LS900WU
DLP Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specific languages using the Regional selection
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS17642

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS900WU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ViewSonic LS900WU

Summary of Contents for ViewSonic LS900WU

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
  • Page 2 Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the follow- ing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this unit near water. Clean with a soft, dry cloth. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s instructions.
  • Page 4 Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance...
  • Page 5 Product Registration To fulfill possible future product needs, and to receive additional product information as it becomes available, please visit your region section on ViewSonic’s website to register your product online. Registering your product will best prepare you for future customer service needs.

  • Page 6: Table Of Contents

    Table of contents Important safety Using the CEC function..... 41 Using the 3D functions ...... 41 instructions .......2 Using the projector in standby mode . 42 Introduction......7 Adjusting the sound ......42 RJ45 ........... 43 Projector features ......... 7 Preparing Email Alerts ...... 48 Shipping contents.........

  • Page 7: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before you operate your projector.
  • Page 8 Do not place liquids near or on the projector. Liquids spilled into the projector may cause it to fail. If the projector does become wet, disconnect it from the power supply's wall socket and call your local service center to have the projector serviced. This product is capable of displaying inverted pictures for ceiling mount installation.
  • Page 9 Laser warning This symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the instructions are closely followed. Class 3R laser product This Laser Product is designated as Class 3R during all procedures of operation. LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
  • Page 10 Product labels Below drawing show the label’s location. Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007 LASER RADIATION AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT Emitted wavelength : 450-460 nm Max.
  • Page 11 Location of laser aperture Below drawing is the laser aperture location. Be careful not to let the eye see the light directly. Interlock switches This machine has 1 (Top cover) Interlock switches to protect the laser light Leakage. Will power-off the system individually when the top cover is removed.

  • Page 12: Introduction

    Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • Power saving function decreasing the power consumption of the light source by up to 70% or 80% when no input signal can be detected for a set period of time •...

  • Page 13: Shipping Contents

    The supplied accessories will be suitable for your region, and may differ from those illustrated. Projector Power Cord VGA Cable ViewSonic Corporation (US/Canada/Latin America) : www.viewsonic.com/support/product-registration : 14035 Pipeline Ave. Chino, CA 91710, USA : 909-468-1240 United States Latin America 1-800-688-6688 http://www.viewsonic.com/la/...

  • Page 14: Projector Exterior View

    Projector exterior view Front IR remote sensor Front/upper side Projection lens Focus ring Zoom ring LENS SHIFT UP/DOWN LENS SHIFT RIGHT/LEFT Vent (air inlet) External control panel (See "Projector" on page 10 details.) Power button and top IR remote sensor AC power cord inlet HDMI 1 port HDMI 2 port...

  • Page 15: Controls And Functions

    Controls and functions Projector 2 9 2 10 2 11 2 12 LENS SHIFT UP/DOWN (Menu up) Rotate to move lens up or down. Selects the desired menu items and makes adjustments. Focus ring Adjusts the focus of the projected image. (Keystone key) Zoom ring Manually corrects distorted images...
  • Page 16 Power indicator light Temperature indicator light Lights up or flashes when the projector is Lights up red if the projector's temperature under operation. becomes too high. Power Light source indicator light Toggles the projector between standby Indicates the status of the light source. mode and Power ON.
  • Page 17 Remote control (Keystone keys) Power Manually corrects distorted images Toggles the projector between standby resulting from an angled projection. mode and Power ON. Left/ Right/ Down HDMI 1 Selects HDMI 1 source for display. Selects the desired menu items and makes adjustments.
  • Page 18 HDMI 2 (Information) Selects HDMI 2 source for display. Displays the Information menu. Source PgUp (Page Up)/1 Displays the source selection bar. Operates your display software program Blank (on a connected PC) which responds to page up commands (like Microsoft Hides the screen picture.
  • Page 19 Remote control code The projector can be assigned to 8 different remote control codes, 1 to 8. When several adjacent projectors are in operation at the same time, switching the remote control codes can prevent interference from other remote controls. Set the remote control code for the projector first before changing that for the remote control.
  • Page 20 Replacing the remote control batteries Remove the cover by sliding it in the direction indicated by the arrow. Insert two new AAA batteries (check the polarity). Replace the cover. WARNING • Avoid leaving the remote control and batteries in an excessive heat or humid environment like the kitchen, bathroom, sauna, sunroom or in a closed car.

