Right on the remote control to select Enable.
  • Page 25 4. Available Wi-Fi networks will then be displayed. Select one of the available Wi-Fi networks. 5. If you connect to a secure Wi-Fi network, you must enter the password when prompted.

  • Page 26: Custom Ssid

    Custom SSID 1. Ensure the Wi-Fi dongle is plugged into the projector’s Wi-Fi dongle socket. 2. Go to: Home > Settings > Network Settings > Wi-Fi 3. Press Left or Right on the remote control to select Enable. 4. From the available Wi-Fi networks list select Others and press OK on the remote control.
  • Page 27 6. Enter the password when prompted. NOTE:  It is recommended to let the system configure the network settings automatically by choosing Automatic for Configure IP.

  • Page 28: Wired Lan Connection

    Wired LAN Connection You can easily connect to wired Internet networks and customize the connection as well. 1. Plug the RJ45 cable into the LAN port of the projector, then ensure the other end is plugged into your wired Internet source. 2.

  • Page 29: Bluetooth Connection

    Bluetooth Connection Bluetooth Speaker The projector is equipped with Bluetooth that allows the user to connect their device wirelessly for audio playback. To connect and pair your device: 1. Go to: Home > Bluetooth. 2. Use the Left and Right directional buttons on the remote control to select Bluetooth Speaker or Bluetooth Pairing.
  • Page 30 4. A sound effect will be audible upon entering pairing mode. 5. Upon successful connection, another sound effect will be audible. NOTE:  • Once paired, if both the projector and your device are powered on they will automatically connect via Bluetooth. •...

  • Page 31: Bluetooth Out

    Bluetooth Out Connect the projector to external headphones or speakers that support Bluetooth. To connect and pair your device: 1. Go to: Home > Bluetooth. 2. Use the Left and Right directional buttons on the remote control to select the Bluetooth Out option.

  • Page 32: Using The Projector

    Using the Projector Starting Up the Projector 1. Ensure the projector’s power cord is properly connected to a power outlet. 2. Press the Power button to turn on the projector. NOTE:  The Status LED will be blue during startup. First Time Activation If the projector is activated for the first time, you will need to select your Preferred Language, Projection Orientation, Network Settings, and Source Input.

  • Page 33: Preferred Language

    Preferred Language Select the desired language and press OK to confirm the selection. Projection Orientation Select the preferred projection orientation and press OK to confirm the selection. For more information, see page 33.

  • Page 34: Network Settings

    Network Settings Select one of the available options. For more information, see page 24. Source Input Quickly access the Source Input menu by pressing the Down button on the remote control when at the Home Screen. Additionally, you can press the Source button on the remote control.

  • Page 35: Selecting An Input Source

    Selecting an Input Source The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. USB 1 (3.0) USB 2 (2.0) HDMI 1 AUDIO USB C AUDIO 5V/2A 5V/1.5A HDCP 2.2 WiFi DONGLE...

  • Page 36: Adjusting The Projected Image

    Adjusting the Projected Image Adjusting the Projector's Height and Projection Angle The projector is equipped with two (2) adjuster feet. Adjusting the feet will change the projector’s height and the vertical projection angle. Setting Up the Desired Image Size The included Distance Card can be used to determine the desired image size.

  • Page 37: Fine-Tuning The Image Clarity

    Fine-Tuning the Image Clarity You can improve the clarity of the image by pressing the Focus button, then using the Left and Right buttons on the remote control.

  • Page 38: Shutting Down The Projector

    Shutting Down the Projector 1. Press the Power button on the projector or remote control and the following message will appear: 2. Press the Up/Down buttons on the remote control to select Turn Off and press OK on the remote control. 3.

