Multi-Protocol On-board Multi-function Print Server
NETWORK
NETWORK
NETWORK
USER'S GUIDE
USER'S GUIDE
USER'S GUIDE
MFC-8460N
MFC-8660DN
MFC-8670DN
MFC-8860DN
DCP-8065DN
Please read this manual thoroughly before using
this machine on your network. You can print or view
this manual from the CD-ROM at any time, please
keep the CD-ROM in a convenient place for quick
and easy reference at all times.
The Brother Solutions Center
(http://solutions.brother.com) is your one stop
resource for all your printing needs. Download the
latest drivers and utilities for your machine, read
FAQs and troubleshooting tips or learn about
special printing solutions.
Version D