  • Page 21: Positioning Your Projector

    Positioning your projector Choosing a location Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.

  • Page 22: Projection Dimensions

    Projection dimensions LS900WU (WUXGA) The "screen" mentioned below refers to the projection screen usually consisting of a screen surface and a support structure. • 16:10 image on a 16:10 screen • 16:10 image on a 4:3 screen (e): Screen (f): Center of lens...
  • Page 23 16:10 image on a 4:3 Screen (a) Screen (b) Projection distance (d) Vertical offset Size (c) Image height min. max. min. max. inch inch inch inch inch inch 1372 1262 2085 1651 1519 2510 1930 1776 2934 2210 2033 3359 1105 2489 2290...

  • Page 24: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 25: Connecting A Computer Or A Monitor

    Connecting a computer or a monitor Connecting a computer Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer. Connect the other end of the VGA cable to the COMPUTER IN signal input socket on the projector.
  • Page 26 video natively, so if available on your devices, this should be your connection method of choice in preference to (composite) video. "Connecting a Component Video source device" on page 22 for how to connect the projector to a component video device. Least video quality Composite Video is an analog video and will result in a perfectly acceptable, but less than optimal result from your projector, being the least video quality of the available methods...
  • Page 27 LAN port and RS-232C port are disabled when Network Settigs to the HDBaseT and RS232 settings to HDBaseT channel. Use LAN cables of up to 100m long. Exceeding this length, the image will be deteriorated, and can experience malfunction on LAN transmission. HDBaseT BEST PRACTICE: i.

  • Page 28: Playing Sound Through The Projector

    Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. Take a Video cable and connect one end to the composite Video output socket of the Video source device.

  • Page 29: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). (If available) Remove the lens cap. Press Power to start the projector. As soon as the light source lights up, a "Power On Ring Tone"...

  • Page 30: Using The Menus

    Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. The OSD screenshots below are for reference only, and may differ from the actual design. Below is the overview of the OSD menu. Main menu icon Highlight Status...

  • Page 31: Utilizing The Password Function

    Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. For details of the OSD menu operation, please refer to "Using the menus"...
  • Page 32 Entering the password recall procedure Continuous press Auto Sync on the remote or Auto on the key pad for 8 times. The projector will display a coded number on the screen. Write down the number and turn off your projector. Seek help from the local service center to decode the number.

  • Page 33: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. Be sure the Quick Auto Search function in the SYSTEM menu is On if you want the projector to automatically search for the signals.

  • Page 34: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with two adjuster foot. It changes the image height and vertical projection angle. Screw the adjuster foot to fine tune the angle until the image is positioned where you want it. If the projector is not placed on a flat surface or the screen and the projector are not perpendicular to each other, the projected image becomes trapezoidal.
  • Page 35 Adjusting the horizontal image position With the lens horizontal image position can be adjusted to a maximum of 5% for 1080P and 5% for WUXGA of the image width. Note that the maximum horizontal image height adjustment can be limited by the vertical image position. For example it is not possible to achieve the maximum horizontal image position if the vertical image position is at maximum.

  • Page 36: Adjusting Projected Image Position Using Lens Shift

    Adjusting projected image position using lens shift Vertical Horizontal Lens Shift Knob Lens Shift Knob The Lens Shift feature provides a lens shift function that can be used to adjust the position of the projected image either horizontally or vertically within the range detailed below. Shift is a unique system that provides lens shift while maintaining a much higher ANSI contrast ratio than traditional lens shift systems.
  • Page 37 Fine-tuning the image clarity Adjust the projected image to the size If necessary, sharpen the image by rotating that you need using the zoom ring. the focus ring. Correcting keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection.