  • Page 39: Input Source Selected - On-Screen Display (Osd) Tree

    Input Source Selected - On-Screen Display (OSD) Tree After your input source is selected, you can adjust the Image Setting and Advanced menus. Main Menu Sub-menu Menu Option Image Setting Brightest Movie Gaming Color Mode User 1 User 2 TV-HDR Movie-HDR Pink Wall Color...
  • Page 40 Main Menu Sub-menu Menu Option Image Setting 2.35 Gamma sRGB Cubic Green Blue Primary Color Cyan Color Management Magenta Yellow (-/+, -50~50) Saturation (-/+, 0~100) Gain (-/+, 0~100) Full Light Source Level Dynamic Black 1 Dynamic Black 2 Test Pattern Reset Current Color Settings...
  • Page 41 Main Menu Sub-menu Menu Option Advanced Auto Aspect Ratio 16:9 16:10 Native Auto EOTF High Frame Interpolation High Auto HDMI Range Full Limited Auto Disable Frame Sequential 3D Sync Frame 3D Settings Packing Top-Bottom Side-by-Side Disable 3D Sync Invert Invert...
  • Page 42 Main Menu Sub-menu Menu Option Advanced Movie Music Audio Mode User 100Hz 500Hz 1500Hz harman/kardon 5000Hz 10000Hz Audio Volume (-/+, 0~50) Enable Mute Disable Enable S/PDIF Disable Full Light Source Level Dynamic 1 Dynamic 2 Source Resolution Information 3D Format HDR/HLG...
  • Page 43 Image Setting Menu To access the Image Setting menu: 1. Press Setting on the remote control. 2. Use the Up/Down buttons to select a menu.
  • Page 44 3. Then use the Left/Right buttons to enter the sub-menu(s) and/or adjust the settings. 4. Press the Return button to go to the previous menu or exit.
  • Page 45 Menu Option Description Color Mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal. Brightest Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, i.e.
  • Page 46 Menu Option Description Color Temp Select the color temperature setting. • 6500K: Maintains normal white coloring. • 7500K: A higher, cooler color temperature than 6500K. • 9300K: The highest color temperature; makes the image appear the most bluish-white. • User Color: Adjust red, green, and blue values as desired.
  • Page 47 Menu Option Description Color Only in permanent installations with controlled lighting Management levels such as: boardrooms, lecture halls, or home theaters should Color Management be considered. Yellow Green White Magenta Cyan Blue Color Management provides fine color control adjustment to allow for more accurate color reproduction, should you require it.
  • Page 48 Advanced Setting Menu To access the Advanced menu: 1. Press Setting on the remote control. 2. Press the Right button to access the Advanced menu.
  • Page 49 3. Use the Up/Down buttons to select a menu. 4. Then use the Left/Right buttons to enter the sub-menu(s) and/or adjust the settings. 5. Press the Return button to go to the previous menu or exit.
  • Page 50 Menu Option Description Aspect Ratio The Aspect Ratio is the ratio of the image width to the image height. With the advent of digital signal processing, digital display devices, like this projector, can dynamically stretch and scale the image output to a different aspect than that of the image input signal.
  • Page 51 Menu Option Description Aspect Ratio Native Projects the image as its original resolution and resizes it to fit within the display area. For input signals with lower resolutions, the projected image will be displayed in its original size. The projector supports HDR imaging. It can automatically detect the dynamic range of the source from the HDMI 1/2/3 ports, and optimize settings to reproduce contents under a wide range of light conditions.

  • Page 52: Operating The Projector

    Operating the Projector This section will introduce the Home Screen and its menus. Home Screen The Home Screen is displayed every time you start the projector. To navigate the Home Screen, simply use the directional buttons on the remote control. You can return to the main Home Screen at any time by pressing the Home button on the remote control, regardless of what page you are on.

