3 . 2 W a l l - M o u
3 . 2 W a l l - M o u
Vigor167 has keyhole type mounting slots on the underside.
1. Drill the holes on the wall according to the recommended instruction.
2. Fit screws into the wall using the appropriate type of wall plug.
Note
3. When you finished about procedure, the modem has been mounted on the
wall firmly.
n t e d I n s t a l l a
n t e d I n s t a l l a
The recommended drill diameter shall be 6.5mm (1/4").
t i o n
t i o n