  • Page 38: Magnifying And Searching For Details

    Adjusting 4 corners Using the OSD menu Open the OSD menu and go to the DISPLAY > Corner Adj. menu. It will show 4 corner adjustmant OSD on screen. To select the corner you want to adjust than the selected area will show gray color Two degree selection couble be adjust To save the settings before you want to close the OSD menu How to reset the corner adj.:...

  • Page 39: Selecting The Aspect Ratio

    Selecting the aspect ratio The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and computers are in 4:3 ratio, and digital TV and DVDs are usually in 16:9 ratio. With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input signal.

  • Page 40: Optimizing The Image

    The image is projected as its original Native: resolution, and resized to fit within the display area. For input signals with lower resolutions, 4:3 picture the projected image will display smaller than if resized to full screen. You could adjust the zoom setting or move the projector away from the screen to increase the image size if necessary.
  • Page 41 Using Screen Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Screen Color feature can help correct the projected picture’s colors to prevent possible color difference between the source and projected pictures. To use this function, go to the DISPLAY >...
  • Page 42 Adjusting Brilliantcolor Go to the IMAGE > ADVANCED > Brilliantcolor menu and press This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in the projected picture. It enables a greater than 50% brightness increase in mid-tone images, which are common in video and natural scenes, so the projector reproduces images in realistic and true colors.
  • Page 43 Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. Color management provides fine color control adjustment to allow for more accurate color reproduction, should you require it. If you have purchased a test disc which contains various color test patterns and can be used to test the color presentation on monitors, TVs, projectors, etc., you can project any image from the disc on the screen and enter the Color Management menu to make adjustments.

  • Page 44: Setting The Presentation Timer

    Setting the presentation timer Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Go to the BASIC > Presentation Timer menu. Press Enter to display the Presentation Timer page. Highlight Timer Period and decide the time period by pressing .

  • Page 45: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can press BLANK to hide the screen image. Press any key on the projector or remote control to restore the image. The word 'BLANK' appears at the lower right corner of the screen while the image is hidden. >...

  • Page 46: Using The Cec Function

    Using the CEC function This projector supports CEC (Consumer Electronics Control) function for synchronized power on/off operation via HDMI connection. That is, if a device that also supports CEC function is connected to the HDMI input of the projector, when the projector’s power is turned off, the power of the connected device will also be turned off automatically.

  • Page 47: Using The Projector In Standby Mode

    Using the projector in standby mode Some of the projector functions are available in standby mode (plugged in but not turned on). To use these functions, be sure you have turned on the corresponding menus under POWER MANAGEMENT > Standby Settings, and the cable connections are correctly made.

  • Page 48: Rj45

    Microphone Volume To adjust the microphone sound level, Open the OSD menu and go to the BASIC > Audio Settings. Press to highlight Microphone Volume and press to select a desired sound level. Turning off the Power On/Off Ring Tone Open the OSD menu and go to the BASIC >...
  • Page 49 This projector is compliant to support Extron device(s) for reference. http://www.extron.com/ This projector supports all commands of PJLink Class1 (Version 1.00). http://pjlink.jbmia.or.jp/english/ For more detail of information about the diverse types of external devices which can be connected to the LAN/RJ45 port and remote/control the projector, as well as the related control commands supporting for each external device, kindly please get contact with the Support-Service team directly.
  • Page 50 Right-click on Local Area Connection, and select Properties. In the Properties window, select the Networking tab, and select Internet Protocol (TCP/IP). Click Properties. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK.
  • Page 51 Press the MENU button on the projector. Select Advanced > Network Setting > Wired LAN. After getting into Wired LAN, input the following: • DHCP: Off • IP Address: 10.10.10.10 • Subnet Mask: 255.255.255.0 • Gateway: 0.0.0.0 • DNS Server: 0.0.0.0 Press ENTER / .
  • Page 52 Category Item Input Length IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm more information, please visit http://www.crestron.com.