  • Page 53: Home Screen - On-Screen Display (Osd) Menu Tree

    Home Screen - On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option File Management Apps Center Bluetooth Settings Disable SSID: Configure IP IP Address Wi-Fi Subnet Mask Enable Default Gateway Network DNS Server Settings Others Automatic Configure IP Manual IP Address xxx.xxx.xxx.xxx Wired LAN...
  • Page 54 Main Menu Sub-menu Menu Option Settings English French German Italian Spanish Russian 繁體中文 簡體中文 日本語 韓語 Swedish Language Dutch Turkish Czech Portuguese Thai Basic Settings Polish Finnish Arabic Indonesian Hindi Vietnam Greek Front Table Front Ceiling Projector Projection Rear Table Rear Ceiling Keystone Manual...
  • Page 55 Main Menu Sub-menu Menu Option Settings Disable Automatic Date & Time Enable Date Time Date & Time Time Zone 12 hours Time Format 24 hours Software Update Online Software Update Firmware by USB Upgrade Disable OTA Reminder Enable Software Version Home HDMI 1 Power On Source...
  • Page 56 Main Menu Sub-menu Menu Option Settings Disable 10 minutes Auto Power Off 20 minutes 30 minutes Disable 30 minutes 1 hour Smart Energy 2 hours Sleep Timer 3 hours 4 hours 8 hours 12 hours Enable Power Saving Disable Movie Music Audio Mode Advanced...
  • Page 57 Main Menu Sub-menu Menu Option Settings Disable High Altitude Mode Enable Advanced Reset Settings Settings Cancel Reset To Factory Default Cancel Light Source Hours System Version Memory Information Information Network Mac Address Wi-Fi Mac Address Serial Number Screen Mirroring Add App Add App Add App Add App...

  • Page 58: Menu Operations

    Menu Operations File Management Easily manage files and folders. 1. Select: Home > File Management. 2. Select a device on the source list: USB, Local Storage, etc. Use the direction buttons to select the desired file. Then press OK on the remote control to open the selected file.
  • Page 59 How to Edit a File 1. While in File Management, press and hold the OK button for three (3) seconds. 2. A check box will appear at the front of each file. Use the direction buttons and press OK to select one or more files. 3.
  • Page 60 How to Use Control Bar Buttons The Control Bar buttons will appear on screen if a video, music, or photo file are selected to be opened. Picture Video Music Back Back Back Play Rewind Play Next Play Pause Zoom in Pause Next Zoom out...
  • Page 61 Supported File Formats Supported Office formats: Item Indicators Able to open and read documents in doc/ doc/docx Document docx viewing xls/xlsx Able to open and read documents in xls/xlsx function ppt/pptx Able to open and read documents in ppt/pptx Able to open and read documents in pdf English, Simplified Chinese, Chinese (TW), Chinese (HK), Spanish (LA), French (EU), PT (EU), PT (BR), German, Russian, Italian,...
  • Page 62 Supported Photo formats: Format Type Maximum Resolution Progressive JPEG 7680 x 4320 .jpg/.jpeg Baseline JPEG 7680 x 4320 .bmp 9600 x 6400 .png 7680 x 4320 Supported External Connected Device formats: Support Size Device NTFS Format FAT32 Format exFAT (Max. Size) Read Write Read...

  • Page 63: Apps Center

    Apps Center View, launch, and uninstall Apps. 1. To view your Apps, select: Home > Apps Center. 2. Use the direction buttons to select the desired App. Then press OK on the remote control to launch the App. NOTE:  Press the Home button on the remote control to return to the Home Screen at anytime.
  • Page 64 To Uninstall Apps 1. Open the Apps Center by selecting: Home > Apps Center. 2. Use the directional buttons to select the desired App. 3. Press and hold OK on the remote control for three (3) seconds. The below dialogue box will appear: 4.

  • Page 65: Bluetooth

    Bluetooth The projector is equipped with Bluetooth that allows the user to connect their device wirelessly for audio playback. For more information, see page 29.