  • Page 53: Preparing Email Alerts

    Preparing Email Alerts Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex-ample, Microsoft Internet Explorer v6.01/v8.0). From the Homepage of LAN/RJ45, click Alert Settings. By default, these input boxes in Alert Settings are blank.
  • Page 54 For Sending alert mail, input the following: • The SMTP field is the mail server for sending out email (SMTP protocol). This is a required field. • The To field is the recipient’s email address (for example, the projector administrator). This is a required field. •...

  • Page 55: Rs232 By Telnet Function

    RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector.
  • Page 56 (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then Enter key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows VISTA / 7 / 8 / 10 By default installation for Windows VISTA / 7 / 8 / 10, “TELNET” function is not included. But end-user can have it by way of “Turn Windows features On or Off”...
  • Page 57 Select Turn Windows features on or off to open. Have Telnet Client option checked, then press OK button. Specsheet for “RS232 by TELNET” : Telnet: TCP. Telnet port: 4661. (for more detail, kindly please get contact with the service agent or team) Telnet utility: Windows “TELNET.exe”...

  • Page 58: Shutting Down The Projector

    Shutting down the projector Press Power and a confirmation message is displayed prompting you. If you don't respond in a few seconds, the message will disappear. Press Power a second time. Once the cooling process finishes, a "Power Off Ring Tone" will be heard. Disconnect the power cord from the wall socket if the projector will not be used in an extended period of time.

  • Page 59: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.
  • Page 60 Timer Display Always/1 min /2 min/3 min/Never Timer Top-Left/Bottom-Left/Top-Right/ Position Bottom-Right 4. BASIC Presentation Timer Timer Counting Count Down/Count Up Direction Sound On/Off Reminder Start Yes/No Counting/Off Disable/5 min/10 min/15 min/20 min/25 Blank Timer min/30 min Message On/Off Pattern On/Off Splash Black/Blue/ViewSonic/Off Screen...
  • Page 61 Main menu Sub-menu Options Auto/Off/Frame Sequential/Frame 3D Sync Packing/Top-Bottom/Side-by-Side 3D Sync 3D Settings Disable/Invert Invert Save 3D Yes/No Settings HDMI Format Auto/RGB/YUV HDMI Settings HDMI Range Auto/Enhanced/Normal DHCP/IP Address/Subnet Mask/ Wired LAN Gateway/DNS Server/Standby LAN Control/Apply Network AMX Device On/Off Settings Discovery Control 4...
  • Page 62 Main menu Sub-menu Options Language Multi-language OSD selection Projector Front Table/Rear Table/ Position Rear Ceiling/Front Ceiling Menu Display 5 sec/10 sec/15 sec/20 sec/ Time 25 sec/30 sec Menu Settings Menu Center/Top-Left/Top-Right/ Position Bottom-Left/Bottom-Right High Altitude Off/On Mode Quick Auto SYSTEM Off/On Search Change...
  • Page 63 Description of each menu Function Description "Using Screen Color" on page 36 for details. Screen Color This function is only available when a PC input signal is selected. Aspect Ratio "Selecting the aspect ratio" on page 34 for details. Keystone "Correcting keystone"...
  • Page 64 Function Description Color Mode "Selecting a picture mode" on page 35 for details. Brightness "Adjusting Brightness" on page 36 for details. Contrast "Adjusting Contrast" on page 36 for details. "Selecting a Color Temperature" on page 37 "Setting a Color Temp preferred color temperature"...
  • Page 65 Function Description Computer Selecting Enable allows the projector to turn on automatically once the VGA signal is fed through the VGA cable. HDMI Selecting Enable allows the projector to turn on automatically once the HDMI signal is fed through the HDMI cable. Auto Power On "Using the CEC function"...
  • Page 66 Function Description 3D Settings "Using the 3D functions" on page 41 for details. HDMI Format "Changing HDMI input settings" on page 28 for details. Settings Wired LAN • DHCP: If the projector installation environment has the Dynamic Host Configuration Protocol server. You can set this function ON to let the projector get the auto ID from server.
  • Page 67 Function Description Light Source Mode • Normal: Brightness will be 100% when set to Normal mode. If the projection environment requires brighter picture, you can set the light source mode to Normal for the highest projection brightness. • Eco: When set to Eco mode, the brightness will be 80% of the normal brightness.
  • Page 68 Function Description Sets the language for the On-Screen Display (OSD) menus. See Language "Using the menus" on page 25 for details. Projector "Choosing a location" on page 16 for details. Position Menu Display Time Sets the length of time the OSD will remain active after your last key press.