  • Page 66: Setting

    Setting Under Setting you can adjust Network, Basic, and Advanced Settings, Date & Time, Firmware Update, and view Information. Network Settings 1. Select: Home > Setting > Network Settings.
  • Page 67 2. Choose from one of the available options: Wi-Fi or Wired LAN. 3. To setup a Wireless or Wired LAN Connection, see “Connecting to Networks” on page 24.
  • Page 68 Basic Settings 1. Select: Home > Setting > Basic Settings. 2. Use the Up and Down buttons to select the desired option and press OK. Then use the Left and Right buttons to make adjustments or selections. 3. To return to a previous menu press the Return button.
  • Page 69 Menu Description Language Select your desired language. Projector Position Select the preferred projection position. Adjust trapezoidal screen image distortion. Keystone Keystone can be adjusted manually from -14 to 14. Adjust the focus of the screen image. Focus Use the Directional buttons on the remote control to adjust the focus.
  • Page 70 Date & Time Adjust Date, Time, Time Zone, and Time Format. NOTE:  The time is displayed in the top-right corner after connecting to the Internet. 1. Select: Home > Setting > Date & Time. 2. Use the Up and Down buttons to select the desired option and press OK. Then use the Left and Right buttons to make adjustments or selections.
  • Page 71 Menu Description Users can synchronize the date and time automatically after connecting to the Internet. Enable Automatic Date & Time Turn on synchronization. Disable Turn off synchronization. Select your desired location. Time Zone Select a different display time format. 12 Hours Time Format 12-hour clock.
  • Page 72 Firmware Upgrade Users can update the firmware by internet or USB, and check the version number. NOTE:  Do not unplug the power cord, USB, or disconnect from the Internet during the upgrading process. 1. Before entering the Firmware Upgrade menu, ensure the projector is connected to the Internet.
  • Page 73 2. Select Enter by pressing OK on the remote control. 3. The system will check the ViewSonic website (OTA) and display the below dialog message if there is new Firmware. 4. After selecting Yes, a progress bar will appear as the update process begins.
  • Page 74 Firmware Update by USB with FAT32 Format NOTE:  NTFS format, read only. 1. Download the latest version from the ViewSonic website and copy the file to a USB device. 2. Plug the USB into the projector, then go to: Home > Setting > Firmware Upgrade >...
  • Page 75 Advanced Settings 1. Select: Home > Setting > Advanced Settings. 2. Use the Up and Down buttons to select the desired option and press OK. Then use the Left and Right buttons to make adjustments or selections. 3. To return to a previous menu press the Return button.
  • Page 76 Menu Description Allows the user to enter the desired source directly Power On Source after turning on the projector. This projector supports CEC (Consumer Electronics Control) function for synchronized power on/off operation via HDMI connection. That is, if a device that also supports CEC function is connected to the HDMI input of the projector, when the projector’s power is turned off, the power of the connected...
  • Page 77 Menu Description Audio Mode • Movie: Default audio mode. • Music: Tuned for music playback. • User: Allows the user to customize the audio equalizer. NOTE:  In Custom mode, 100Hz, 500Hz, 1500Hz, 5000Hz, and 10000Hz can be selected. harmon/kardon Audio Volume Adjust the volume from 0 to 50.
  • Page 78 Menu Description Select the suitable power consumption of the LED. Full 100% Dynamic Black 1 Light Source Level See more dark scene details according to the brightness level of different scenes in the input content. Dynamic Black 2 High contrast performance according to the brightness level of different scenes in the input content.
  • Page 79 Menu Description Reset the Settings to default. NOTE:  Language, High Altitude Mode, Projector Position, Network Settings, All installed Reset Settings Apps in the Apps Center, Add App, Bluetooth, V Keystone, and Light Source Hours will remain unchanged. Factory reset. Reset to Factory Default NOTE: ...
  • Page 80 Information 1. Select: Home > Setting > Information. 2. View system status and information. NOTE:  Press the Home button on the remote control to return to the Home Screen at anytime.

  • Page 81: Screen Mirroring

    Screen Mirroring Mirror your personal device’s screen. To setup wireless Screen Mirroring, see page NOTE:  Ensure your device is connected to the same network as the projector.
  • Page 82 Adding Apps Add your favorite Apps to the Home Screen. 1. From the Home Screen, select Add App and then press OK on the remote control. 2. Use the directional buttons to select the desired App and press OK.
  • Page 83 3. Now your favorite App will appear on the Home Screen. Delete Apps From the Home Screen 1. From the Home Screen, select the App you want to delete and press and hold OK for three (3) seconds. 2. The message, “Do you want to Delete this application from My Favorites?” will appear.

  • Page 84: Appendix

    757 x 169 x 291 mm (W x H x D) (29.8” x 6.65” x 11.46”) Weight Physical 9.44 kg (20.79 lbs) Power 200W (Typical) Consumption < 0.5W (Standby) ¹ Please use the power adapter from ViewSonic® or an authorized source only.
  • Page 85 Projector Dimensions 757 mm (W) x 169 mm (H) x 291 mm(D) 169 mm 757 mm 291 mm...