  • Page 69: Maintenance

    Maintenance Care of the projector You need to keep the lens and/or filter (optional accessory) clean on a regular basis. Never remove any parts of the projector. Contact your dealer when any part of the projector needs replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface.

  • Page 70: Light Source Hours Information

    Light Source Hours information Getting to know the light source hours When the projector is in operation, the duration (in hours) of light source usage is automatically calculated by the built-in timer. To obtain the light source hour information: Open the OSD menu and go to the ADVANCED > Light Source Setting menu. Press Enter and the Light Source Settings page is displayed.
  • Page 71 Setting Power Saving The projector lowers the power consumption if no input source is detected after 5 minutes to prevent unnecessary waste of light source life. You can further decide if you would like the projector to turn off automatically after a set period of time. Open the OSD menu and go to the POWER MANAGEMENT >...
  • Page 72 Indicators Light Status & Description Blue Power events Light source Ready Start Flashing Cooling Flashing Case Open 7 blinks DMD Error 8 blinks Color Wheel Error 9 blinks Phosphor wheel error 9 blinks 1 blinks System events 1W MCU detects scaler stops working 2 blinks Thermal events Over Temperature T1...

  • Page 73: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the power There is no power from the power cord. outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 74: Specifications

    All specifications are subject to change without notice. • Not all models can be purchased in your region. General Product name DLP Projector Optical Resolution LS900WU: 1920 x 1200 WUXGA Display system 1-CHIP DMD Light source Laser Diode Electrical Power supply AC100–240V, 50–60 Hz (Automatic)

  • Page 75: Dimensions

    Environmental Requirements Operating temperature 5°C–40°C at sea level Operating relative 10%–90% (without condensation) humidity Operating altitude • 0–1499 m at 5°C–35°C • 1500–3000 m at 5°C–25°C (with High Altitude Mode on) Storage temperature -10°C to +60°C Storage humidity 10% to 85% Non-Condensing Storage altitude 30°C@ 0 to 12200m above sea level Dimensions...

  • Page 76: Timing Chart

    Timing chart Analog RGB Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) 640 x 480 60/72/75/85 SVGA 800 x 600 60/72/75/85 1024 x 768 60/70/75/85 1152 x 864 1280 x 768 15:9 WXGA 1280 x 800 16:10 60/75/85 1360 x 768 16:9 Quad-VGA 1280 x 960...
  • Page 77 HDMI Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) 640 x 480 SVGA 800 x 600 1024 x 768 1280 x 768 15:9 WXGA 1280 x 800 16:10 1360 x 768 16:9 Quad-VGA 1280 x 960 SXGA 1280 x 1024 SXGA+ 1400 x 1050 WXGA+...
  • Page 78 3D (HDMI signal included) Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) SVGA 800 x 600 60* / 120** 1024 x 768 60* / 120** 1280 x 720 16:9 60* / 120** WXGA 1280 x 800 16:9 60* / 120** HDTV (1080p) 1920 x 1080 16:9...
  • Page 79 Component video Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) HDTV (1080p) 1920 x 1080 16:9 50 / 60 HDTV (1080i) 1920 x 1080 16:9 50 / 60 HDTV (720p) 1280 x 720 16:9 50 / 60 SDTV (480p) 720 x 480 4:3 / 16:9 SDTV (576p) 720 x 576...

  • Page 80: Copyright Information

    Copyright 2019. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of ViewSonic Corporation. Disclaimer...

  • Page 81: Appendix

    Appendix IR control table Key (with Blue back light) Format Byte1 Byte2 Byte3 Byte4 Power On Power Off COMP HDMI HDMI2 HDMI3 HDBaseT Source Auto sync Up / V keystone + Blank Left / H keystone - Enter Right / H keystone + Menu Down / V keystone - Exit...

  • Page 82: Rs232 Command Table

    RS232 command table <Pin assignment for this two end> Description Description RTSZ CTSZ <Interface> RS-232 protocol Baud Rate 115200 bps (default) Data Length 8 bit Parity Check None Stop Bit 1 bit Flow Control None When select HDBaseT for RS232 control channel, change Baud rate to 9600.
  • Page 83 0x06 0x14 0x00 0x04 0x00 0x34 0x11 Write Blue 0x0A 0x01 0x68 Splash Screen 0x06 0x14 0x00 0x04 0x00 0x34 0x11 ViewSonic 0x0A 0x02 0x69 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x11 0x0A 0x68 0x06 0x14 0x00 0x04 0x00 0x34 0x11...
  • Page 84 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Front Table 0x00 0x00 0x5E 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Rear Table 0x00 0x01 0x5F Write Projector 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Rear Ceiling Position 0x00 0x02 0x60 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Front Ceiling...
  • Page 85 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Auto 0x04 0x00 0x62 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x04 0x02 0x64 0x06 0x14 0x00 0x04 0x00 0x34 0x12 16:9 0x04 0x03 0x65 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Aspect ratio 16:10 0x04 0x04 0x66...
  • Page 86 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x0A 0x00 0x68 Write Keystone- 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Increase Vertical 0x0A 0x01 0x69 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Get value 0x00 0x12 0x0A 0x69 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Brightest 0x0B 0x00 0x69...
  • Page 87 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x12 0x00 0x70 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Saturation Increase 0x12 0x01 0x71 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Get value 0x00 0x12 0x12 0x71 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x13 0x00 0x71...
  • Page 88 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x14 0x00 0x01 0x61 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x14 Mute 0x00 0x00 0x60 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x14 0x00 0x61 0x06 0x14 0x00 0x04 0x00 0x34 0x14 Increse 0x01 0x00 0x61 0x06 0x14 0x00 0x04 0x00 0x34 0x14...
  • Page 89 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x0d 0x6E 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x0e 0x6F 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x0f 0x70 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x10 0x71 0x06 0x14 0x00 0x04 0x00 0x34 0x15 Write...
  • Page 90 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x2B 0x00 0x88 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x2B 0x01 0x89 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x11 0x2B 0x89 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Error status Read Status...
  • Page 91 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x0C code 7 0x48 0x06 0xA6 Write Remote 0x06 0x14 0x00 0x04 0x00 0x34 0x0C code 8 Control code 0x48 0x07 0xA7 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x0C 0x48 0xA1 0x06 0x14 0x00 0x04 0x00 0x34 0x11...
  • Page 92 Function Type Action Command 0x02 0x14 0x00 0x04 0x00 0x34 0x02 Menu 0x04 0x0F 0x61 0x02 0x14 0x00 0x04 0x00 0x34 0x02 Exit 0x04 0x13 0x65 0x02 0x14 0x00 0x04 0x00 0x34 0x02 0x04 0x0B 0x5D 0x02 0x14 0x00 0x04 0x00 0x34 0x02 Bottom 0x04 0x0C 0x5E 0x02 0x14 0x00 0x04 0x00 0x34 0x02...
  • Page 93 Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) la/soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Peru) la/soporte/servicio-tecnico Macau www.hk.viewsonic.com T= 853-2840-3687 service@hk.viewsonic.com...
  • Page 94 ViewSonic . Please refer to the ViewSonic website in your country to check the local terms and model variants, and see if the product model in your country is eligible for a longer warranty period.
  • Page 95 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based...
  • Page 96 If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 97 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 (English); 866-323-8056 (Spanish); Tijuana, Mexico E-Mail: http://www.viewsonic.com...