  • Page 86: Timing Chart

    Timing Chart HDMI/USB C Video Timing Timing Resolution (dots) Refresh Rate (Hz) SDTV (480i) 720 x 480 SDTV (480p) 720 x 480 SDTV (576i) 720 x 576 SDTV (576p) 720 x 576 HDTV (720p) 1280 x 720 50 / 60 HDTV (1080P) 1920 x 1080...

  • Page 87: Hdmi/Usb C Pc Timing

    HDMI/USB C PC Timing Horizontal Dot Clock Resolution Refresh Rate (Hz) Frequency (KHz) Frequency (MHz) 59.940 31.469 25.175 72.809 37.861 31.500 640 x 480 37.500 31.500 85.008 43.269 119.518 61.910 52.500 720 x 400 70.087 31.469 28.3221 56.250 35.156 60.317 37.879 72.188 48.077...
  • Page 88 Horizontal Dot Clock Resolution Refresh Rate (Hz) Frequency (KHz) Frequency (MHz) 55.469 88.75 59.887 55.935 106.500 1440 x 900 74.984 70.635 136.75 84.842 80.430 1600 x 1200 59.883 64.674 1680 x 1050 59.954 65.290 146.250 1920 x 1200 59.950 74.038 3840 x 2160 67.5 3840 x 2160...

  • Page 89: 3D Support Timing

    3D Support Timing HDMI 3D (BlueRay 3D with info frame) Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) Support Frame Packing 16:9 23.98/24 1080p 1920 x 1080 16:9 50/59.94/60 720p 1280 x 720 Side by Side 16:9 50/59.94/60 1080i 1920 x 1080 Top and Bottom 16:9 23.98/24...

  • Page 90: Ir Control Table

    IR Control Table Address Code Inverse Function Byte 1 Byte 2 Byte 3 Byte 4 Down Left Right Mute Home Play/Pause Exit Menu/Setting Source Power On/Off Focus Bluetooth Previous Next Volume + Volume -...

  • Page 91: Glossary

    Glossary This section describes the standard glossary of terms used in all projector models. All terms are listed in alphabetical order. NOTE: Some terms may not be applicable to your projector. Aspect Ratio Refers to the ratio of the image width to the image height. Brightest Mode Maximizes the brightness of the projected image.
  • Page 92 Dynamic Black This feature gives more depth to your image by smoothly adjusting the light and signal output to create a stunning high contrast ratio. Bright scenes appear crisp and clear, while dark scenes remain detailed with deep blacks and exceptional light and shade detail. Focus Improve the clarity of the projected image.
  • Page 93 Keystone The distortion of an image caused by projecting it onto an angled surface. Light Source Level Use Normal or Eco mode to adjust the brightness level and power consumption. Movie Mode A Picture Mode appropriate for playing colorful movies, video clips from digital cameras, or DVs through the PC input.

  • Page 94: Troubleshooting

    Troubleshooting This section describes some common problems that you may experience when using the projector. Problem or Issue Possible Solutions The projector does not • Ensure the power cord is properly attached to the turn on projector and to the power outlet. •...

  • Page 95: Maintenance

    • ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the lens or case. Some chemical cleaners have been reported to damage the lens and/or case of the projector. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

  • Page 96: Led Indicators

    LED Indicators Light Status and Description Power Stand-by mode (5 sec.) (< 0.5W) Blue Powering up Blue Normal operation Green Bluetooth Mode...

  • Page 97: Regulatory And Service Information

    Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 98: Ce Conformity For European Countries

    This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This device complies with RSS 210 of Industry Canada.

  • Page 99: Declaration Of Rohs2 Compliance

    Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance Proposed Maximum...

  • Page 100: Indian Restriction Of Hazardous Substances

    Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...

  • Page 101: Copyright Information

    ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). As an ENERGY STAR® partner, ViewSonic® Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein;...

  • Page 102: Customer Service

    For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/...

  • Page 103: Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
  • Page 104 (e) the serial number of the product. 3. Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. 4. For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
  • Page 105 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.

  • Page 106: Mexico Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 107 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based...
  • Page 108 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
  • Page 109 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
